Vlt1 – User Manual Ver 2.0 (Vlt1_Eagles.hex) Content Features ......................................3 Pedal elements ....................................4 Connections ....................................... 5 Function Modes ....................................7 4.1. Bank Mode ....................................8 4.2. Edit Mode .................................... -
Page 3: Features
You can configure the functions of each switch • Expression pedal Input • Input power supply: 12V DC 2A • 2 Output power supply at 12V DC (600mA) and 9V DC (600mA) • Dimensions (LxAxH in mm): 454x86x50 • Programming over Bluetooth using app JomLabs Control •... -
Page 4: Pedal Elements
Exit A. Switchs A) Switches: The Dsh4 pedal has 8 backlit switches labelled A to H. Each of the functions assigned to the switches are configurable (see section 4.2.6. - General Settings). B) Loops Indicator It shows which loops are activated in each module. -
Page 5: Connections
Connect included power supply to this input to use the pedal. B) Power Outputs Dsh4 pedalboard can supply 12V DC and 9V DC power. See polarity schema indicated. These outputs may provide up to 600mA. C) Midi Connections Connect Midi Ouput to the device to control Midi Input. If you have a compatible device that can send tuner info over Midi, connect device's Midi output to the Dsh4's Midi input. - Page 6 Ver 2.0 (Vlt1_Eagles.hex) E) Loops modules Dsh4 has to separate loops modules. They have 4 connections for effect pedals and an Input and Output. If you do not connect the module 2 output, this is connected directly to the module 1 input.
-
Page 7: Function Modes
Tuner Mode: It allows get tuner information sent by compatible Midi Devices. • Dsh4 pedal board contains 8 switches labelled A to H. These switches provide four different functions depending on current mode selected: In Bank Mode: You can change current bank or send functions configured in the switches •... -
Page 8: Bank Mode
Vlt1 – User Manual Ver 2.0 (Vlt1_Eagles.hex) 4.1. Bank Mode After pressing change bank switch, this one lights on and the screen will show song and bank names. After selected the bank, next actions are made: Toggle On loops configured •... -
Page 9: Edit Mode
In any screen edit mode pressing F & G returns to the previous screen and pressing switches G & H leaves edit mode (if you have changed any parameters Dsh4 will ask the user whether to save the bank). The following diagram shows the menus and screens available in Edit mode:... -
Page 10: Loops Activation / Deactivation
Vlt1 – User Manual Ver 2.0 (Vlt1_Eagles.hex) The next table shows functions associated to each switch: Edit Mode A Configure loops activation B Configure Midi Commands C Set bank name, song name, effects names and Control Change Toggle names D Configure Control Change Commands Setting attenuator and booster level for the bank General Settings 4.2.1. -
Page 11: Midi Commands
Vlt1 – User Manual Ver 2.0 (Vlt1_Eagles.hex) 4.2.2. Midi Commands You can configure up to 8 Midi Commands in each Bank. Available commands are: Midi Commands Continius Control Change Start Stop Note Off Program Change Continue Note On Clock You can associate Midi commands to events in the bank. Next table shows available events: Events DISABLED Midi command disabled... - Page 12 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) Next table shows functions associated to each switch: Midi Commands A Decrement parameter value B Increment parameter value C Select previous parameter D Select next parameter It is very important to establish the event in which the Midi will be sent, otherwise it will not be sent once made the push command...
-
Page 13: Edit Names
Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.2.3. Edit names In this section you can set song, bank, effects and control change toggle names. Next table shows functions associated to each switch: Select name to edit A Edit current song... -
Page 14: Control Change Toggle Commands
After selecting the group of commands, pressing each of the switches activate or deactivate the command and lighting on the switch if the command is activated. When the command is activated, Dsh4 sends value 127 to the Midi Channel and Midi Command configured (see section 4.2.7.1 Midi Values on Control Change Toggle Commands). -
Page 15: Setting Volume Levels
Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.2.5. Setting Volume levels Using this option you can set attenuator level and Booster level for the selected bank. A level of 100 for the attenuator means no reduction in volume for the bank. -
Page 16: General Settings
Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.2.6. General Settings In this menu you can configure next options: Switches functions • Control Change Toggle Commands values • General options • Next table shows functions associated to each switch: General Settings... -
Page 17: Switches Function Settings
Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.2.7. Switches function settings Vlt1 pedal lets you configure the behaviour of the switches of all the control options available for the switches and combinations of them. There are 4 actions that can be configured related to the type of press: Simple press •... - Page 18 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) Next table shows available behaviours: Behaviour Description None No function set Go Bank Load the bank Bank Up Next Bank Bank Down Previous Bank Edit Bank Edit current selected Bank Song Down Previous song...
- Page 19 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) Some features are not supported with pressing type, function and event. Next table shows compatible features: Press type Function Compatible Events Not Compatible Events BANK 1ST BANK 2ND Simple Press Go Bank LONG PRESS...
- Page 20 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) Next table shows default factory settings defined: Press type Function Press type Function BTNA Go Bank BTNA.RLS None BTNB Go Bank BTNB.RLS None BTNC Go Bank BTNC.RLS None BTND Go Bank BTND.RLS None...
- Page 21 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) Next table shows functions associated to each switch: Switches functions settings A Previous function B Next function C Previous switch D Next switch 4.2.7.1. Control Change Toggle Commands Midi Values Use this menu for setting Midi values for the 16 Control Change Toggle Commands and their names.
- Page 22 Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.2.7.2. General Options In this menu you can set general options for the Vlt1 Pedal: Available options are: Option Values Use BT Yes Use Bluetooth Use this options for switch on / switch off Bluetooth function to avoid interferences.
-
Page 23: Jam Mode
Dsh4 – User Manual Ver. 1.0 (Dsh4_Deep_Purple.hex) 4.3. Jam Mode Pressing simultaneously switches D & E (factory setting), or through the definition of a function in a switch, you can set Jam mode. In this mode you have direct access to the activation / deactivation of the Loops for each switch. -
Page 24: Tuner Mode
Midi Device. You need to connect a standard Midi Cable from Midi Out in your device to Midi In port in the Dsh4. There are some devices likes Fractal Axe which need to set tuner mode also. To set tuner mode in the device, Dsh4 can send Midi Command at the beginning and end of tuner mode. -
Page 25: Bluetooth Connection
5. Bluetooth Connection Dsh4 pedal has a Bluetooth port useful to send commands and parameters using JomLabs Control app, available in Google Play. To avoid unwanted access to Dsh4 pedal is recommended deactivate Bluetooth function after configure banks and settings (See section 4.2.6.3 –...
