Summary of Contents for Lab 12 DAC1
- Page 1 Owner’s Manual DAC1 Special Edition Handcrafted Digital to Analog Converter www.lab12.gr v1.2...
-
Page 2: Table Of Contents
LAB12 DAC1 Handcrafted Digital to Analog Converter Table of Contents It is yours Unpacking and Warnings Features Installation & Placement Front Panel Indicators Rear Panel Connections For the safety of your equipment Specifications Your DAC id... -
Page 3: It Is Yours
Do not forget that your DAC is totally handcrafted with perfectly matched parts of the finest selections. You have to know that to reach the optimal performance your DAC1 need at least 200 hours of listening. In this time all components go from “burn in”... -
Page 4: Features
Metallic color finish (Lexus white, Etna black, Custom colors) Installation & Placement The LAB12 DAC1 Special Edition should be placed on a solid flat surface. You should avoid placing it near a heat source as this could compromise the DAC’s performance and reliability. You should never place another... -
Page 5: Front Panel Indicators
The center LED (A) indicates that the device is powered on. The LEDs (B and C) indicates that the DAC1 Special Edition has successfully locked onto an input signal. To the left and right of the 3 LEDs you see two retro analog VU meters (D and E). You can accurately monitor the output level of each channel on dB scale. -
Page 6: For The Safety Of Your Equipment
Always use a high quality audio grade USB cable to achieve ideal performance. Before connecting your PC to USB input of DAC1 Special Edition you have to install the Drivers of the device. You will find those on the provided CD-ROM. Follow the instructions and connect your dac when the installation is completed. After the installation and connection you need to select the USB output to your playback devices (maximum 96 Khz/24bit). -
Page 7: Specifications
LAB12 DAC1 Handcrafted Digital to Analog Converter Specifications DAC: 8x TDA1543 Power : 230/240 Vac 50Hz Power consumption: 80 watt max (1A fused) Inputs: 1xSPDIF (Coaxial RCA), 1xUSB2 Frequency response: 20Hz to 20 KHz +0dB/-1dB ... - Page 8 LAB12 DAC1 Handcrafted Digital to Analog Converter Your Special Edition DAC id Coupling Capacitors ________ __________ Jantzen Superior-z Output Tube _________________ ___________ Philips Jan 6922 Max output at 1Khz 0dB ________ ________________ 2.15 Volts Frond Panel Color _______________ ______ Gray Matt...
