syscomtec SCT-IPKVM-CX User Manual

Ip control box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
distributed by
User Manual
SCT-IPKVM-CX
IP Control Box
Version: V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCT-IPKVM-CX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for syscomtec SCT-IPKVM-CX

  • Page 1 User Manual SCT-IPKVM-CX IP Control Box Version: V1.0.0...

  • Page 2: Important Safety Instructions

    distributed by Important Safety Instructions Note In case of any content change, we are sorry for no further notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.

  • Page 3: Table Of Contents

    distributed by Table of Contents Introduction ....................4 Overview ....................4 Features ....................5 Package Contents ..................5 Specifications .................... 6 Panel ......................8 Hardware Installation ................... 10 Access the Device ..................11 Web ......................11 Telnet ...................... 12 Web Configuration ..................14 Home Screen ..................
  • Page 4 distributed by API Command Sets ..................32 Configure Set Parameter ................ 32 Set IP Address ................. 32 Set IP Address 2 ................32 Set Password for Web ..............33 Reset IP Control Box ............... 33 Shutdown IP Control Box ..............34 Reboot IP Control Box ..............
  • Page 5 distributed by Remove Video Wall Configuration ........... 49 Configure Video Wall ............... 49 Create a Video Wall Layout ............. 50 Change the Source of a Certain RX ..........50 Change the Source of All RX ............51 Set the Size of TV Frame ..............51 Set the Image Shift ................

  • Page 6: Introduction

    Introduction Overview SCT-IPKVM-CX is an Audio/Video control device to manage TX/RX detected on the local area network. It can automatically search and display TX/RX, perform operations on TX/RX, such as switching between multiple input sources, setting Video wall. This device can be controlled by web browser, a...

  • Page 7: Features

    distributed by Features Ÿ Provides built-in web server and Telnet API (used in a third-party controller) Ÿ Detect TX/RX automatically Ÿ Supports matrix switching between TX and RX Ÿ Supports Video Wall Ÿ Standards and protocols: HTTP, TCP/IP, Multicast Package Contents Ÿ...

  • Page 8: Specifications

    distributed by Specifications Technical 1 x RJ45 Port I/O Connections 1 x RS232 Power LED, Work LED Button 1 x Reset Button Power Supply 5V/2A DC, 5.5mm 1.4Watts Power Consumption Web; Telnet; Control Method A Third-party Control System. RS232 Cables System Requirements Industry Standard CAT5e/6/7 Cables SCT-IPKVM-TX131,...
  • Page 9 distributed by Device: 141mmW×115mmD×26mmH /5.6’’W×4.5’’D×1’’H Dimension Gift box: 390mmW×220mmD×92mmH /15.4’’W×8.7’’D×3.6’’H Weight 0.42kg (without accessories) Certification CE, FCC, RoHS...

  • Page 10: Panel

    distributed by Panel Front Panel Name Description Power This LED glows steady red when the device is powered on. WORK This LED glows steady blue when the device is working properly. If red, that means the device is rebooting. RESET When the device is powered on, press and hold this button...
  • Page 11 distributed by Name Description for 5 seconds, it automatically restores to factory default settings. Label Write down the IP address of the device on the label comes with the device, then insert the label into the device. Rear Panel Name Description ETHERNET RJ45 Port...

  • Page 12: Hardware Installation

    Hardware Installation Connect PC, SCT-IPKVM-CX, and TX/RX to a Switch via CAT5e/6 cables. Connect HDMI Source (such as Apple TV, Xbox or PS3) to TX. Connect HDMI Sink (such as a plasma TV) to RX. Power on all the devices.

  • Page 13: Access The Device

    distributed by Access the Device Users can access the device through Web, Telnet or a Third-party controller. To access the device through Web Management Page, follow these steps. Step 1. Enter 192.168.11.243 into a browser. We recommend you use, Firefox, Opera, Safari, Internet Explorer 11 or Chrome. Step 2.

  • Page 14: Telnet

    distributed by Telnet To access the device through Telnet, follow these steps (here take Window 7 as an example). Step 1. Click Start menu, go to Run. Input cmd, click OK. Step 2. Input telnet 192.168.11.243, press Enter.
  • Page 15 distributed by Then you can see this window comes up. Note: ž The IP address of the computer and IP Control Box should be in the same network subnet. For example, if the IP address of IP Control Box is 192.168.11.243, then the computer should be 192.168.11.X. ž...

  • Page 16: Web Configuration

    distributed by Web Configuration The Web Management Page is designed to perform the functions to control the device in a user-friendly interface. Home Screen Open your browser, enter 192.168.11.243 in the address bar, and input the password (admin by default), click Login. The home screen comes up.

  • Page 17: Matrix

    distributed by Matrix Click Load Matrix button, a table comes up. The first row shows TX, the first column shows RX. Icon Description The device is online. The device is offline. The green bar represents correspondence TX and RX are linked.

  • Page 18: Tx/Rx Settings

    distributed by TX/RX Settings Click TX/RX Settings tab, TX/RX Settings page comes up. Select a device you want to configure. IP Setup GUI Element Description Auto IP Obtain the IP address automatically. DHCP The IP address is assigned by a DHCP server. Static The IP address is manually configured.

  • Page 19: Alias

    distributed by Alias GUI Element Description Alias Give the TX/RX a different name which would be easier to remember. Note: Alias cannot contain ',' ';' '_' '@', '*', '&', 'EX131', 'EX363', 'EX373', 'EX383', 'EX393', 'TX', 'EX141', 'EX403', 'RX'. Commands GUI Element Description Factory Default Restore the TX/RX to factory default settings.

  • Page 20: System Settings

    distributed by System Settings Click System Settings tab, System Settings page comes up. In this page, you can configure the IP Control Box. IP Setup (TX and RX communication) GUI Element Description IP Address The IP address for TX and RX communication. Subnet Mask The subnet mask for TX and RX communication.

  • Page 21: Ip Setup (Telnet /Browser Communication)

    distributed by IP Setup (Telnet /browser communication) GUI Element Description IP Address The IP address for Telnet client and web. Subnet Mask The subnet mask for Telnet client and web. Default Gateway The default gateway for Telnet client and web. Web Password GUI Element Description...

  • Page 22: Commands

    distributed by Commands GUI Element Description Factory Default Restore the IP Control Box to factory default settings. Reboot Reboot the IP Control Box. Shutdown Shutdown the IP Control Box.

  • Page 23: Faq

    distributed by 1. Why I cannot login the Web Management Page? Check the IP address of your computer. The default IP address of the IP Control Box is 192.168.11.243, so the IP address of the computer should be 192.168.11. X. Check the Web browser.
  • Page 24 distributed by configuration effective are decided by your Third-party software. Any Third-party party software could recall a specific configuration, based on this API protocol and repeat corresponding add commands. 6. How to add a 2*2 video wall? A: Before you use video wall, you can assign an alias name to it. just like this: if you have 4 tx and 4 rx, config set device alias EX131-AAAAAAAAAAAA tx1...
  • Page 25 distributed by 7. How to use command "vw bezelgap vw-name ow oh vw vh"? A: This command is incorrect. The correct one is "vw bezelgap vw-name vw ow vh oh". If your TV vw is 90.01 cm, ow is 91.01 cm, vh is 40.52 cm and oh is 42.52 First need change...

  • Page 26: Access The Device

    distributed by Access the Device Users can send API command through Web or Telnet. Step 1. Enter 192.168.11.243 into a browser. We recommend you use, Firefox, Opera, Safari, Internet Explorer 11 or Chrome. Step 2. Enter a password (admin by default), click Login to access the device.

  • Page 27: Telnet

    distributed by Step 3. The home screen comes up. You can enter the API command in Telnet API Command box. Telnet To access the device through Telnet, follow these steps (here take Window 7 as an example). Step 1. Click Start menu, go to Run. Input cmd, click OK.
  • Page 28 distributed by Step 2. Input telnet 192.168.11.243, press Enter. Then you can see this window comes up.
  • Page 29 distributed by Note: ž The IP address of the computer and IP Control Box should be in the same network subnet. For example, if the IP address of IP Control Box is 192.168.11.243, then the computer should be 192.168.11.X. Step 3. You can enter the API command. Note: The telnet client is disabled by default on window 7.

  • Page 30: Api Command Table

    distributed by API Command Table config set Command Description config set ip4addr xx.xx.xx.xx netmask Change the IP address which is used for xx.xx.xx.xx gateway xx.xx.xx.xx communicating with TX and RX. config set ip4addr2 xx.xx.xx.xx netmask Change the IP address which is used for xx.xx.xx.xx gateway xx.xx.xx.xx Telnet/Web.
  • Page 31 distributed by Supported by N373 only. Turn on the display which is connected config device onetouchplay to hostname device. The display must hostname1 hostname2 ... support CEC control. This command is supported by N373 only. config get Command Description config get version Obtain API version and system version.
  • Page 32 distributed by Videowall Command Description Create a video wall configuration, and vw add vw-name n m tx assign a TX. vw rm vw-name Remove video wall configuration. Configure the video wall vw-name, add vw add vw-name tx1 position1 rx2 the correspondence of RX and Displays, position2 can set up many RX and their displays correspondence by once.
  • Page 33 distributed by Scene Command Description scene get Displays all current scenes scene active scene name Active a certain scene. scene set scenename posX posY tx1… Change the source of a certain rx. Serial Command Description serial param –r {on|off} Pass through the serial command. Use “command-string”...

  • Page 34: Api Command Sets

    distributed by API Command Sets Configure Set Parameter Set IP Address Syntax config set ip4addr xx.xx.xx.xx netmask xx.xx.xx.xx gateway xx.xx.xx.xx ip setting will change to: ipaddr xx.xx.xx.xx netmask xx.xx.xx.xx Response gateway xx.xx.xx.xx Change the IP address which is used for communicating with TX and Note RX.

  • Page 35: Set Password For Web

    distributed by Example: Command: config set ip4addr 192.168.11.1 netmask 255.255.0.0 gateway 192.168.11.243 Response: Ip2 setting will change to: ipaddr 192.168.11.1 netmask 255.255.0.0 gateway 192.168.11.243 Set Password for Web Syntax config set webloginpasswd xxxxxx Response password for web modified Note Change the login password of web. Example: Command: config set webloginpasswd 123456...

  • Page 36: Shutdown Ip Control Box

    distributed by Shutdown IP Control Box Syntax config set shutdown Response system will shutdown now Note Shutdown the IP Control Box. Example: Command: config set shutdown Response: System will shutdown now Reboot IP Control Box Syntax config set reboot Response system will reboot now Note Reboot the IP Control Box.

  • Page 37: Set Alias

    distributed by Response: debuglog will switch on Set Alias Syntax config set device alias hostname xxxx Response hostname’s alias is xxxx Set the Alias of the TX/RX. Note Alias can’t use following delimiter like ‘,’ ‘、’ ‘@’ ‘*’ ‘&’ ‘_’ ‘ ’(space) Example: Command: config set device alias EX383-341B22FFFFB3 MYDVD...

  • Page 38: Set Ip Address Mode

    distributed by EX373-ABCDEFGHIJKL Set IP Address Mode config set device ip hostname1 {autoip|dhcp|static} ip4addr Syntax netmask gateway, hostname2 ... Devices’ ipsetting will change to: EX363-mac1 autoip Response EX373-mac2 static ip4addr netmask gateway mytv dhcp Set the IP address mode. If it’s a static IP, then followed by IP address/netmask/gateway.

  • Page 39: Reboot Device

    distributed by Reboot Device Syntax config set device reboot hostname1 hostname2 ... the following device will reboot now: hostname1 Response hostname2 Note Reboot TX/RX. Example: Command: config set device reboot EX383-341B22FFFFB3 EX383-341B22FFFFB4 Response: the following device will reboot now: EX383-341B22FFFFB3 EX383-341B22FFFFB4 Reset Device Syntax...

  • Page 40: Set Device Info

    distributed by EX383-341B22FFFFB3 EX383-341B22FFFFB4 Set Device Info config set device info key1=value1 key2=value2 key3=value3 Syntax key4=value4 hostname1 hostname2 ... config set device info key1=value1 key2=value2 key3=value3 Response key4=value4 hostname1 hostname2 ... Note Set the volume and gain of the device. Example: Command: config set device info mic_volume=20 audio.mic1.gain=12...

  • Page 41: Set Device Onetouchplay

    distributed by Response: config set device standby EX373-AABBCCDDEEFF Set the display which is connected to EX373-AABBCCDDEEFF to standby mode. Set Device Onetouchplay Syntax config set device onetouchplay hostname1 hostname2 ... Response config set device onetouchplay hostname1 hostname2 ... Turn on the display which is connected to hostname device (The Note display must support CEC control).

  • Page 42: Get Device List

    distributed by Command: config get version Response: API version: v1.2 System version: v3.0.2 (v1.5.4) Get Device List Syntax config get devicelist Response devicelist is hostname1 hostname2 ... Note Obtain device list. Example: Command: config get devicelist Response: devicelist is EX363-341B228000BC EX373-341B22800490 Get IP Setting Syntax config get ipsetting...

  • Page 43: Get Ip Setting 2

    distributed by Get IP Setting 2 Syntax config get ipsetting2 Response ipsetting2 xx.xx.xx.xx netmask xx.xx.xx.xx gateway xx.xx.xx.xx Obtain the IP information which is used for Telnet/Web. The default Note IP is 192.168.11.243. Example: Command: config get ipsetting2 Response: Ipsetting2 is : ipaddr 192.168.11.243 netmask 255.255.0.0 gateway 192.168.11.1 Get Alias Syntax config get name {alias | hostname}...
  • Page 44 distributed by Ip4addr xx.xx.xx.xx netmask xx.xx.xx.xx mac xx.xx.xx.xx.xx.xx gateway xx.xx.xx.xx sink xxxx sink devices connected Obtain TX/RX information with hostname. Note The feedback information varies with different devices. Example: Command: config get device EX383-341B22FFFFB3 Response: EX383-341B22FFFFB3 information is: Ipmode autoip Ip4addr 169.254.11.110 netmask 255.255.0.0 mac 34:1b:22:ff:ff:d1...

  • Page 45: Get Device Json Info

    distributed by Get Device Json Info Syntax config get device info hostname1 hostname2…. devices json info: devices: name:"MX143-341B22FFFF11", ip_mode:"autoip", ip4addr:"169.254.7.174", netmask:"255.255.0.0", mac:"34:1b:22:ff:ff:11", gateway:"169.254.0.254", mic_volume:60, mic_mute:false, Response audio: name:"mic1", gain:0, phantom:true, name:"mic2", gain:0, phantom:true, name:"mic3",...
  • Page 46 distributed by gain:0, phantom:true, name:"mic4", gain:0, phantom:true, name:"mic5", gain:0, phantom:true, name:"mic6", gain:0, phantom:true, name:"lineout1", volume:60, mute:false, name:"lineout2", volume:60, mute:false, hdcp:false,...
  • Page 47 distributed by sourcein:"hdmi1", enc_rc_mode:"vbr", profile:"hp", cbr_avg_bitrate:10000, vbr_max_bitrate:2000, vbr_min_qp:0, vbr_max_qp:51, fixqp_iqp:25, fixqp_pqp:25, enc_gop:60, enc_fps:60, transport_type:"raw" Obtain device information. The feedback information varies with Note different devices. For detail information about the parameter description, please refer to Device json info description Example: Command: config get device info EX383-341B22FFFFB3 Response:...
  • Page 48 distributed by ip4addr:"169.254.22.245", netmask:"255.255.0.0", mac:"34:1b:22:ff:ff:b3", gateway:"169.254.0.254", hdcp:false, sourcein:"341B22FFFFC2;341B22FFFFC3;341B22FFFFC9", audio: name:"lineout1", mute:false...

  • Page 49: Matrix Parameter

    distributed by Matrix Parameter Set Matrix Syntax matrix set TX1 RX1 RX2,TX2 RX3 RX4,... Response matrix set: TX1 RX1 RX2,TX2 RX3 RX4,... Represent one or Multiple TX was displayed by one or Multiple RX. Note Each TX and its connected RX compose a record, and separated by a commas.

  • Page 50: Video-Wall

    distributed by TX2 RX4 Obtain matrix information. Based on current TX/RX in the network, Note re-construct the network topology and feedback to the third-party controller. Example: Command: matrix get Response: matrix information: MS501-341B22FFFFC2 EX373L-341B22800316 MS501-341B22FFFFC2 EX373-341B22800309 MS501-341B22FFFFC2 EX373-341B22800319 MS501-341B22FFFFC2 EX373-341B2280031A Video-Wall Create Video Wall Configuration Syntax...

  • Page 51: Remove Video Wall Configuration

    distributed by Remove Video Wall Configuration Syntax vw rm vw-name Response videowall item vw-name removed Note Remove video wall configuration. Example: Command: vw rm vw1 Response: videowall item vw1 removed Configure Video Wall Syntax vw add vw-name tx1 position1 rx2 position2 videowall item vw-name configuration added: rx1 posion1 Response...

  • Page 52: Create A Video Wall Layout

    distributed by tx1” first. (From left to right, it is 1, 2, 3, 4 …) Create a Video Wall Layout vw add vw-name layout n m TX RX11 RX12 RX13 RX1m RX21 ... Syntax RXnm Response videowall vw-name layout n*m tx rx11 rx12 rx13 rx1m rx21 ... rxnm Add a video wall layout n*m, subsequently the RX based on display Note order.

  • Page 53: Change The Source Of All Rx

    distributed by vw change rx4 tx2 Response: videowall config clear: rx4 and connect to tx2 Change the Source of All RX Syntax vw change vw-name tx hostname Response videowall vw-name tx connect to txhostname Note Set all rx display tx. Example: Command: vw change vw1 tx2...

  • Page 54: Set The Image Shift

    distributed by Set the Image Shift vw pictureparam vw-name h-shift v-shift h-scale v-scale Syntax teraring-delay rx1 rx2 rx3 ... set videowall vw-name’s pictureparam: xx xx xx xx xx to rx1 rx2 Response rx3 ... configure the rx1/rx2/rx3 ... image shift (Unit: 8 pixels, a negative number indicates to move left or up) / scale (Horizontal scale units: Note 1/Columns ;...

  • Page 55: Multiple View

    distributed by row-number1 RX11 RX12… Obtain video wall information. Based on current TX/RX in the Note network, re-construct the network topology and feedback to the third-party controller. Example: Command: vw get Response: Video wall information: 11-12_fanzhuan MS501-341B22FFFFC2 Row 1: EX373-341B22FFFFD1 EX373-341B22800309 Row 2: EX373-341B2280031A EX373-341B22800319 11-11_liuxijun MS500-341B22FFFFC9 Row 1: EX373-341B2280031A EX373-341B22800319...

  • Page 56: Set Multiple View

    distributed by mv get Response: mv information: EX383-341B22FFFFB3 tx1 tx2 MS501-341B22FFFFC9 MS501-341B22FFFFC2 Set Multiple View Syntax mv set rx tx1 tx2 txn Response rx1 tx1 tx2 tx3… One tx to multiple tx, supports 1, 4, 9, 16 displays, the numbers of Note display is up to the tx number.

  • Page 57: Active A Scene

    distributed by scene get Response: scene list: Office-meeting room Office-training room Active a Scene Syntax scene active scenename Response scene scenename active success Note Active a certain scene. Example: Command: scene active Office-meeting room Response: scene Office-meeting room active success Change the Source of a Certain RX Syntax scene set scenename posX posY tx1…...

  • Page 58: Serial

    distributed by Serial Pass through the serial command. serial -b param –r {on|off} “command-string” hostname1 Syntax hostname2 ... serial command received: Response serial -b param –r {on|off} “command-string” hostname1 hostname2 ... Configure devices hostname1, hostname2 to pass through serial command. After receiving the command-string, TX/RX pass through the command directly to peripherals through RS232 port.

  • Page 59: Device Json Info Description

    distributed by Device Json Info Description Property Name Description Usage name Device true name read-only like AA:BB:CC:DD:EE read-only ip_mode autoip/static/hdcp ip_mode=static ip4addr like 192.168.11.243 ip4addr=192.168.11.1 netmask like 255.255.0.0 netmask=255.255.0.0 gateway like 192.168.11.1 gateway=192.168.11.1 hdcp true/false hdcp=true The following parameters are supported by MX143 and MS500 only. Property Name Description Usage...
  • Page 60 distributed by audio.volume [0,100] step 10 audio.lineout1.volume= audio.mute true/false audio.lineout1.mute=fal EX373, EX383, EX373L support change lineout1 mute or not enc_rc_mode cbr/vbr/fixqp enc_rc_mode=cbr sourcein vga1/vga2/cvbs1/cvbs2/hdmi1/hdm sourcein=hdmi1 i2/hdmi3/hdmi4 The following parameters are supported by MX143,MX153,MS500,MS501 and EX363 Property Name Description Usage profile bp/mp/hp profile=bp bp: base profile...
  • Page 61 distributed by vbr_max_qp [0,51] vbr_max_qp=50 fixqp_iqp [0,51] fixqp_iqp=10 fixqp_pqp [0,51] fixqp_pqp=20 enc_gop [1,65535] enc_gop=50 enc_fps [1,60] enc_fps=30 transport_type raw/ts transport_type=ts...

  • Page 62: Product Service

    distributed by Product Service Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Provided Service 1. Damage Requiring service: The unit should be serviced by qualified service personnel if: Ø...

  • Page 63: Warranty

    distributed by If repair is needed during the limited warranty period the purchaser will be required to furnish a sales receipt/proof of purchase indicating date of purchase, amount paid and place of purchase. Customer will be charged for the repair of any unit received without such proof of purchase. Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for...
  • Page 64 distributed by Service, or damage that is attributable to acts of God. 2. There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty.

  • Page 65: Glossary

    distributed by Glossary Acronym Complete Term Application Programming Interface DHCP Dynamic Host Configuration Protocol Digital Television HDMI High Definition Multimedia Interface Receiver Transmitter Video Wall...
  • Page 66 Distribution AG Addresse: Raiffeisenallee 8 82041 Oberhaching / Germany Tel: +49 (0)89 666 109 330 Fax: +49 (0)89 666 109 339 post@syscomtec.com www.syscomtec.com...
