- Page 1 10" Wet Tile Saw 8 8 1 1 3 3 0 0 2 2 3 3 9 9 with Stand O O w w n n e e r r ’ ’ s s M M a a n n u u a a l l Read and understand all instructions before use.
-
Page 2: Specifications
Specifications • 2.5 HP, 15A, 3,450 RPM motor • No load speed: 2,700 RPM • 10" continuous rim wet diamond blade for tile cutting • Includes submersible water pump with filter, stand with wheels, and water reservoir with drain • 45° mitre block and 90° rip guide Cutting capacities: •... - Page 3 15. Check for damaged parts. Before using any tool, any part that appears damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment and bending of moving parts; any broken parts or mounting fixture; and any other condition that may affect proper operation. Any part that is damaged should be properly repaired or replaced by a qualified technician, do not use the tool if any switch does not turn on and off properly.
- Page 4 Unpacking When unpacking, check to make all parts listed on pages 8 to 10 is included. If any parts are missing or broken, please call your local retailer. Notes: • Table Stand is specifically designed for use with this 10” Tile Saw and is not included. Stand is available for purchase from your local retailer.
- Page 5 Installing water supply To prevent excessive water on the blade, be sure to maintain a continuous flow of water over the blade while cutting. Never cut anything if the water flow is not continuous. Attach the pump as described in step 4 “assembly” position the pump so it will not interfere with the motion of the table while cutting.
- Page 6 Using the parallel guide: If you have to cut a number of tile to the same dimension, using the parallel guide may save you a significant amount of time. Mark the first tile to the correct dimension, allowing space for grout With the motor turned off, place the marked tile on the table against the fence.
- Page 7 Figure 1...
-
Page 8: Parts Diagram
Parts Diagram... -
Page 9: Parts List
Parts List Description Q’ty No Description Q’ty Washer Connecting plate Small shaft Water tank Washer Elastic washer Knob Bolt Screw Rubber insert Connecting plate Aluminum guide Small shaft Plastic insert Position tube Pressing plate Washer Screw Bolt Machine frame Blade guard Screw Bolt Rubber pad...
