Eliminator Lighting Electro 196 II User Manual

Electro 196 II
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.

Operating Instructions:

The Electro 196 II has been tested at the factory, there is no assembly required. The unit is ready to
be plugged into a power outlet. This unit is a 8 channel DMX intelligent LED par can. It can be run as
a stand-alone unit, DMX controlled unit, or in a Master/Slave configuration. While in Stand Alone or
a Master/Slave configuration, you can run the auto mode, sound active mode, or control the colors
and intensity manually. For stand-alone mode, Master/Slave configuration, and DMX Control see
other side.

1 Year Limited Warranty:

1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

SPECIFICATIONS:

Model:
Lamp:
Weight:
Size:
Fuse:
Supply Voltage:
Working Position:
Duty Cycle:
DMX Channels:
Colors:
Warranty:
Eliminator Lighting warranty is valid from the date of purchase. Our
Caution! Never open unit when in use.
Always disconnect main power before
replacing fuse. Remember to always
replace with the exact same type fuse.
Electro 196 II
L.E.D. (84 Red, 51 Green,
and 60 Blue)
2.8lbs./ 1.3kgs.
6.14" (H) x 8.07" (W) x
6.8" (D)
2 Amp
120V
Any Safe position
None
8
Multiple Colors
1 Year
