MACHINE DESCRIPTION
HOW TO OPEN THE MACHINE DOOR
A ) Pull down the coffee outlets
completely.
B) Turn the key and open the
machine door.
Q U I C K S T A R T G U I D E
Armonia
C O F F E E M A C H I N E S
LEGEND
1. PRODUCT CANISTER
2. PRODUCT CANISTER / COFFEE HOPPER
3. COFFEE HOPPER
4. CARD READER
5. DECAFFEINATED DOOR
6. DOSE BUTTON
7. SERVICE KEYPAD
8. DISPLAY
9. INFO BUTTON
10. SHIFT BUTTON
11. RUBBER PROTECTION
12. DOOR LOCK
13. STEAM WAND
14. ADJUSTABLE DELIVERY OUTLETS
15. DRIP TRAY
16. GROUNDS BIN
Advertisement
Summary of Contents for IMC Armonia
-
Page 1: Machine Description
Q U I C K S T A R T G U I D E Armonia C O F F E E M A C H I N E S MACHINE DESCRIPTION LEGEND 1. PRODUCT CANISTER 2. PRODUCT CANISTER / COFFEE HOPPER 3. - Page 2 STARTING UP DISPENSING After checking that the machine door is closed and the ground bin and the drip tray are inserted, power on the machine by means of the main switch underneath the machine basement (Fig.A). Push the service keypad door to open it ( Fig.B) and press the (ON/OFF) key to switch ON the machine ( Fig.C). (FOR SELF CONFIGURATION , press the ( ON/OFF ) key COFFEE/CAPPUCCINO/CHOCO Where “XXXXXXXX”...
- Page 3 AUTOMATIC CLEANING OF COFFEE GROUP- MIXER AND MILK FROTHER At the end of each working day , and/or in case the machine will not be used some time, we strongly recommend to carry out automatic cleaning of the coffee group ,the mixer and the milk frother.
- Page 4 MANUAL CLEANING OF MIXER MILK FROTHER ADJUSTMENT WE STRONGLY RECOMMEND CLEANING THE MIXERS ONCE A DAY Open the machine door Remove the pipe from the mixer Turn the fl ange anticlockwise Remove the mixer Foam setting Milk temperature setting to remove the mixer The milk frother is equipped with The milk frother is equipped a FOAM REGULATOR which sets...
-
Page 5: Access The Main Setting Menus With Password Or Smart-Card
The Manufacturer reserves the right to modify the equipment presented in this publication without notice. · · · · · IMC S.p.A. Via Industriale, 1 24040 Chignolo d’Isola (BG) Italy Tel. +39 035 905440 Fax +39 035 905447 www.carimali.com www.macco.it...
