Thank you for purchasing your new OWC Mercury

Elite Pro hard drive enclosure. Follow these steps

to install your hard drive mechanism.

Unpack your new OWC Mercury Elite Pro enclosure. Depending

on the model purchased, you will have different interface cables.

Shown above is the contents of the 'Quad Interface' model. The

FireWire / USB only model will include feet, power cord, power

supply, FireWire 400 cable, and USB 2.0 cable.

All OWC Mercury Elite Pro enclosures include an interface cable

for each of the different ports the enclosure supports.

Extra accessories are available on our website, if you plan on

using your new enclosure at work and home, you may want to

purchase a second

Remove the top cover from your OWC Mercury Elite Pro enclo-

sure by sliding the top cover towards the rear of the unit. Then,

remove the single Phillips screw securing the top metal shield,

and lift up on it to remove, exposing the inside of the enclosure.

Remove the taped down packet of screws.

Need help?

Do you have a question about the Mercury Elite Pro Classic and is the answer not in the manual?

Page 1 Thank you for purchasing your new OWC Mercury Elite Pro hard drive enclosure. Follow these steps to install your hard drive mechanism. Unpack your new OWC Mercury Elite Pro enclosure. Depending on the model purchased, you will have different interface cables. Shown above is the contents of the ‘Quad Interface’...
Page 2: System Setup
Lay the power and SATA wires flat inside the case, then place the metal shield back on top of the enclosure. Secure the metal shield with the 3 short Phillips screws that were inside the clear plastic bag and the one screw you removed to initially remove the metal cover - it takes 2 per side to assemble.
