EVGA TEGRA NOTE 7 Quick Start Manual

02
InCLUDED In ThE BOX
The following equipment is included in the
Tegra NOTE 7 box.
Tegra nOTE 7 micro USB to
DirectStylus USB Cable
US/China hong Kong/UK
AC Adapter AC Adapter
!
Attention: Only the adapter for your area will be included in
the box. It is recommended that you use the USB cable/AC
adapter that comes with your Tegra NOTE 7.
www.evga.com
03
EQUIpmEnT In-DEpTh
Dual Speakers
Front Camera
(located behind the glass)
Microphone
(located behind speaker grill)
Europe
AC Adapter Bass Reflex Port
(located on bottom edge)
Cover Slot
(holds cover stand accessory in
place. Located on bottom edge.)
QUICK START GUIDE
Front
01
SPECIFICATIONS
Thank you for choosing the Tegra NOTE 7.
Your new Tegra NOTE 7 brings together a set of premium
features and innovations that are the foundation of the tablet.
Your tablet is loaded with the Google Android
system and will function as any standard Android device.
Specifications Premium
Processor NVIDIA Tegra 4 - up to 1.8 GHz Quad+1 Cortex A15, 72 core
NVIDIA GeForce GPU, 1080p video decode, encode / record
System Memory 1 GB DDR3L-1600, 12.8 GB/s
Camera VGA Front webcam, 5 MP AF instant HDR rear
Storage 16 GB e.MMC
Audio Front facing stereo speakers with unique bass reflex port.
Tegra nVoice audio processing for increased volume, noise
reduction, and echo cancellation.
Enhanced frequency range for more natural voice and
higher highs.
Touchscreen High-speed 10-point capacitive DirectTouch
Connectivity 802.11 b/g/n Wi-Fi, WiFi Direct, Bluetooth 4.0 LE, GPS/
GLONASS
Sensors 9-axis (gyro, accelerometer, compass)
Interfaces USB2.0 with host and device support
3.5 mm audio jack with mic support
Front mic for chat and voice commands
HDMI with up to Ultra HD 4K display support
Battery 4100 mAh for up to 8 hours HD video playback
Stylus
Stylus Slot
Back
™ 4.2.2 operating
Volume
MicroSD Card Slot
Camera
Power/Lock
3.5 mm
Headphone Jack
HDMI
Micro USB
