SIMPLE-2
SERVICE MANUAL
DVD PLAYER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-00A-350-7T3).
XD-DV170
BASIC DVD/CD MECHANISM : DV32BF
A par t of contents is adequate.
Re-issuing is under r equest.
S/M Code No. 09-00A-350-7R4
HR(S)
