MICROFLASH 4T

User's Guide

Table of Contents

Need help?

Do you have a question about the Microflash 4T and is the answer not in the manual?

Questions and answers

Summary of Contents for O'Neal Microflash 4T

Page 1 MICROFLASH 4T User's Guide...
Page 3: Table Of Contents
TABLE OF CONTENTS microFlash 4t Printer: Top View Installing a Radio Card Using Batteries: General Guidelines Installing and/or Replacing Batteries Charging the Battery Determining Battery Condition Installing Paper Printing a Self-Test Configuring the Printer Using Printer Data Cables Using 802.11b/Bluetooth 802.11b Parameters...
Page 4: Microflash 4T Printer: Top View
MICROFLASH 4T PRINTER USER'S GUIDE microFlash 4t Printer: Top View Battery Retaining Clip Battery/Battery Well RF/Power Button/LED Self-Test Button Charge LED Print Head Release Lever Data Port Roller Power Port Paper/Paper Cavity Figure 1...
Page 5: Installing A Radio Card
MICROFLASH 4T PRINTER USER'S GUIDE Installing a Radio Card Note: The following information applies to printers with radio capabilities. Caution: Before installing the radio card, verify the red, battery isolator labels are in place or remove the batteries before installing the radio card.
Page 6: Using Batteries: General Guidelines
MICROFLASH 4T PRINTER USER'S GUIDE Using Batteries: General Guidelines If your printer came with batteries already installed, remove the red, battery isolator labels. If your printer did not come with batteries installed, see Installing and/or Replacing Batteries on this page If you are storing your printer for a long period of time, reinstall the battery isolator labels.
Page 7: Charging The Battery
MICROFLASH 4T PRINTER USER'S GUIDE Charging the Battery To charge the battery, you must first remove the red, battery isolator labels. If the battery is low when the printer “wakes up,” the printer sounds three short beeps. Plug the AC Adapter into an appropriate power source.
Page 8: Installing Paper
MICROFLASH 4T PRINTER USER'S GUIDE Installing Paper 1. Insert a roll of paper with the end of the roll exiting from the bottom of the paper cavity (Figure 8). 2. Open the print head by raising the gray, print head release lever until it is fully open.
Page 9 MICROFLASH 4T PRINTER USER'S GUIDE 5. Lower the gray, print head release lever (Figure 12). 6. Feed the paper through the printer's cover (Figure 13). Figure 13 Figure 12 7. Close and latch the printer's cover.
Page 10: Printing A Self-Test
MICROFLASH 4T PRINTER USER'S GUIDE Printing a Self-Test 1. After installing the paper, open the printer's cover. Caution: If the red, battery isolator labels are installed, remove them. 2. Press and hold the red, self-test button for approximately five seconds until printing begins.
Page 11: Using 802.11B/Bluetooth
MICROFLASH 4T PRINTER USER'S GUIDE Using 802.11b/Bluetooth Note 1: The following information applies to printers with 802.11b/Bluetooth capabilities. Note 2: e only authorized 802.11b radio cards in O’Neil printers. For information on authorized 802.11b radio cards, contact O'Neil Product Development at (949) 458-0500.
Page 12: Using Buttons, Leds, And Audio Indicators
MICROFLASH 4T PRINTER USER'S GUIDE Using Buttons, LEDs, and Audio Indicators Button Functions Red Self-Test Button Short press If printer is asleep; printer wakes up. If printer is awake; paper feeds. Long press (press Prints a self-test. and hold for five...
Page 13: Charge Led Indicators
MICROFLASH 4T PRINTER USER'S GUIDE Charge LED Indicators State of Charge Action Solid Red Charge in progress. Wait for the charge LED to turn green. Green Charge complete. None. Red flash - Battery is disconnected. Connect battery. slow Battery is too cold.
Page 14: Audio Indicators
MICROFLASH 4T PRINTER USER'S GUIDE Audio Indicators Beep(s) Description Action Printer wakes up. None. Out of paper. Install paper. Low battery. Charge battery. 1 short RF power is on (when blue, None. RF power button is pressed and power was turned off).
Page 15: Using A Cardreader
MICROFLASH 4T PRINTER USER'S GUIDE Using a CardReader Note: he following information applies to printers installed with the CardReader option. CardReader CardReader Slot Figure 15 General Guidelines To wake up the CardReader, insert a card into the CardReader slot. One short beep indicates the CardReader/printer is awake.
Page 16: Agency Approvals
MICROFLASH 4T PRINTER USER'S GUIDE Agency Approvals FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 17 MICROFLASH 4T PRINTER USER'S GUIDE Warranty The Company warrants that O'Neil Product Development, Inc.'s products are free from defects in manufacturing materials and workmanship for one (1) year from date of original purchase to Buyer/Distributor (OEMs 90 days from the date of purchase).
Page 18: Supplies
MICROFLASH 4T PRINTER USER'S GUIDE Supplies Use only supplies certified by the Original Equipment Manufacturer (OEM). For OEM supplies, please contact O’Neil at (949) 458-0500. Media Supplies O'Neil Product Development, Inc. offers seven certified grades of paper for use in the PrintPAD series of printers.
Page 19: For More Information
MICROFLASH 4T PRINTER USER'S GUIDE For more information For information about using the printer, contact O'Neil at (949) 458-0500, or visit wsww.oneilprinters.com.
Page 20 World Headquarters O'Neil Product Development 8 Mason Irvine, CA 92618-2705 Ph: 949.458.0500 Fx: 949.458.0708 Europe 6 Joplin Court, Crownhill Milton Keynes MK8 0JP United Kingdom Ph: +44 (0) 1908 635360 Fx: +44 (0) 1908 635361 AustralAsia 1/8 Railway Terrace Dutton Park QLD 4102 Austalia Ph: +61 (7) 3255 3360...
