Summary of Contents for SEDONA SD-9000
- Page 1 F O O D D E H Y D R A T O R S EDO NA DEHYD R AT O R OPERATION MANUAL MODEL: SD-9000...
-
Page 2: Introduction
Be sure to carefully unpack your Sedona and check that all of the parts are included with your package. Also take the time to become familiar with the functions of the unit before you begin dehydrating foods. -
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction........................2 Important Safety Precautions..................4 Safety Tips........................5 Parts List........................6 Operation........................7 Set-Up..........................8 Cleaning and Maintenance....................11 Troubleshooting......................12 Warranty........................13 Registration Form......................15 When You Need Service....................17 Recipe Index.........................18 Product Information......................24... -
Page 4: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should always be followed including the followings: 1. Read all instructions. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock do not immerse cord, plugs, Dehydrator in water or other liquid. -
Page 5: Safety Tips
To avoid any possible damage or injury, please follow the basic safety tips: • Do not clean the Sedona with water. Always use a wet towel to clean the Sedona. • Never use Sedona in a humid room such as a bathroom. Use Sedona in a well venti- lated setting. -
Page 6: Parts List
*Please Note: Each unit is packaged with sponge tray holders. Please make sure to remove the sponge tray holders before using Sedona. The sponge tray holders were designed to keep your trays in place during transportation. They are not intended to be used with the normal operation of Sedona. -
Page 7: Operation
• For 4-5 trays of dehydrated recipes, please use the upper compartment for best results. 3. Open the door to insert trays into the Sedona. Hold the tray in the horizontal position and push the tray into the proper slots. -
Page 8: Set-Up
Select which temperature mode you want to display by pressing °F/°C button. The basic setting of Sedona is Celsius when out of the factory. Once you set the machine to Celsius or Fahrenheit, the Sedona will remember your setting even after you turn OFF the switch. - Page 9 9 trays of foods or up to 4 trays of food in either the upper half or the lower half of the unit. Sedona is designed to operate the whole unit or only operate the upper half or only operate the lower half in order to conserve energy when dehydrating smaller quanti- ties of food.
- Page 10 START/PAUSE button, then press the SET button and change the temperature and/or time. Then press START/PAUSE button to re-start the Sedona. NOTE: Sedona can be used to dehydrate up to 4 trays of food for smaller batches of dehy- drated foods.
-
Page 11: Cleaning And Maintenance
2. To clean the main body, first unplug the machine and then clean with a wet towel. Do not rinse the Sedona with water or submerge the machine in water. 3. Make sure the trays and tray sheets are thoroughly dried before inserting them back into the machine. -
Page 12: Troubleshooting
TROUBLESHOOTING Symptom Probable Cause Remedy Machine does not turn on • the plug is incorrectly posi- • plug in again tioned in the electrical outlet • turn the switch on • the machine switch is not on Display lights are not on •... -
Page 13: Warranty
We warrant to you, the “end-user” who has properly registered after purchasing the Sedona Dehydrator (hereinafter referred to as “SD”) for a valuable consideration, that the Plastic Body, Fan Motor and the Heating Coil of this SD will be free from defects in materials and workmanship for a period of five (5) years from the date of purchase. - Page 14 TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.
- Page 15 Please initial here if you would NOT like us to send you important product updates and announcements: _________ If you have comments or suggestions about our product, please write to: Sedona Customer Relations, P.O. Box 4089, Cerritos, CA 90703...
-
Page 16: Registration Form
$25,000-$50,000 $50,000-$75,000 $75,000-$100,000 more than $100,000 • What factors most influenced your decision to purchase a Sedona? (please check up to three) Sedona reputation Style and appearance Value for the price Special product features ... -
Page 17: When You Need Service
When You Need Service In the unlikely event that you require service on your Sedona Dehydrator, or if it fails to function properly within the warranty period during normal household operation, contact the Sedona Warranty Service Center. SERVICE CENTER **For all service inquiries, please contact the Warranty Service Center for a Return Merchandise Authorization (RMA) number and proper routing instructions. -
Page 18: Recipe Index
Learn more about Jenny Ross by visiting www.shop118degrees.com Sprouted Grain Tortilla....................19 Basic Squash Flax Tortilla.....................19 Garden Crackers......................20 Basic Flax Crackers.......................20 Marinataed Vegetables....................21 Sweet Sedona Cookies....................22 Easy Fudge Brownies....................22 *Recipes by Elysa Markowitz, author and raw food expert. Kale Chips........................23 Dehydrated Spices......................24 Fruit Chips........................24... - Page 19 *Sprouted Grain Tortilla 2 Cups Sprouted Wheat Berry, Rye or Kamut 1 Cup Ground Golden Flax Seed 1 Zucchini 2 Tbsp. Chili Powder 1 Tsp. Sea Salt 2 Cups Water In a high powered blender combine first the sprouted grains, zucchini, spices and then ground flax seed.
- Page 20 *Garden Crackers 4 Cups Ground Golden Flax Seeds 2 Cups Carrot Juice (and leftover pulp) 2 Cups Water 4 Tomatos 1 Clove Garlic 1 Stem Green Onion 1 Tbsp. Dried Dill or Italian Seasoning 1 Tsp. Sea Salt In a high powered blender combine the carrot juice, water, tomato, garlic green onion, sea salt and dried seasonings until a puree forms.
- Page 21 *Marinated Vegetables Vegetables are quite nice in the dehydrator in fact just coating vegetables like squash, red bell peppers and mushrooms with a little bit of high quality extra virgin olive oil and dried spices will yield a nice soft vegetable within an hour with an enhanced flavor profile. Try the marinade and vegetable mix below to get an idea of what is possible in your own kitchen.
- Page 22 *Cookies - Sweet Sedona’s 4 Cups Macadamia Nuts or Cashews 1 Cup Raw Cacao (optional) 2/3 Cup Raw Honey or Agave Nectar 1 Tsp. Cinnamon 1 Tsp. Sea Salt 1 Dash Nutmeg For Garnish – Coconut Shreds, Soaked Gogi Berries or Hemp Seeds In a food processor add the nuts, cacao, cinnamon, nutmeg, and sea salt.
- Page 23 To prepare the brownie: In a food processor, process nuts to a meal being careful not to over process into a butter. Then add to the mixture the cacao and spices and pulse to combine. Turn on the processor all the way and add the desired sweetener from the top while pro- cessing until a dough ball forms.
- Page 24 *Dehydrated Spices Choose the leaves of spice(s) you want to dehydrate: - Parsley - Dill - Rosemary - Thyme - Oregano - Basil - Sage - Whatever spice you want dried Chose the spice(s) you want to dehydrate. If you want to keep them separate, keep each spice on different trays –...
- Page 25 Soy sauce (especially good on tomatoes) – Nama Shoyu or low Sodium, wheat free San-J Soy Sauce Fruit concentrates: Black cherry Pomegranate Cranberry Orange Elderberry Pineapple Clean fruit(s), take off skin, where appropriate (like bananas, papaya, pineapple), and take out pits (like plums, apricots, cherries, etc.) and cut / make into thin slices. Put fruit into a bowl and coat / cover with desired marinades / sweetener(s) / spice(s) –...
- Page 26 In blender mix ingredients together – adding first one cup of water, and adding more water to create ‘thick soup’ like consistency (up to 2 cups). Pour pecan mixture into glass pie plate and put into dehydrator and dehydrate at 110 degrees until a ‘mouse like’...
-
Page 27: Product Information
PRODUCT INFORMATION Product name: Sedona Dehydrator Power: 120Vac, 60Hz, 600W for the USA and Canada 220-240Vac, 50/60Hz, 550-650W for European and Asian countries Size: 433mm(W) x 370mm(H) x 500mm(D) 17.05in(W) x 14.6in(H) x 19.7in(D) - Page 28 Tribest Corporation P.O. Box 4089 Cerritos, CA 90703 toll free: 888-254-7336 | fax: 714-879-7140 www.tribest.com | service@tribest.com ©2011 Tribest Corp. v20110421...
