Summary of Contents for Costar Video Systems CRIS12

  • Page 1 Gigabit PoE Switch Operation Manual CRIS12 CRIS28...

  • Page 2: Safety Symbols

    Before reading this manual This operation manual contains basic instruction on installing and using Gigabit PoE Switch. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Fcc Compliance Statement

    FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
  • Page 4 Safety Precautions Do not use the product in an excessively hot (50°C or above), cold (0°C or below), or humid environment. ● Presents a fire hazard. Set up the product in a shaded area providing protection against exposure to direct sunlight and maintain an even ambient temperature.
  • Page 5 Safety Precautions If there is a strange noise or smell coming from the product, unplug the power cable and contact the service center right away. ● Presents fire and electric shock hazards. Failure to comply can lead to minor injury and/or product Caution damage.

  • Page 6: Table Of Contents

    Table of Contents Part 1 - Introduction Product Features Accessories Overview Front Panel Rear Panel Part 2 - Installation Grounding Port Connection NVR Connection DirectIP™ Camera Connection Cascading Port Connection Warnings and Tips Part 3 - Miscellaneous Supported SFP Transceiver Module List Troubleshooting Specifications...

  • Page 7: Part 1 - Introduction

    Part 1 Introduction Product Features This multi-port, and IEEE 802.3af and IEEE 802.3at Power over Ethernet-enabled Gigabit Switch offers the following features: ● NVR Connection – Automatic network IP configuration – Individual port data transmission to NVR (Network Video Recorder) ●...
  • Page 8 Part 1 - Introduction Gigabit PoE Switch Connection Diagram SFP Module SFP Module Types of Cables Optical Cable UTP Cable (Data only) UTP Cable (Data + PoE)

  • Page 9: Accessories

    Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. ● CRIS12/28 ● Power Cable ● Installation Manual ● Rack Mount Brackets: 2EA ● Screws – CRIS12: 8EA – CRIS28: 4EA Overview Front Panel CRIS12 CONSOLE DIAG...
  • Page 10 1 RJ-45 Service Ports These are PoE-enabled RJ-45 ports. Connect a network camera to one of these ports. Model Port Number CRIS12 1 - 8 CRIS28 1 - 24 • PD network cameras will receive power over the signal line, without the use of an external power source.
  • Page 11 RJ-45 uplink ports are used to connect the switch to a higher tier device. These ports are useful when cascading multiple network devices. Model Port Number CRIS12 9 (top) and 10 (bottom) CRIS28 25 (left) and 26 (right) • If not using for uplinking purposes, these ports can be used as service ports, but they do not support PoE.
  • Page 12 These ports are used to connect the switch to higher tier devices that are some distances away via optical cables. These ports are useful when cascading multiple network devices. Model Port Number CRIS12 11 (top) and 12 (bottom) CRIS28 27 (left) and 28 (right) • If not using for uplinking purposes, these ports can be used as service ports.
  • Page 13 6 SFP Uplink Port LEDs These LEDs indicate the status of the SFP uplink ports. 27 28 Model Port LEDs CRIS12 CRIS28 27 28 The LED color indicates connection and communications speeds with the connected device. LED Status Indications Mode...
  • Page 14 Part 1 - Introduction 9 Reset Button The reset button, which is located to the right of the PoE LED button, is used to reset the product's settings. Pressing the reset button immediately reboots the product. If the product does not reboot after pressing the button, press and hold the button for 5 seconds.

  • Page 15: Rear Panel

    Part 1 - Introduction Rear Panel CRIS12 CRIS28 Power Connector Grounding Terminal 1 Power Connector Connect the power cable to this connector. This product does not feature a separate power on/off button and will turn on the moment power is supplied.

  • Page 16: Part 2 - Installation

    Remove the grounding screw located on the back of the product, next to the power switch. CRIS12's grounding terminal is located on the upper left section on the back of the product. Thread the grounding screw through a grounding wire and screw it back in place.

  • Page 17: Port Connection

    Part 2 - Installation Port Connection NVR Connection Via UTP Cable Connect the NVR's VIDEO IN port to the system's RJ-45 uplink port using a UTP cable. Check the RJ-45 uplink port LED's status and verify that a normal connection has been established.

  • Page 18: Directip™ Camera Connection

    Part 2 - Installation DirectIP™ Camera Connection Connect the system's RJ-45 service port to the network camera's RJ-45 port using a UTP cable. Check the RJ-45 service port LED's status and verify that a normal connection has been established. PoE cameras can receive power through the UTP cable.

  • Page 19: Cascading

    Part 2 - Installation Cascading Via UTP Cable Connect the RJ-45 uplink ports of system 1 and system 2 using a UTP cable. Check the RJ-45 uplink port LED's status and verify that a normal connection has been established between the two products. Remote Connection via an Optical Cable Insert SFP modules into the SFP uplink slots of system 1 and system 2 and then connect the modules using a fiber optic cable.

  • Page 20: Port Connection Warnings And Tips

    Part 2 - Installation Port Connection Warnings and Tips • Keep the UTP cable length to less than 100m. • If you need to replace an SFP uplink transceiver module while the system is operating, deactivate the port first and then replace the transceiver module in order to avoid a system malfunction. • This product uses lasers to transmit signals via its SFP uplink ports.

  • Page 21: Part 3 - Miscellaneous

    Part 3 - Miscellaneous Supported SFP Transceiver Module List The system's SFP ports support the following types of SFP modules: Diameter Wavelength Standard Length Mode Connector SFP Module (um) (nm) 50/125 500m Multi Finisar 1000BASE-SX FTLF8519P3BNL 62.5/125 300m Multi Finisar 1000BASE-LX 9/125 1310...

  • Page 22: Troubleshooting

    Part 3 - Miscellaneous Troubleshooting Problem Check Power LED will not turn on. ● Check the power cable. ● Check the power supply status to the outlet the power cable is connected to. The system shuts down shortly after Check power connection components for electric powering on.

  • Page 23: Specifications

    Part 3 - Miscellaneous Specifications Model CRIS12 CRIS28 Embedded MIPS System Memory 128MB SDRAM, 32M Flash Switching Capacity 24Gbps 56Gbps 8 RJ-45 Connectors 24 RJ-45 Connectors Copper Service Port (10/100/1000BASE-T) (10/100/1000BASE-T) Copper Uplink Port 2 RJ-45 Connectors (10/100/1000BASE-T) Optical Uplink Port...
  • Page 24 COSTAR VIDEO SYSTEMS 101 Wrangler, Suite 201 Coppell, Texas 75019 Phone: (469) 635-6800 Fax: (469) 635-6822 Toll-free: (888) 694-7827...
