Sumatsu KYD-25Xc User Manual

Mobile air conditioner
Hide thumbs

Advertisement

Table of Contents

Foreword
Mobile Air conditioners are pieces of high value. In order to ensure your lawful rights
and interests, please have the professional technicians to do the installation for you.
This Instruction Manual is the universal-purpose version for the models of mobile air
conditioners manufactured by our Co. The appearance of the units that you purchase
might be slightly different from the ones described in the Manual, but it does not
affect your proper operations and usage.
Please read carefully the sections corresponding to the specific model you choose,
and keep the Manual properly so as to facilitate your reference at later time.
Attention:
(1) The appliance is not intended for use by young children or infirm persons
without supervision.
(2) Young children should be supervised to ensure that they do not play with
F
the appliance.
O
(3) The plug shall be accessible after install the appliance.
(4) The appliance shall be installed in accordance with national wiring regulation.
R
(5) The appliance can't be install in laudary.
(7) If the supply cord is damaged,it must be replaced by the manufacturer or
E
its service agent or a similary qualified person in order to avoid a hazard.
w
(8)
impedance no more than 0.322 ohm.In case necessary,please consult your
O
supply authority for system impedance information,
(9)
R
impedance no more than 0.197ohm.In case necessary,please consult your
D
supply authority for system impedance information,
*
C
O
N
T
E
N
T
S
KY(D)-22/Xc series can be connected only to a supply with system
KY(D)-25/Xc series can be connected only to a supply with system
Contents
Instructions
The names of each part and its function
Operation and indication sections of remote controller
Use of control panel
Water drainage methods
Maintenance/service
Reservation methods
Safety cautions
Troubleshooting
Installation
Electric schematic diagrams
1
2
4
5
7
8
10
11
12
13
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KYD-25Xc and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sumatsu KYD-25Xc

  • Page 1 Foreword Mobile Air conditioners are pieces of high value. In order to ensure your lawful rights and interests, please have the professional technicians to do the installation for you. This Instruction Manual is the universal-purpose version for the models of mobile air conditioners manufactured by our Co.

  • Page 2: Instructions

    INTRODUCTION MOBILE AIR CONDITIONER This Mobile Air Conditioner is a small size appliance,which can adjust the temperature and humidity in a room.Its flexibility characteristics make it easily used on different occasions in different rooms.It also has multiple functions, including cooling,dehumidifying and faning ventilation.This unit was designed especially to be used in a family house,office,etc.It has a compact design compared to others with the same cooling capacity.Power consumption is low and the noise especially low.

  • Page 3: The Names Of Each Part And Its Function

    THE NAME OF EACH PART AND ITS FUNCTION FRONT control panel up/down air swinging fins air oulet handle left/right air swinging fins water tank cable (power caster cord and plug) BACK upper air inlet grill hot air outlet grill lower air inlet grill...

  • Page 4: Control Panel Overview And Functions

    THE NAME OF EACH PART AND ITS FUNCTION TIMER Button SWING Button FAN SPEED Button MODE Button Press this button to set the Press this button will select Selection of this button Press this button will time for switch-on,switch- among the modes of cooling, will determine the air choose high,middle or low off or to delete the timing.

  • Page 5: Operation And Indication Sections Of Remote Controller

    OPERATION AND INDICATION SECTIONS OF REMOTE CONTROLLER Display screen ON/OFF Button Temperature setting button Pressing this button will turn the machine This button is used to set the ON or OFF. HEAT room temperature,Each COOL DRY FAN pressing of the" "...

  • Page 6: Use Of Control Panel

    USE OF CONTROL PANEL DEHUMIDIFYING AND COOLING OPERATION The operating ranges for cooling operation is 17 C-31 C(or 63 F-88 F) and the operating range for dehumidifying is 20 C-31 C (or 68 F-88 POWER SOURCE *The AC socket must be firm and reliable. *Don't connect the mobile air conditioner to a multiple socket outlet which is also being used for other electrical appliances.

  • Page 7: Water Drainage Methods

    USE OF CONTROL PANEL TIME SET FUNCTION To set time to start the machine with the unit off (but power supplied), press" " button,the LCD window will show " ", press the TIME button,set the time to start as you like.The setting range is 1-12 hours.
  • Page 8 WATER DRAINAGE METHODS f i g . 2 f i g . 3 CAUTION 1. When in cooling or dehumidifying mode, do not take out the water tank,or the buzzer will sound and the compressor stops,and the mode changes to FAN.

  • Page 9: Maintenance & Service

    MAINTENANCE/SERVICE MAINTENANCE METHODS *Pull the plug out of the socket,before cleaning. *Make sure there is no power to the unit before beginning to maintain or repair,Prevent accident caused by elec. shock. *Do not use chemical solvent ( like benzene,alcohol glazer) to clean the surface of the unit,If you do so, the surface will be scratched,damaged,even the whole casing could become deformed.
  • Page 10 MAINTENANCE/SERVICE SURFACE KEEP CLEAN Clean the surface of the unit with a damp cloth,then dry using a duster or similar. WATER TANK 1. Hold the handle in water tank,and draw out slowly. 2. Pour out the water,clean away any dirt with neutral detergent, wash and dry it carefully and then push the tank back.

  • Page 11: Reservation Methods

    RESERVATION METHODS END OF SEASON OPERATIONS 1. To remove drain water from the drain tank take out, the plug from the plastic pipe shown in Fig. 4. Then operate the unit in fan mode for half a day until the pipe is dry. 2.

  • Page 12: Safety Cautions

    SAFETY CAUTIONS OCCASION * Do not use the unit in a very narrow room with obstacle so as to avoid breakdown. * Do not use the unit where the sunlight is shining directly onto it so as to avoid surface colour changing. * Do not use the unit in water or near water, avoiding leakage of electricity.

  • Page 13: Troubleshooting

    TROUBLESHOOTING Before seeking repair or service,please firstly check the following. Trouble Check Action It is normal. Is power fail? Push the plug into the wall socket. Air conditioner does Is plug out? change the fuse or switch on. not operate at all Is power fuse or switch off? Pour the water out of the water If drain tank indicator is lit?

  • Page 14: Air Exhaust Duct Mounting Method

    INSTALLATION Selection of installation lacation Put the mobile air conditioner in a flat location where the air outlets cannot be covered up,place the unit no less than 50cm away from a wall or other obstacle. 830mm(327 inch) The air exhaust duct mounting method 1) Fix the square end of the exhaust dust to the exhaust terminal of the unit 2) Put the other end(discharge) to the nearest window Attention:The length of the air exhaust between 600mm-1800mm,Use the Min length when working,we...
  • Page 15 INSTALLATION Correct mounting shown below(If mounting in the wall,the heigh of the hole should be 40cm~130cm) fig. 23 (51 inch) (16 inch) If the air exhaust requires bend,shown as below. (20 inch) (24 inch) (20 inch)
  • Page 16 INSTALLATION The wrong mounting diagram ( Air exhaust bend too large, easily cause malfunction). Window Kit Installation Your window kit has been designed to fit most standard "vertical" and "horizontal" window applications.However,it may be necessary for you to improvise/modify some aspects of the installation procedures for certain types of windows.
  • Page 17 INSTALLATION Installation Accessories Fig. 25 Description Fig. 25 Fiexible exhaust hose with adapters...3/set stretces from 19 1/2" (50 cm) up to 78 3/4"(200cm) Window exhaust adapter (flat mouth )..1pc Adjustable window slider kit......2/set from 26 5/8" (67.5 cm) up to 48 3/8"...
