Summary of Contents for Jackson Grills JFP-LP
- Page 1 OWNER’S MANUAL for Patio Fire For Portable Gas Camp Fire: Model # JFP-LP Important Notice Please read ALL safety notices on PP.3 & PP.4 before assembling or operating this Patio Fire. Version: Jan14...
- Page 2 TABLE OF CONTENTS: Specifications: Safety Warnings: Warranty Registration: Certification Info: Package Contents Checklist: Assembly & Preparation: Lighting & Shutoff Instructions: Natural Gas Conversion Instructions: Care & Maintenance: Storage 10-11 Parts List: Warranty: SPECIFICATIONS: Input: 46,500 BTU/h (13.6 KW/h) Manifold Pressure: 11 inch W.C.
- Page 3 !SAFETY WARNINGS! IMPORTANT: Please read and understand all warnings and precautions before using your Patio Fire. !WARNING! !DANGER! If you smell gas: Do not store or use gasoline or 1. Shut off gas to the appliance. other Flammable liquids in the 2.
- Page 4 Inspect fuel supply hose for damage before each use. If excessive wear, abrasion, or cracks are present, the hose MUST be replaced with a genuine Jackson Grills replacement part, prior to using this outdoor appliance (Contact your nearest dealer for assistance).
- Page 5 To obtain replacement parts for your Jackson Patio Fire, contact your local dealer. If you have any question, contact us anytime via phone or email as shown below: (Please have your model and serial number at hand) Patio Fire Model: JFP-LP Portable Patio Fire *Serial Number: _________________ *Write your serial number here for future reference.
- Page 6 CERTIFICATION & TESTING: This appliance has been tested by Labtest Certification Inc. (LC), test to ANSIZ271.97-2010 & CSA CAN 1-2.21-M85, Certified for use in Canada and the USA. PACKAGE CHECK LIST: PARTS CHECKLIST TECH TIP Lid and Tee Handle Wind Guard Ring (Stainless) Do not throw away packaging Base Body with burner until you have confirmed that...
- Page 7 STEP 4: Place logs #2 and #3 onto the burner as shown. Press onto pins where required. (fig.3 & 4) Fig. 4 Fig. 3 STEP 5: Place logs #4 and #5 onto the burner as shown. (fig.5 & 6) Fig. 5 Fig.
-
Page 8: Lighting Instructions
LIGHTING INSTRUCTIONS: 1. Inspect the hose and burner for wear or damage. DO NOT LIGHT THE FIRE PIT IF DAMAGE OR WEAR IS FOUND. 2. PROPANE: Attach the regulator assembly to your propane cylinder. NOTE: Make sure your propane cylinder valve is closed. - Page 9 NATURAL GAS CONVERSION: NOTE: Natural Gas Conversion Kits are available from your local Jackson dealer. Please ask for part number; CONNG-JFP Natural Gas Conversion Kit; Patio Fire !WARNING! Tools Required: BEFORE PERFORMING CONVERSION: shut off gas at source and shut off Patio # 2 Phillips screwdriver Fire valve, then disconnect Patio Fire from gas supply hoses or pipes.
- Page 10 Care & Maintenance 1. Should your campfire be left out in the rain, simply light it as usual and burn until the log set and embers have dried out and begin to glow. 2. Scratches and stains on the wind guard can be buffed out using a Scotch-Brite pad. Be sure to buff “with the grain”...
- Page 11 2) Disconnected cylinders must have threaded valve plugs tightly installed and must not be stored in a building, garage or any other enclosed area. 3) Enclosures for LP-gas supply cylinders shall be ventilated by openings at the level of the cylinder valve and at floor level.
-
Page 12: Parts List
Parts List: Part Number Part Description JP-01 Tee Handle Assembly JP-02 JP-03 Wind guard JP-11 Log set JP-04 Embers (2 bags) Not Shown JP-05 LP Burner JP-06 Body JP-07 LP Hose & Regulator Assy. JP-08 LP Orifice Mount Assembly JP-09 Bungee Cord Owner’s Manual JP-01... - Page 13 One (1) Year Warranty: Jackson Grills provides a one (1) year warranty for the Jackson JFP-LP Patio Fire. Under this warranty, Jackson covers all defects in materials and workmanship, for replacement of the affected part, for a period of one year.
