(These instructions are intended for use by a technician familiar with electronic products)
Unit
m onitors
b atteries
f or
o ptimal
c harging
a nd
•
maintenance
Highly
r ecommended
f or
d eep
c ycle
o r
g el
c ell
b atteries
•
Extended
b attery
l ife
•
Indicator
l ight
f or
b attery
c onditions
•
110
/
2 20
V AC
s witch
s electable
•
Battery
p olarity
p rotection
•
Approvals:
U L,
C UL,
C E,
T EV
•
Manufactured
t o
I SO
9 001
Q uality
A ssurance
•
3
y ear
w arranty
•
DESCRIPTION
The SC series is designed to auto-charge and maintain Gelled electrolyte (Gel-Cell) and liquid electrolyte lead-acid batteries.
The SC series is a constant current monitoring charger for the charge and maintenance of fixed location UPS, emergency lighting
systems, and telecommunications battery backup systems. The charger is protected against over loading by deep discharge start
circuitry with auto shut down due to over-voltage, over-temperature, short circuit and reverse polarity. Switch mode circuit design
provides high efficiency, compact size, cool operation and high reliability. Dual color red/green LED provides a visual indication of
charger status.
SPECIFICATIONS
Output Voltage ............................................................................................................................................................................... 13.8 VDC
Maximum Power, continuous.........................................................................................................................................................120 Watts
Maximum output current ....................................................................................................................................................................7 Amps
Input voltage range .................................................................................................................................................. 90-130 or 180-260 VAC
Max inrush current, single cycle ......................................................................................................................................................35 Amps
Input frequency range ..................................................................................................................................................................... 47-63 Hz
Typical Efficiency ....................................................................................................................................................................................80%
Short Circuit protection ...................................................................................................................................................... Foldback Limiting
Overload Protection (operates)........................................................................................................................................typical 105-150 pct
Fan Control ................................................................................................................................................................ High rate charge = ON
Over Temperature ............................................................................................................................... >195 F (90 C) auto output shutdown
Working Temperature range ..................................................................................................................................... -4 – 140 F(-20 -+ 60 C)
Storage Temperature............................................................................................................................................. -40 – 185 F (-40 - +85 C)
Dimensions .................................................................................................................................................2 H x 4 W x 7 D inches, nominal
Weight...................................................................................................................................................................................2.5 lbs, nominal
SC-‐12
Smart
C harger
S eries
Owners
G uide
1
Advertisement
Table of Contents
Summary of Contents for DuraComm SC-12
-
Page 1: Specifications
SC-‐12 Smart C harger S eries Owners G uide (These instructions are intended for use by a technician familiar with electronic products) Unit m onitors b atteries f or o ptimal c harging a nd •... - Page 2 The individual user should take care to determine, prior to use or installation, whether this device is suitable, adequate and safe for the use intended. Since individual applications are subject to great variation, DuraComm makes no representation or warranty as to the merchantability, suitability or fitness of these units for any specific application.
- Page 3 CONDUCTOR PRETREATMENT All kinds of copper conductors can be clamped without treatment. DO NOT solder tin stranded conductors. The solder yields and fractures under high pressure. The result is increased contact resistance and excessive temperature rise. Additionally, corrosion has been observed due to the fluxes. Notch fractures at the transition from the rigid tinned part to the flexible conductors are also possible. Ferrules can be used as a protection when wiring stranded conductors.
-
Page 4: Limited Warranty
DuraComm, at its option, will repair or replace the faulty product or parts thereof, which, after examination by DuraComm, prove to be defective or not operational according to specifications in effect at the time of sale to the initial end user. The product that is replaced or repaired under the provisions of this warranty, will be warranted for the remainder of the original warranty period, only, and will not extend into a new three year warranty period.
