INTRODUCTION
CAUTION
CDA320
24/192 CD PLAYER & CONVERTER
Thank you for choosing the Stello CDA320 from April Music.
The Stello CDA320 is a truly innovative design embodying a brand new concept in CD
player making that combines the CD transport and D/A converter section in a single chassis.
As a unique entry-level model, the CDA320 stands out amongst a myriad of relatively
affordable CD players. Intended for 2-channel reproduction, the CDA200 will compete
favorably against, and even surpass, the performance of the latest available digital formats.
The Stello CDA320 is designed to operate at the following line voltages; 117,
230(220), 240 volts AC. This proper voltage is selected through internal voltage
selector switches.
The Stello CDA320 is a highly sensitive electronic apparatus. The best performance
results will be achieved when used on a leveled, vibration free shelf system, away
from airborne vibration.
The 'Mains' switch is located on the rear panel. The 'Stand-by' switch can be
operated manually on the front panel and through the red button of the remote
control. During a normal daily operation use only the 'Stand-by' switch leaving the
'Mains' switch in the 'on' position. The amount of current draw in the stand by mode
is very small while the internal circuitry is maintained at an optimal operating
temperature. It is, however, recommended to turn the 'Mains' switch off or unplug
the AC power lead when you plan to leave the house for a prolonged period of time.
Do not open the chassis without prior authorization from the manufacturer or a
certified Stello agent. Unauthorized repair or tempering of any type will void the
manufacturer's warranty.
Page1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDA320 24/192 and is the answer not in the manual?

Questions and answers

Related Manuals for Stello CDA320 24/192

Summary of Contents for Stello CDA320 24/192

  • Page 1 Thank you for choosing the Stello CDA320 from April Music. The Stello CDA320 is a truly innovative design embodying a brand new concept in CD player making that combines the CD transport and D/A converter section in a single chassis.

  • Page 2: Digital Inputs

    24/192 CD PLAYER & CONVERTER True 192 kHz upsampling The Stello CDA320, utilizes a true 24 Bit/192kHz 'upsampler' DAC chip with Full Balanced Output, resulting in a significantly improved resolution, dynamics and soundstage of the musical recordings, even with standard 16 Bit/44.1kHz CDs.

  • Page 3: Digital To Analog Converter

    CDA320 CONNECTION 24/192 CD PLAYER & CONVERTER CD Player Use a pair of XLR (balanced) or RCA (unbalanced) interconnects between the analog output of the CDA320 and the CD input of your preamplifier or integrated amplifier. When using the balanced connection, the Pin 2 must be positive. Make sure this complies with your other audio equipment.

  • Page 4: Operation

    CDA320 OPERATION 24/192 CD PLAYER & CONVERTER CD Player Fig. 2] The Front Panel Fig. 3] The Display Window STANDBY Turn on 'Mains' power switch located on the rear panel. Red LED above the 'STANDBY' switch will begin to glow. Turn on the unit by pressing the 'STANDBY' button once. The LED will change to green and the CDA320 is now ready for use.
  • Page 5 CDA320 OPERATION 24/192 CD PLAYER & CONVERTER CD Player STOP Use this button to stop playing. The complete information of CD will be shown on the display window. PAUSE Use this button to pause. To resume play again, press 'PAUSE'. TRACK Press this button to skip the track forward or backward.
  • Page 6 CDA320 OPERATION 24/192 CD PLAYER & CONVERTER CD Player STOP Use this button to stop playing. The complete information of CD will be shown on the display window. PAUSE Use this button to pause. To resume play again, press 'PLAY'. TRACK Press this button to skip the track forward or backward.

  • Page 7: Remote Control

    CDA320 OPERATION 24/192 CD PLAYER & CONVERTER Remote Control [Fig. 4] The Remote Controller Layout STBY Same as STANDBY switch of the front panel (red button) DISC Open/Close (blue button) STBY SCAN Pressing this button will play the beginning of each track for 10 seconds.
  • Page 8 CDA320 OPERATION 24/192 CD PLAYER & CONVERTER Remote Control TIME Press the 'TIME' key once to show the TOTAL playing time. Press the 'TIME' key again to show total remaining time and the TIME REM will be displayed. Press 'TIME' once more to make go back to the normal display.
  • Page 9 CDA320 OPERATION 24/192 CD PLAYER & CONVERTER Digital/Analog Converter Fig. 5] The Front Panel & Rear Panel You can use the CDA320 as a dedicated D/A converter by using the DIGITAL INPUT. Stop the CD Player when using the CDA320 as a D/A converter for maximum performance.

  • Page 10: Specifications

    CDA320 SPECIFICATIONS 24/192 CD PLAYER & CONVERTER CD PLAYER / DAC SECTION Transport Mechanism Philips VAM1202 Format Audio CD (CD-DA), CD-Recordable (CD-R) Input Data 16 to 24Bits/32 to 96 kHz Automatically Locked Upsampler Bypass, 96 kHz, 192 kHz Selectable 24/192 Delta-Sigma Digital to Analog Converter Dynamic Range 110 dB Type Signal-to-Noise Ratio...

  • Page 11: International Limited Warranty

    Any unauthorized work, modification or service rendered on the player will void the warranty. Warranty Period 2 years Date of Purchase Authorized Stello Dealer Telephone Serial No. Authorized Stello Service Center Page11...
