Summary of Contents for Mr. Freeze MIM-18
-
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock, and injury to persons or property. Read all instructions before using any appliance. Do not operate this or any other appliance with a damaged cord. ... - Page 4 IMPORTANT SAFEGUARDS (CONT.) Always attach plug to appliance first, then plug cord into wall outlet. To disconnect, turn all controls to the OFF position, grasp plug body and remove from the electrical outlet. Do not pull by the cord. ...
-
Page 5: Parts Identification
PARTS IDENTIFICATION 1. Silicon Water Drain Stopper - For draining water from the water reservoir. 2. Water Reservoir - holds up to 1.7L of water. 3. Compressor 4. Power Cord 5. Top Lid 6. Viewing Window 7. Back Top Cover 8. -
Page 6: Operating Procedures And Maintenance
PARTS IDENTIFICATION (CONT.) ON/OFF: Press to power unit on or off. ADD WATER: This light will turn on along with a beep indicator when the water level is too low. You will need to add water to the Water Reservoir and press the 'Power' button two times to restart the Ice maker. - Page 7 OPERATING PROCEDURES AND MAINTENANCE (CONT.) This unit should be properly grounded for your safety. The power cord of this appliance is equipped with a three-prong plug which plugs into a standard three prong wall outlet to minimize the possibility of electric shock. Plug your appliance into its own, properly installed, grounded wall outlet.
-
Page 8: Using Your Ice Maker
OPERATING PROCEDURES AND MAINTENANCE (CONT.) The ice maker should be cleaned on a regular basis. (See the “HOW TO CLEAN” section on p.6) It is necessary to have an adequate ventilation space around the ice maker in order to sustain proper performance, dissipation of heat, maintain efficiency, and low power consumption. -
Page 9: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Indicator lights are on but display is not Blown fuse/ No power. Replace fuse/ Turn power on. “Ice Full” indicator is on. Ice basket is full. Remove ice from ice basket. compressor works abnormally with a buzzing The voltage is lower than Stop the ice maker and do not noise... - Page 10 Machine keeps running but the water is warmer than the normal temperature. The magnetic valve is broken. Replace the magnetic valve. Please operate the ice maker below Ambient temperature or water temperature in inner tank is too high. use cold water. Ice making Refrigerant liquid leakage.
- Page 11 Leaking Water: Rubber Drain Stopper may be missing or not inserted properly. If missing, please contact customer service for a replacement rubber insert. Check if unit still leaks water when power is unplugged. If unit does not leak water when power is unplugged then the water is leaking from the water pump.
- Page 12 Model MIM-18 Protection Type Power 120V / 60Hz Rated Current 1.8A Power Consumption 180W Refrigerant R134a/85g Net Weight 23lbs Size 13” H x 9.5” W x 13.5” L...
- Page 13 LIMITED WARRANTY* ONE (1) YEAR WARRANTY IS ONLY VALID WITH A DATED PROOF OF PURCHASE Your small kitchen appliance is built with precision, inspected and tested before leaving our factory. It is warranted, to the original purchaser to be free from any manufacturing defects under normal use and conditions for one (1) year, cord excluded.
- Page 14 RETURN INSTRUCTIONS RETURNS: Any return of defective merchandise to the manufacturer must be processed accordingly by first contacting customer service (contact information shown below) to obtain an RA # (Return Authorization Number). We will not accept any returns of merchandise without an applicable RA #. IMPORTANT RETURN INSTRUCTIONS.
