Meitav-tec Ltd (Contel group)
Tel: +972-3-9626462 Fax: +972-3-9626620
www.meitavtec.com - support@meitavtec.com
ETN-Z100
Owner's Manual – Installation and Operating Instructions
Please read this manual carefully before installation and use.

1. Installation Instructions

ETN-Z100-Zone-Rev1-letter.doc
Rev. 1
15/03/07
Separate the front panel from back panel by depressing the
tongue located in the top of the unit.
Pull the back panel out.
Line the back panel up against the wall or flat surface. Install
three screws as required.
Make electrical connections as shown on enclosed electrical
wiring connections table.
Install the cover to the back panel; first the two tabs on the
bottom and then the top tongue. Push until tight against the
wall.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETN-Z100 and is the answer not in the manual?

Questions and answers

Summary of Contents for meitav-tec ETN-Z100

  • Page 1 Meitav-tec Ltd (Contel group) Tel: +972-3-9626462 Fax: +972-3-9626620 www.meitavtec.com - support@meitavtec.com ETN-Z100 Owner’s Manual – Installation and Operating Instructions Please read this manual carefully before installation and use. 1. Installation Instructions Separate the front panel from back panel by depressing the tongue located in the top of the unit.
  • Page 2: Operating Manual

    2. Operating Manual 2.1 On/Off • Press the On/Off button to turn the zone ON or OFF – “ON” or “OFF” will appear on display. On/Off On/Off 2.2 Temperature set-points • Press the “+” or “-“ buttons – “Cool” and the set-point temperature for cooling will flash. •...
  • Page 3 2.4 Economy mode • Press and hold the On/Off button (10 sec.) to turn the economy mode ON – “EC” will appear on display. In economy mode the thermostat will work according to preset set-point temperatures (see technician settings) • Press and hold the On/Off button again (10 sec.) to turn the economy mode OFF –...
