User’s Manual CONTENTS: Chapter I Introduction to outline and interface-- ----------------------------------------3 1.1 Introduction to FMPD40N2---------------------------------------------------------------------------------------3 1.2 Introduction to FMPD42N2---------------------------------------------------------------------------------------3 1.3 Introduction to FMPD46N2 --------------------------------------------------------------------------------------3 1.4 Introduction to interface-------------------------------------------------------------------------------------------4 Chapter II Connecting ---------------------------------------------------------------------------------5 2.1Control Ting LCD Wall s through RS232-----------------------------------------------------------------------5 2.2 DVI Signal ------------------------------------------------------------------------------------------------------------5 2.3 Video signal ----------------------------------------------------------------------------------------------------------5... -
Page 3: Chapter I Introduction To Outline And Interface
User’s Manual Chapter I Introduction to outline and interface 1.1 Introduction to FMPD40N2: 1.2 Introduction to FMPD42N2: 1.3 Introduction to M20S1: Front: Left: Back: Right: 1.3 Introduction to FMPD46N2:... -
Page 4: Introduction To Interface
User’s Manual Introduction to Interface: A． AC IN: Connect with power cord. H、 OSD interface RS232 INPUT / RS232 OUTPUT BNC/RGB/HV IN: (R, G, B, H, V) input connectors for video signals from computer BNC/RGB/HV OUT: (R, G, B, H, V) output connectors for video signals from computer BNC/YPbPr IN: input connectors for component signals... -
Page 5: Chapter Ii Connecting
User’s Manual Chapter II Connecting 2.1 RS232 Control: Ting LCD Wall s can be controlled by computer through RS232 cable. There are two RS232 connectors on the Ting LCD Wall . (One for signals input, the other for signals output). Every Ting LCD Wall needs a separate ID number to realize management through RS232. -
Page 6: Rgb/Hv Signal
User’s Manual YPbPr and Video1 signal 1. Connect signal source Video1 signal or HD signal and Ting LCD Wall through BNC cable. 2. Use YPbPr OUT or Video1 OUT connector to send signals to a second Ting LCD Wall . 3. -
Page 7: Chapter Iii Remote Control And Signal Input
User’s Manual Chapter III Remote Control and Signal Input 3.1 Introduction to Remote Control: Power: Press this button to turn On / Off monitor Navigation Buttons: Press these buttons to select preference and MENU for confirmation. GOTO: Select signal input 3.2 Instruction to signals input: Press GOTO button to enter signals input list and use navigation buttons to make a choice. -
Page 8: Menu Introduction
User’s Manual 3.3 Menu Introduction: ■ PICTURE： Press “Menu” button, then the following screen shows up. Use navigation buttons to adjust parameters. 1） CONTRAST: Use navigation buttons to adjust values of contrast. 2） BRIGHTNESS: Use navigation buttons to adjust values of brightness. 3）... - Page 9 User’s Manual ■ ADVANCE 1） CLOCKER：Real time set 2） ON TIME： Time to turn on the unit 3） OFF TIME：Time to turn off the unit 4） SLEEP TIME：ON/OFF sleep time (when ON TIME and OFF TIME are not activated) 5） TOTAL X (Number of horizontal screens): Setting the number of landscape displays. Adjust the number of “X”...
- Page 10 User’s Manual ■ OSD: 1) OSD LANGUAGE: CHINESE or ENGLISH. 2) OSD H-POSITION/ OSD V-POSITION: set the horizontal/vertical position of the menu 3) OSD DURATION: 5SEC, 10SEC, 15SEC, 30SEC, 45SEC, 60SEC. 4) MEMORY RECALL: Return to default setting. 5) LEFT EDGE: 0-30 UP EDGE: 0-30...
- Page 11 User’s Manual Chapter Ⅳ Software operation introduction The operation illustrated above is done by OSD control. If COM port management is necessary, please use the software provided by our company. Note: please make application for exclusive register code to our company before using this software. Instructions: 1.
- Page 12 User’s Manual Pic.3 2. If the COM cable is connected, and the light in the top right corner is Green, which means a COM port is open. If the light is Red, please click “Open port” below the light. Note: the default port is COM1, if a new port is preferred, please click “CLOSE PORT” first, then choose the new port and click “OPEN PORT”.
