Aluminium Walkers—
Product Codes:
LM3206 Aluminium Walker, 150mm (6") Castor, curved fold up backrest, 54cm
seat height, security bag, ball end brake handle, in-line brakes.
LM3208 Aluminium Walker, 200mm (8") Castor, curved fold up backrest, 55cm
seat height, security bag, ball end brake handle, in-line brakes.
LM3206BM
LM3206BU
LM3206CM
LM3206PU
LM3206SM
6" Blue Metallic
6" Burgundy Metallic
6" Copper Metallic
6" Purple Metallic
6" Silver Metallic
LM3206 & LM3208
LM3208BM
8" Blue Metallic
LM3208BU
8" Burgundy Metallic
LM3208CM
8" Copper Metallic
LM3208PU
8" Purple Metallic
LM3208SM
8" Silver Metallic

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM3206 and is the answer not in the manual?

Questions and answers

Related Manuals for Evocare LM3206

Summary of Contents for Evocare LM3206

  • Page 1 Aluminium Walkers— LM3206 & LM3208 Product Codes: LM3206 Aluminium Walker, 150mm (6") Castor, curved fold up backrest, 54cm seat height, security bag, ball end brake handle, in-line brakes. LM3208 Aluminium Walker, 200mm (8") Castor, curved fold up backrest, 55cm seat height, security bag, ball end brake handle, in-line brakes.
  • Page 3 150MM (6”) Castors—LM3206 200MM (8”) Castors—LM3208 Note: Maximum user weight for this product is 120kg Evocare is a quality endorsed company and supplies equipment listed with the Therapeutic Goods Administration. The ARTG number for the Walkers is 179500 Page 3.
  • Page 4 Backrest Carry Bag/ Security Bag Star Wheel Nut Bolt Washer Page 4.
  • Page 5 Step 2. Step 1 : Remove all Plastic—Open Walker by spreading the wheels apart and lowering the seat. Remove Star Wheel nut and washers. Step 2 :Insert handles into the tubes on the sides of the walker. Step 3. Step 3 : Align holes of the handle and the tube. Place Bolt through the hole at the desired handle height.
  • Page 6 Step 5. Step 5: Place the padded backrest into the brackets on the frame at the rear of the seat. Press buttons and click into place. Handgrip Brake To operate brakes on walker: lock brakes on by placing hands in levers under handgrips and then pushing down.
  • Page 7 Step 5. Handgrip Handlebar Screw Brake Holder Ball End Brake Brake Cable 2. Place brake cable onto the ball 1. Place brake holder into handle- end brake via brake holder bar and tighten the screw 4. Install handgrip onto 3. Place ball end brake handlebar onto brake holder Page 7.
  • Page 8 Step 5. Handgrip Handlebar Screw Brake Holder Ball End Brake Brake Cable To un-Install: Reverse the procedures. 1. Take out the hand grip 2. Separate the ball end brake and brake holder 3. Un-install the brake cable 4. Screw out the bolt. Page 8.
  • Page 9 The tyres and wheels need to be checked periodically for cracks and wear. If problems are indicated, the problem parts should be identified and replaced immediately. Should brakes need adjusting, consult your local supplier or Evocare Australia. Page 9.
  • Page 10 LM3206 Folding Four Wheel Walker, Adjustable height anatomical hand grips, brakes, folding backrest, 6” wheels and Security bag under seat. Z02A01 Nylon nut cover M01LA802L Front fork 8" walker left B02LA803 Rear fork M01LA802R Front fork 8" walker right AZ01LA803 Castors 8"...
  • Page 11 PARTS LIST FOR WALKERS Nut for Cable Brake Gear Plate Arc Washer H01LA802C A01LA803 H01LA802 Backrest Holder Nylon Nut Brake Spring AU01LA808L—left Z02A01 Y01LA803 AU01LA808R—right Seat Retainer Cupper Screw E01LA802 L01LA809 Page 11.

  • Page 12: Cleaning And Maintenance

    CLEANING & MAINTENANCE Regular cleaning and inspection is recommended. Ensure the walking frame is kept clean. Wipe down the walking frame with a damp cloth on a regular basis. Page 12.
  • Page 13 (as the case may be) free of charge provided that the following procedures are met (a) The consumer must contact the Retailer or Evocare upon becoming aware of any defect to a Product upon which the consumer will be required to complete a Form and provide...
  • Page 14 Your Evocare Walker is warranted to be free of defects in material and workmanship for 12 months, for the original consumer. NOTE: This warranty does not cover device failure due to owner misuse, negligence, or normal wear and tear. The warranty does not extend to non-durable components such as rubber accessories, brakes and grips, which are subject to normal wear and tear.

This manual is also suitable for:

Lm3208
