Summary of Contents for Jaycar Electronics AA2079
- Page 1 TV Hearing Aid Earphones Manual...
- Page 2 Manual Manual A. Functions Contents TV hearing aid function (transmitter + receiver) A. Functions TV hearing aid function Features: 1. Help hearing impaired to listen to TV clearly from far distance, without turning up the volume and disturbing other people. B.
- Page 3 Manual Manual B. Product parts 7 Power adapter 1 Transmitter 2 Receiver 8 Screwdriver 3 Audio cable for transmitter 4 Audio cable 2 9 Manual 10 Earphone x 2 sets Microphone cable 6 Wired headphone cable...
- Page 4 Manual Manual C. Part function D. Product use 1. TV hearing aid function instruction. 1 Transmitter (1) Connect the power adapter to a socket of the power source and the transmitter's power jack. AUDIO IN DC12V OFF ON (2) Connect the audio cable (3.5mm plug) to the transmitter's audio-in socket, connect other plugs to AUDIO OUT socket of TV, DVD, STB, etc, Charging dock if it is computer, you need to connect the plugs with Audio cable 2 (RCA...
- Page 5 Manual Manual Connect to audio out of PC Connect to audio out of DVD b. The infrared window of the transmitter should face the receiver. Audio out Noise will occur when run into the below situations: a. There is some obstacle between the transmitter and the receiver. b.
- Page 6 Manual Manual 3. Wired hearing aid function instruction. (7) Transmitter will standby if there isn't audio signal in 25 seconds. Plug the end of wired headphone cable in LINE IN jack of receiver, When you switch on TV or input signal, the transmitter will start to connect the other end with audio sources like PC, Radio, MP3, etc, switch work.
- Page 7 Manual Manual instruction. 6. Computer chatting function E. Specifications (1)Plug the microphone cable in the micro-in jack of a computer. Transmitter ± Working voltage 12V 0.8V, 400mA Connect one end of wired headphone cable with the ± Working current 95 8mA receiver, and the other end to the earphone jack of the computer, switch on the...
- Page 8 Manual Manual 3.Working environment G. Notes — Working temperature: -10 60 degree, Working humidity: 10% 90% 4. Storage condition Temperature: -30 90 degree, please don't let it be shocked, pressed, and wet. 1. When you don't use the product, please turn off the transmitter and receiver, if don t use it for a long time, please take out the adapter and cables and save them F.
