XtendLan XL-DSPL7-5 User Manual

Ultra-slim 7 inch digital signage
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
XL-DSPL7-5
User Manual

FCC Notices

It's herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is
subject to the following two conditions:
*
This device may not cause harmful interference.
*
This device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
residential installation. This equipment generated uses and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio of television reception, which can be determined by turning the
equipment off or on, the user is encouraged to try to correct the interference by one or more
of the following measures:
*
Reorient or relocate the receiving antenna.
*
Increase the separation between the equipment and receiver.
*
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
*
Consult the dealer or an experienced radio TV technician for help.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XL-DSPL7-5 and is the answer not in the manual?

Questions and answers

Related Manuals for XtendLan XL-DSPL7-5

Summary of Contents for XtendLan XL-DSPL7-5

  • Page 1: Fcc Notices

    FCC Notices It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is XL-DSPL7-5 subject to the following two conditions: This device may not cause harmful interference. User Manual This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    7. Setting Up……………………………………………………….. 2. INTRODUCTION 7.1 Preferences…….…………………..….……………………. 7.2 Photo Setup…………….…………………………………… FJ Display is pleased to introduce the ultra-slim 7 inch digital signage, XL-DSPL7-5. 7.3 Firmware Setup…………………………………………….. The XL-DSPL7-5 feature USB Auto-Copy function, Timer function, Programmed Play and One 8. Using the XL-DSPL7-5...…………………..…………………...

  • Page 3: Hardware Overview

    4.1 Timer’s Battery Installation 4. HARDWARE OVERVIEW Step1. Remove the battery cover screw, and then slide off the battery cover. Step2. Insert the battery (CR1220 3V) with correct polarity (+/-), and then close the battery cover, and fasten it with the screw.

  • Page 4: Remote Control

    * Status 1: If the “Auto Start (ALL, Photo + Music, One File Repeat or Programmed Play)” Move the cursor function is enabled and there are media files on the memory card, the XL-DSPL7-5 will auto Confirm the selection/ entry play media files after power on.

  • Page 5: Setting Up

    ” button on remote control to select the “Setup” item, Photo + Music: Play the pictures with music. and then press the “ENTER” button. You will be presented with the XL-DSPL7-5 settings One File Repeat: Repeat only the selected file.

  • Page 6: Photo Setup

    7.2 PHOTO SETUP 8. USING THE XL-DSPL7-5 □ Slideshow Mode: Enable/ disable the slideshow function. 8.1 TOUCH SCREEN FUNCTION The touch screen function supports up to 29 kinds of templates. 8.1.1 Touch Panel Setup Window Press the EDIT button twice to open the Touch Panel Setup Window.
  • Page 7 Template 1 Template 2 Step3: Copy all the files (include 1 default file and 6 media files) to the CF card, and insert to XL-DSPL7-5. 8.1.3 Play Media Files on Touch Screen Step1: Confirm the Programmed Play function is enabled.

  • Page 8: Usb Auto-Copy Function

    Step2: Put the files that you want to copy and the file “AUTOCOPY.ini” to the USB pen driver. NOTE: 1. If the file “AUTOCOPY.ini” is not on Pen Driver, the XL-DSPL7-5 will not execute the Auto-Copy function. 2. Please confirm there are no “Folder”, “Hidden File” and “System File” on the USB pen driver and CF card.

  • Page 9: Programmed Play Function

    NOTE: Use the ▲ or ▼ button to select the “Clear” item, and press the “ENTER” button to clear the Programmed Play list (all the play lists will be deleted). Step3: Restart the XL-DSPL7-5 after setting, and the XL-DSPL7-5 will execute the One File Repeat function.

  • Page 10: Troubleshooting

    9. TROUBLESHOOTING Situation Check Point Check power cable and power switches. No Picture Make sure the file format on the memory card is correct. Ensure that the battery (CR2025 3v lithium battery) in the remote No Response From control and it is inserted the correctly. the Remote Control Check for any barrier between the remote control and the product.
