Summary of Contents for Newskill HANSHI
- Page 1 KAILH RED mechanical key switches technology...
- Page 2 FEATURES GOLD PLATED CONNECTOR ERGONOMIC WRIST REST BRAIDED FIBER CABLE N-KEY ROLLOVER, FULL ANTI-GHOSTING ALUMINUM DESIGN GAMING BACKLIGHT...
- Page 3 INTRODUCTION Indicator Lights(Num Lock / Caps Lock / Scroll Lock) Profile Keys, FN+F1~F12 Volume Up/Down Mute Key Mechanical Switches KAILH RED Actuation Point 2.0mm±0.6mm Full Travel 4.0mm Actuation vs Reset 0.2mm Life Span Up to 55 million Actuation Force Palm Rest...
- Page 4 SPECIFICATION Technical Features Physical characteristics KAILH RED SPECIFICATION - All key support without conflict, FN + F8 key switch Mechanical Performance 1- Rating: 12 VAC/DC max. 2 VDC min. N key not compatible with MAC and other systems. Operating force of standard buttons: 45g. 10mA AC/DC max.
- Page 5 KEYBOARD HOT KEYS QUICK GUIDE Roller to scroll up to FN+F1= Macro1 FN+W=“W,A,S,D ”Into the direction key switch key the volume increase “W” = “A” = “S” = “D” = FN+F2= Macro2 FN+Windows(left) = Windows Locking and release button Mute FN+F3= Macro3 6 Key and N key version switch : Default 6 Key FN+F4= Macro4...
- Page 6 Keyboard Hotkeys 1. The multimedia and programmable profile functions are available pressing ‘Fn’ Key. 2. Illumination brightness control: Recycleable 4 level for LED illumination: Levels 1: 25% lighting Levels 2: 50% lighting Levels 3: 75% lighting Levels 4: 100% lighting When 100% lighting, press Fn + F9, the brightness comes to 25% again.
- Page 7 Keyboard Hotkeys 4. WASD can be changed as Direction Arrow function by pressing : Fn + W Press Fn + W again, WASD comes back to normal letters function. 5. 6-NKRO(Default mode)/Full-NKRO switching by pressing : The default mode is 6K mode (USB standard mode); If the end user needs to switch to NK mode, press Fn + F10, all the keycap-illumination (if any) will be lighted off temporary;...
- Page 8 Keyboard Hotkeys 6. Keycaps Lock function (ie, keycaps are locked, no function) by pressing : When the keycaps are fully lighted up, we press Fn + F11 to enter keycap-lock mode, the F11 key will be lighted off; When the keycaps are fully lighted off, we press Fn + F11 to enter keycap-lock mode, the F11 key will be lighted on; Press again, the keycaps are un-locked, with function.
- Page 9 Keyboard Hotkeys 8. Macro record This keyboard can supply 5 Macro records function by Fn + F1(or F2/F3/F4/F5). The process reads as follows: Step One: Press Fn + F6 to enter Macro-record mode; Then the 3 LED indictors (Numlock/capslock/scroll-lock) will keep flashing . Step Two：...
- Page 10 Keyboard Hotkeys 9. Picture Record This keyboard can totally supply 6 pictures (keycap backlited shape) , The default Picture (already recorded when production) is : all keycaps are lighted up; We can make the other 5 Pictures record by the following steps: Before picture record, we need to make sure all keycaps are backlited (by pressing Fn + F12 to switch into the mode of All keycaps illumination on) .
- Page 11 www.newskillgaming.com...
