- Page 1 ENGLISH S-RH/T HUMIDITY AND TEMPERATURE AMBIENT AIR SENSOR INSTALLATION AND OPERATING INSTRUCTIONS...
- Page 2 DESCRIPTION This sensor measures ambient relative humidity as well as temperature. It miniaturized sensitive element uses a CMOS capacitive relative humidity sensor and a band gap temperature sensor, for a very precise and stable measurement with a very low consumption. The sensor is self calibrated. The user can choose between two outputs: 0-10 V or PWM.
- Page 3 WARNINGS PLEASE READ THE FOLLOWING INSTRUCTIONS BEFORE THE INSTALLATION: ∙ In case of non-compliance with advice and warnings contained in this manual, the manufacturer can not be considered responsible for damages to persons or property. ∙ The installation and electrical connections must be carried out by a qualified technician according to the manufacturer’s instructions and in compliance with the characteristics of the product...
- Page 4 INSTALLATION Sensors must be installed on the wall, at a height of at least 1.5 meters from the floor, or at the ceiling, and must respect the following recommendations: ∙ keep the sensor away from any direct solar radiation, ∙ keep the sensor away from draughts (door, window, supply, etc.), ∙...
- Page 5 STEPS 1. Remove the front cover (A). 2. Unclip the electronic card (B) and the plastic protection (D) from the base (C). 3. Fix the base (C) by the mean of 2 screws (not supplied). The screws and plug must be chosen according to the type of the support. 4.
- Page 6 CAUTION! Chemical vapors at high concentration in combination with long exposure times may offset the sensor reading. In manufacturing and transport the sensors shall be prevented of high concentration of chemical solvents and long exposure times. Out-gassing of glues, adhesive tapes and stickers or out-gassing packaging material such as bubble foils, foams, etc.
-
Page 7: Technical Data
TECHNICAL DATA Capacitive humidity sensor Measurement principle Band gap temperature sensor -40°C +120°C Working range 0 % - 100% Relative Humidity max +/-3 % RH at 25°C, Precision RH typical +/-2 % on 20 % -80 % range. Precision temperature max +/-0,4°C in [5°C ; 60°C] range, typical 0,3°C. Measuring time interval 60 s Supply voltage... - Page 8 WARRANTY The product is guaranteed two years. Its validity is submitted to conformed installation, use and maintenance. This product is manufactured by Aereco S.A. in France 62 rue de Lamirault Collégien 77615 MARNE LA VALLEE CEDEX 3 FRANCE www.aereco.com...
