User Manual

IP CAMERA
1/67

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ovc-2birsf and is the answer not in the manual?

Questions and answers

Related Manuals for fine ovc-2birsf

Summary of Contents for fine ovc-2birsf

  • Page 1: User Manual

    User Manual IP CAMERA 1/67...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK).

  • Page 3: Table Of Contents

    Content PREFACE ........................4 PRODUCT SPECIFICATIONS ..................4 III. PRODUCT INSTALLATION ................... 5 ........................5 ONITOR ETTING ......................6 ARDWARE NSTALLATION IP A ........................10 SSIGNMENT : ....................13 NSTALL CTIVE CONTROL IV. LIVE VIDEO ......................... 20 IP CAMERA CONFIGURATION .................. 24 ............................

  • Page 4: Preface

    I. Preface This is a 1/2.7” 2 Megapixel CMOS sensor Outdoor IP camera with a built-in web server. The user can view real-time video via IE browser. It supports H.264, and M-JPEG video compression which provides smooth and high video quality. The video can be stored in the Micro SD card and playback remotely.

  • Page 5: Product Installation

    III. Product Installation A. Monitor Setting Right-Click on the desktop. Select “ Properties” Change color quality to highest (32bit). 5/67...

  • Page 6: Hardware Installation

    B. Hardware Installation 6/67...
  • Page 7 1. Connector Instruction The Cable and connectors are as below. Connect power adaptor first, then connect the IP Camera to PC or network, and set up the network configurations according to the network environment. About I/O setting, please refer to chapter VII in User Manual: "I/O Configuration"...
  • Page 8 2. 3-Axis Bracket Use the 3-Axis bracket to adjust the camera to appropriate angle, then turn and tighten the screw to fix it. 3. PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is recommended Power over Ethernet (PoE) is a technology that integrates power into a 8/67...
  • Page 9 standard LAN infrastructure. It enables power to be provided to a network device, such as an IP phone or a network camera, using the same cable as that used for network connection. It eliminates the need for power outlets at the camera locations and enables easier application of uninterruptible power supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

  • Page 10: Ip Assignment

    C. IP Assignment Use the software, “IP Installer” to assign the IP address of IP CAMERA. The software is in the attached software CD. IP installer supports two languages IPInstallerCht.exe：Chinese version IPInstallerEng.exe：English version iii. There are 3 kinds of IP configuration. Fixed IP (Public IP or Virtual IP) DHCP (Dynamic IP) Dial-up (PPPoE)
  • Page 11 vii. IP Installer will search all IP Cameras connected on LAN. The user can click “Search Device” to search again. viii. Click one of the IP Camera listed on the left side. The network configuration of this IP camera will show on the right side. You may change the “name”...
  • Page 12 Different Subnets: IP CAM IP address: 192.168.2.200 PC IP address: 192.168.1.100 To Change PC IP address: Control PanelNetwork ConnectionsLocal Area Connection PropertiesInternet Protocol (TCP/IP) Properties Please make sure your IP Camera and PC have the same Subnet. If not, please change IP Camera subnet or PC IP subnet accordingly. A quick way to access remote monitoring is to left-click the mouse twice on a selected IP Camera listed on “Device list”...

  • Page 13: Install Active Xcontrol

    Then, please key in the default “user name: admin” and “password: admin”. D. Install ActiveX control: 1. To users of IE 6.0 above: For the first time to view the camera video via IE, it will ask you to install the ActiveX component.
  • Page 14 1. If the installation failed, please check the security setting for the IE browser. IE  Tools  Internet Options…  Security Tab  Custom Level…  Security Settings  Download unsigned ActiveX controls Select “Enable” or Prompt. IE  Tools  Internet Options…  Security Tab  Custom Level… Initialize and script ActiveX controls not marked as safe ...
  • Page 15 When popup the following dialogue box, click “Yes”. 2. You can choose another way: Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the IP address and click "OK". In the site list you can key one single IP address or a LAN address. For example, if you add "192.168.21.*", all the IP address under .21 LAN will be regarded as trusted sites.
  • Page 16 2. Use Non-IE Web Browser If you use Firefox or Google chrome to access the IP camera but fail to watch the live video, please follow the steps to install necessary tools: (The following pictures are based on chrome.) a. You may see the prompt message as the picture below. First, click the link: "Firstly, please install Microsoft Visual C++ 2010 Redistributable Package (x86)."...
  • Page 17 The link conducts you to the Microsoft official site where you can download the tools. Please select the language and click "download". (ii) In the pop-up window, please tick the first and the third file as the picture below. Click "Next" to download both "Microsoft .NET Framework 4 Client Profile (Web Installer)"...
  • Page 18 (iii) After finishing downloading, execute the two files respectively to install them. The windows may ask you to reboot the PC when the installation is finished. b. Then, click the second link "Please click here to download the installation program which does not support IE browser." to download Setup ActiveX. After finishing the downloading, execute the files to install ActiveX.
  • Page 19 c. If you execute the steps above but still cannot see the live video normally, please try the solution: (i) Search for the file "np_hoem_x.dll" in your system disk. For Windows XP users, please go to "Start" → "Search" → Search for "All files and folders" and key-in "np_hoem_x.dll".

  • Page 20: Live Video

    (iii) Start your web browser, and repeat the step 2-b: "Download the installation program which does not support IE browser" to download and install ActiveX. IV. Live Video Start an IE browser, type the IP address of the IP camera in the address field. It will show the following dialogue box.
  • Page 21 When the IP Camera is connected successfully, it shows the following program interface. 21/67...
  • Page 22 Double-click the video to switch to full screen view. Press “Esc” or double-click the video again back to normal mode. 1. Get into administration page 2. Video Snapshot 3. Zoom-in / Zoom-out 4. Reduce / Increase focus 5. Auto focus 6.
  • Page 23 Right-Click the mouse on the video, it will show a pop-up menu. Snapshot：Save a JPEG picture Record Start: Record video in the local PC. It will ask you where to save the video. To stop recording, right-click the mouse again. Select “Record Stop”. The video format is AVI.

  • Page 24: Ip Camera Configuration

    V. IP Camera Configuration Click to get into the administration page. Click to go back to the live video page. 24/67...

  • Page 25: System

    A.System i、 System Information Server Information: Set up the camera name, select language, and set up the camera time. Server Name: This is the Camera name. This name will be shown on the IP Installer. Select language: English, Traditional Chinese, and Simplified Chinese can be selected.
  • Page 26 Server time setting: Select options to set up time - “NTP”, “Synchronize with PC’s time”, “Manual”, “The date and time remain the same”. ii、 User Management 26/67...
  • Page 27 The IP Camera supports three different users, administrator, general user, and anonymous user. a. Anonymous User Login: Select “Yes” for allowing everybody to watch live video without username and password. However, if you try to enter the configuration page the camera will ask you to key-in username and password. Select "No"...
  • Page 28 Type the user name and password, then click “Add/Set”. The guest user can only browse live video page and is not allowed to enter the configuration page. d. Click “edit” or “delete” in the user list to modify them. The system will ask you to key-in the password in the pop-up window before you edit the user information.
  • Page 29 Reboot system: re-start the IP camera Factory default: delete all the settings in this IP camera. Setting Management: The user may download the current settings to PC, or upgrade from previous saved settings. Settings download: Right-click the mouse button on Setting Download  Select “Save AS…”...

  • Page 30: Network

    B. Network i、 IP Settings The IP Camera supports DHCP and static IP. DHCP: The IP Camera will get all the network parameters automatically. Static IP: Type-in the IP address subnet mask, gateway, and DNS manually. Port Assignment: The user may need to assign different port to avoid conflicts when setting up the IP.
  • Page 31 transmitting port (Default: 80) HTTPs Port: setup the https port(Default: 443) UPnP This IP camera supports UPnP, if this service is enabled on your computer, the camera will automatically be detected and a new icon will be added to “My Network Places.” UPnP Port Forwarding ：...
  • Page 32 RTSP setting RTSP Server: enable or disable RTSP Port: setup port for RTSP transmitting (Default: 554) RTP Start and End Port: in RTSP mode, you may use TCP and UDP for connecting. TCP connection uses RTSP Port (554). UDP connection uses RTP Start and End Port. ii、...
  • Page 33 Created Request: remove the security identification in Created request mode. There is a warning message shown. Please set “Yes” to remove the security identification. Setting the security identification and apply it. Installed Certificate: remove Certificate in. Installed Certificate mode. There will show another warning message. There are two ways to set: Install Signed Certificate and Create Self-Signed Certificate.
  • Page 34 SNMP(Simple Network Management Protocol): Enable SNMPv1 or SNMPv2 and write the name of both Write Community and Read Community. Enable SNMPv3. Set Security Name, Authentication Type, Authentication Password, Encryption Type, Encryption Password of Write mode and Read mode. Enable SNMPv1/SNMPv2 Trap for detecting the Trap server. Please set what event needs to be detected.
  • Page 35 QoS/DSCP(Quality of Server/Differentiated Services Code-point): DSCP specifies a simple mechanism for classifying and managing network traffic and provide QoS on IP networks. DSCP is a 6-bit in the IP header for packet classification purpose. Please define it for Live Stream, Event / Alarm and Management. IEEE 802.1x: 35/67...
  • Page 36 IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to a device on a LAN or WLAN. The EAPOL protocol support service identification and optional point to point encryption over the local LAN segment. Please check what version of the authenticator and authentication server is supported.
  • Page 37 PPPoE: Select “Enabled” to use PPPoE. Key-in Username and password for ADSL connection. Send mail after dialed: When connect to the internet, it will send a mail to a specific mail account. For mail setting, please refer to “Mail and FTP” settings. DDNS: It supports DDNS (Dynamic DNS) service.
  • Page 38 (1) Enable this service (2) Key-in the DynDNS server name, user name, and password. (3) Set up the IP Schedule update refreshing rate. (4) Click “Apply” (5) If the schedule update is too frequently, the IP may be blocked. In general, schedule update every day (1440 minutes) is recommended 38/67...
  • Page 39 iv, Server settings There are three choices of server types available: Email, FTP and SAMBA. Select the item for display detailed configuration options. You can configure either one or all of them. To send out the video via mail of FTP, please set up the configuration first.
  • Page 40 Samba Select this option to send the media files via a neighbor network when an event is triggered 40/67...

  • Page 41: A/V Setting

    C. A/V Setting 1. Image Setting For security and privacy purposes, there are three areas that can be set up for privacy. Click the Area button first, then drag an area on the above image. Remember to save your settings. The masked area will not shown on both live view and recording image.
  • Page 42 c. Shutter Time: Choose the location of your camera or a fixed shutter time. The shorter the shutter time is the less light the camera receives and the image becomes darker , it can adjust by Day and Night. The available values are: Outdoor, Indoor, 1/30, 1/50, 1/60, 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/10,000.
  • Page 43 3D denoise analyzes successive pictures to detect the noise places while. 2D denoise analyzes only single picture. 2. Video Setting User may select the camera system type Streaming 1 Setting: Basic mode and Advanced mode Streaming 2 Setting: Basic mode, Advanced mode, and 3GPP mode (Max Video Frame Rate for both streaming combined is 30 FPS) Streaming 1 Basic Mode: Resolution:...
  • Page 44 There are 5 levels: Best/ High/ Standard/ Medium/ Low The higher the quality is, the bigger the file size is. Not good for internet transmission. Video Frame Rate: The video refreshing rate per second. Video Format: H.264, JPEG RTSP Path: RTSP output name Streaming 1 Advanced Mode: Resolution: There are 5 resolutions that can be chosen:...
  • Page 45 CBR: 32Kbps~8Mbps (the higher the CBR is, the better the video quality is) VBR: 1(Low) ~10(High) – Compression rate, the higher the compression rate, the lower the picture quality is; vise versa. The balance between VBR and network bandwidth will affect picture quality.
  • Page 46 Best/ High/ Standard/ Medium/ Low The higher the quality is, the bigger the file size is. Not good for internet transmission. Video Frame Rate: The video refreshing rate per second. Video Format: H.264, JPEG RTSP Path: RTSP output connecting route Streaming 2 Advanced Mode: Resolution: There are 4 resolutions can be chosen.
  • Page 47 Video Frame Rate: The video refreshing rate per second. Video Format: H.264 or JPEG RTSP Path: RTSP output connecting path 3GPP Streaming mode: The RTSP here is separated from the RTSP settings in the "IP SETTINGs". 3GPP Streaming can still work even if you select "disabled" in the RTSP server option of IP Setting.
  • Page 48 Audio from local PC to IP Camera: Check “chatting” in the browsing page. The Audio will not be smooth when the SD card is recording. 48/67...

  • Page 49: Event List

    D.Event List 1. Event Setting a. Motion Detection To enable motion detection, tick Area 1/2/3. Click Area 1/2/3 in Area Setting, and draw an area on the preview screen. When motion is detected in the area, the word Motion! will be displayed on the live screen. The camera will send video or snapshot to specific mail addresses, trigger the output device, or save video to FTP/ Micro SD card/ Samba.
  • Page 50 • Based on the schedule: When the option box is ticked, only during the selected schedule time the motion detection is enabled. b. Tampering Detection When the camera view is covered, moved, hit by strong light, or out of focus, the tampering detection will be triggered, and send snapshot or video to mail/FTP/Samba/SD card, or trigger the external alarm.
  • Page 51 Before Tampering Detection Tampering Triggered (Glare) Before Tampering Detection Tampering Triggered (Camera Moved) • Interval: The tampering detecting interval. Take the diagram below as example. The interval is set for 30 second; the camera lens is covered during 10 - 40 sec. At time point B, the camera compares the view with time point A, and sends an alarm when it founds that the lens is covered.
  • Page 52 c. Record File When an event occurs, the IP camera will record a video clip or take snapshot, and then send to mail/ FTP/ Samba. Select the file format to be saved. • AVI File (with Record Time Setting): Save AVI video file. The video length is according to the value set in Record Time Setting.
  • Page 53 d. Record Time Setting When an event occurs, the IP camera can record a video clip or take a snapshot, and then send it via mail/ FTP/ Samba. Select the video recording length before and after the event is detected. 53/67...
  • Page 54 e. Network Dis-connected: The IP Camera will scan the network. The image will be record to the SD card after the IP Camera detects network dis-connected, if set Save to SD card. f. Network IP check: After enabling IP Check, the IP camera can check if the network server is connecting.
  • Page 55 2. Schedule a. Schedule: After complete the schedule setup, the camera data will be recorded according to the schedule setup. b. Snapshot: After enable the snapshot function; the user can select the storage position of the snapshot file, the interval time of the snapshot and the reserved file name of the snapshot.
  • Page 56 I/O Setting a. Input Setting: The IP Cam supports input and output. When the input condition is triggered, it can trigger the relay; send the video to mail addresses /FTP server / SAMBA. • Interval: For example, if you select "10 sec" here, once the motion is detected and action is triggered, it cannot be triggered again within 10 seconds.
  • Page 57 b. Output Setting: The output mode affects the DO or relay out duration. (i) ON/Off Switch: The camera triggers the external device and lasts for 10 seconds. You can turn off the alarm manually by clicking “off” at the right bottom of the live video page. (ii) Time Switch: The camera triggers the external device and lasts for certain time according to the internal setting, and the user is not allowed to break off the alarm manually.
  • Page 58 Micro SD card a. Playback Please Insert t h e Micro SD card before use it. Make sure t o push the Micro SD card into the slot completely. Click the date listed on this page, and it shows the list of the video. The video format is AVI.
  • Page 59 Note ： The use of the SD card will s l i g h t l y affect the operation of the IP Camera, such as affecting the frame rate of the video. c. Copy to PC You can insert the Micro SD card to the PC and read the files directly, or use FlashGet instead to download the files from the IP camera.
  • Page 60 (ii) Open FlashGet, select "File" → "Import" → "Import list", and find the link list file you just saved. The file name may be called “SD_list”. (iii) FlashGet will show you the link list, and you can tick the files you want to copy to your PC.

  • Page 61: Network Configuration

    VI. Network Configuration i、 Configuration 1: Internet Access: ADSL or Cable Modem IP address: One real IP or one dynamic IP Only the IP CAMERA is connected to the internet For fixed real IP, set up the IP into IP CAMERA. For dynamic IP, start PPPoE.
  • Page 62 iii、 Configuration 3: Internet Access: ADSL or Cable Modem IP address: one real IP or one dynamic IP IP CAMERA and PC connect to the internet Device needed: IP sharing Use virtual IP, set up port forwarding in IP sharing. 62/67...
  • Page 63 VII. I/O Configuration I/O Connection a. Please connect the GND & DO pin to the external relay (buzzer) device. b. Please connect the GND & DI pin to the external trigger device. c. I/O PIN definition • GND (Ground): Initial state is LOW •...
  • Page 64 2. I/O Setup a. Click I/O Setting from the system setup page via IE, and check “Out1” to enable I/O signal. b. Output Test After the external input and output hardware is installed, you can use the "Relay Out" bottom on the live video page to test if DO / Relay Out works.
  • Page 65 (ii) Time Switch mode: Click "Pulse", the camera will trigger the external output device for several seconds; the duration length is according to the "interval" setting in Output Setting. 65/67...

  • Page 66: Factory Default

    VIII. Factory Default If you forget your password, please follow the steps to revert back to default value. • Remove the power and Ethernet cable. • Take an electronic wire, plug one side of the wire into "Default" and the other side into "GND"...

  • Page 67: Micro Sd Card Compatibility

    IX Micro SD Card Compatibility The following are the recommended Micro SD Card: Transcend SDHC class4 16GB SDHC class4 32GB class4 16GB class4 32GB SDHC class6 SDHC class6 SDHC class6 16GB class6 class6 class6 16GB SanDisk SDHC class4 SDHC class4 SDHC class4 16GB...
