- Page 1 GLB0035 GLB0038 GLB0036 GLB0039 GLB0037...
-
Page 2: Table Of Contents
INSTRUCTION MANUAL FOR DISHWASHERS CONTENTS CHAP 1 PREFACE........................2 CHAP 2 INSTALLATION......................2 ........................2 NPACKING ........................2 OSITIONING ....................3 LECTRICAL CONNECTION .....................3 LUMBING CONNECTION ..................4 ONNECTION TO THE DRAIN LINE CHAP 3 RISKS AND IMPORTANT WARNINGS...............4 CHAP 4 USING YOUR APPLIANCE ..................5 .........................5 YMBOLS USED ........................5 TARTING... -
Page 3: Preface
INSTRUCTION MANUAL FOR DISHWASHERS Chap 1 PREFACE Failure to follow the instructions provided in the attached documentation may jeopardize safety of the appliance and immediately cancel the warranty. The warnings contained in this manual provide important information regarding safety during the various installation, operation and maintenance stages. Carefully store all documentation near the appliance;... -
Page 4: Electrical Connection
INSTRUCTION MANUAL FOR DISHWASHERS 2.3 Electrical connection • There must be an omnipolar type of main switch that disconnects all contacts, including the neutral, with a distance of at least 3 mm between the open contacts and with safety circuit breaker tripping or connected with fuses, to be sized or calibrated in conformity with the power indicated on the machine’s data plate. -
Page 5: Connection To The Drain Line
INSTRUCTION MANUAL FOR DISHWASHERS 2.5 Connection to the drain line • The drain line must be made up of a free water trap of a size proportionate to the delivery of the drain pipe supplied with the machine. The pipe must be able to reach the water trap without being pulled, squeezed, bent, crushed, pressed or forced by anything. -
Page 6: Chap 4 Using Your Appliance
INSTRUCTION MANUAL FOR DISHWASHERS Chap 4 USING YOUR APPLIANCE 4.1 Symbols used Push button Push button corresponding to one of the corresponding to one of the symbols shown. The related symbols shown. warning light illuminates. warning light warning light corresponding to one of the corresponding to one of the symbols shown lights up. -
Page 7: Turning Off The Appliance
INSTRUCTION MANUAL FOR DISHWASHERS For versions with rotating basket: • If possible, run the cycle only with the basket full, evenly distributing the dishes. • Place the lightest dishes near the middle of the rack, and the heaviest ones near the outside. •... -
Page 8: Discharging The Appliance
INSTRUCTION MANUAL FOR DISHWASHERS 4.6 Discharging the Appliance 4.6.1 Models without discharging pump 1. Turn off the appliance as described in the “Turning off the Appliance” paragraph, above. 2. Remove the overflow cap: wait until the tank is completely empty. 4.6.2 Models with discharging pump 1. -
Page 9: End Of Service
INSTRUCTION MANUAL FOR DISHWASHERS • Make sure the overflow cap has been removed. • Open the salt dispenser inside the tank. • Pour approx. 250g of regenerating salt (cooking salt with no additives and grains of 1-2 mm in diameter). •... -
Page 10: Weekly Maintenance
INSTRUCTION MANUAL FOR DISHWASHERS • To clean the steel tank, do not use abrasive detergents or objects; instead, use a lightly soaped damp cloth. • Do not use pressurised water jets as these may damage the electrical system. 5.3 Weekly Maintenance •... -
Page 11: Annual Maintenance
INSTRUCTION MANUAL FOR DISHWASHERS 5.4 Annual Maintenance Have your appliance carefully inspected by an authorised technician, and in particular: • Remove residues from the bottom of the tank. • Remove and deep clean wash arms and diffusers. • Thoroughly clean the weir inserted in the lower wash arm shaft and the water exit area. •... -
Page 12: Models With No Detergent Metering Unit
INSTRUCTION MANUAL FOR DISHWASHERS insufficient amount of rinse agent. • To obtain optimum results, use only rinse agents with a manufacturer’s suggested dosage of less than 1.5 gr. /litre. • 7.9 cm of pipe = 1 ml. of product (= 1 gr. of product with a density of 1 kg/dm ). -
Page 13: Chap 7 Deinstallation
INSTRUCTION MANUAL FOR DISHWASHERS Chap 7 DEINSTALLATION Only qualified and authorised technical personnel can perform deinstallation. • Turn off the power to the machine with the external main switch. • Shut off the external water supply tap. • Completely disconnect the machine from the electric and water supply networks. •... -
Page 14: Replacing The Tank Pressure Switch
INSTRUCTION MANUAL FOR DISHWASHERS 9.4 Replacing the Tank Pressure Switch If replacing the pressure switch, or its drum, or in the case of the appliance accidentally tipping over, proceed as follows: 1) The pressure switch is 3) Blow inside the tube to eliminate 2) Remove the tube and, if situated either at the back or condensation.
