Original instruction
40V LITHIUM-ION CORDLESS CHAINSAW
Model: E212C,E214C,E216C
Operator's Manual and Part List
Before use please read & understand this manual, paying particular attention
to the safety instructions.
Retain these instructions for future reference
Manufacturer: Ningbo NGP Industry Co., Ltd.
Address: No. 88, Lane 666, Jinshan Road, C Zone Jiangbei Investment Center, Ningbo
315020, P. R. China
1 / 20
Advertisement
Table of Contents
Summary of Contents for Ningbo E212C
- Page 1 Before use please read & understand this manual, paying particular attention to the safety instructions. Retain these instructions for future reference Manufacturer: Ningbo NGP Industry Co., Ltd. Address: No. 88, Lane 666, Jinshan Road, C Zone Jiangbei Investment Center, Ningbo 315020, P. R. China 1 / 20...
-
Page 2: Table Of Contents
Original instruction CONTENTS • Contents………………………………………………………..….2 • Safety Instructions…………………………………….…..…..3-6 • Symbols……………………………………………………..……..7 • Technical Data………………………………………………..…8-9 • Assembly and Operation……..……………………………...10-11 • Maintenance and Storage……………………………………..12 • Trouble shooting and Guarantee………………………..….13-14 • Exploded View and Part List…………………………………..16 • EC Declaration of conformity……………………………………17 2 / 20... -
Page 3: Safety Instructions
Original instruction SAFETY INSTRUCTIONS Intended / not Intended Use This chain saw is only designed for cutting of brushes, trunks or timber beams up to a diameter according the guide bar length. It is only allowed to cut wood. Every other use of the machine is a not intended use. Furthermore a professional use for tree services is strictly forbidden. - Page 4 Original instruction c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. 2) Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.
- Page 5 Original instruction may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
-
Page 6: Chain Saw Safety Warnings
Original instruction with the equipment. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Do not use any battery pack which is not designed for use with the equipment. Keep battery pack out of the reach of children. -
Page 7: Causes And Operator Prevention Of Kickback
Original instruction loaded limb may strike the operator and/or throw the chain saw out of control. Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance. Carry the chain saw by the front handle with the chain saw switched off and away from your body. - Page 8 Original instruction The chain saw operator should keep on the uphill side of the terrain as the tree is likely to roll or slide downhill after it is felled. An escape path should be planned and cleared as necessary before cuts are started. The escape path should extend back and diagonally to the rear of the expected line of fall as illustrated in Figure 3.
-
Page 9: Symbols
Original instruction Bucking is cutting a log into lengths. It is important to make sure your footing is firm and your weight is evenly distributed on both feet. When possible, the log should be raised and supported by the use of limbs, logs or chocks. Follow the simple directions for easy cutting. - Page 10 Original instruction Wear eye protection Wear dust mask Do not expose to moisture Do not burn the battery Do not expose to rain or water Hold the chain saw by two hands Danger of Kickback: never cut with the tip of the chainsaw This product has been marked with a symbol relating to removing electric and electronic waste.
- Page 11 Original instruction COMPONENT PART 1.Chian bar 2.Chain 3.Chain tensioning knob 4.Locking knob 5.Cover plate 6 .Oil filler cap 7.Rear handle 8.Hand guard 9.Spiked bumper 10.Battery pack 11.Lock off button 12.On/off swtich 13.Blade cover 11 / 20...
- Page 12 Choose the type according to the work you intend to undertake. Refer to the accessory packaging for further details. Store personnel can assist you and offer advice. SPECIFICATION Model E212C E214C E216C Voltage 40V DC...
-
Page 13: Assembly And Operation
Original Instructions OPERATION ASSEMBLY and WARNING! Do not connect the chain saw to mains before it is completely assembled. Always use gloves when handling the chain. Assembly / Replacement of the Guide Bar and Chain The chain must be so fitted over the guide bar that the cutting edges of the cutters (a) face in the direction that the chain runs. - Page 14 Original Instructions Chain life and cutting capacity depend on optimum lubrication. Therefore, the chain is automatically oiled during operation via oil outlet. Filling oil tank: 1. Set chain saw on any suitable surface with oil filler cap facing upward. 2. Clean area around the oil filler cap with cloth unscrew cap. 3.
-
Page 15: Maintenance And Storage Of Chain Saw
Original Instructions • Stand slightly to left side of saw. This keeps your body from being in direct line with chain. • Do not let guide bar nose touch anything when chain is moving. • Never try cutting through two logs at same time. Only cut one log at a time. •... - Page 16 Original Instructions 3. Maintain chain saw with care. • Never expose saw to rain. • Keep chain sharp, clean, and lubricated for better and safer performance. • Follow steps outlined in this manual to sharpen chain. • Keep handles dry, clean, and free of oil and grease. •...
-
Page 17: Sharpening Saw Chain
Original Instructions FIG H SHARPENING SAW CHAIN WARNING: Remove battery pack from chain saw before servicing. Severe injury or death could occur from body contact with moving chain. WARNING: Cutting edges on chain are sharp. Use protective gloves when handling chain. Keep chain sharp. -
Page 18: Trouble Shooting
Original Instructions TROUBLE SHOOTING Symptom Possible Causes Possible Solution Chain saw fails to Out of battery Charge the battery pack operate Fuse faulty Replace fuse Loose connection Contact service agent Chain saw operates Internal wiring defective Contact service agent intermittently On/Off switch defective Contact service agent No oil in reservoir... -
Page 19: Exploded View And Part List
Original Instructions EXPLODED VIEW AND PAR LIST Part No. Description Part No. Description 20040080 Tension nut 25180150 tank assembly 70030580 Tension shaft 20260010 Auxiliary handle 20670020 Upper cover 20030050 Brake guard 70670200 Tension gear 30080080 Chain 70220040 Tension bar 30080070 70220050 Tension rod 30090010... -
Page 20: Ec Declaration Of Conformity
EC- Declaration of Conformity Ningbo NGP Industry Co., Ltd. No. 88, Lane 666, Jinshan Road, Investment Center, Ningbo, Zhejiang, P. R. China Herewith we, declare that the following Appliance complies with the appropriate basic safety and health requirements of the EC Directives (see item 4) based on its design and type, as brought into circulation by us.
