User Manual and
Installation Instructions
Model: : : : EA120BTSX
Model: : : : EA120BIS
Model: : : : EA90BTSX
Model: : : : EA90BIS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EA120BTSX and is the answer not in the manual?

Questions and answers

Summary of Contents for EURO EA120BTSX

  • Page 1 User Manual and Installation Instructions Model: : : : EA120BTSX Model: : : : EA120BIS Model: : : : EA90BTSX Model: : : : EA90BIS...
  • Page 2 Service & Spare parts Your appliance should be serviced annually by a competent authorised person For serving or spare parts or Natural Gas conversion kit, please contact Eurostyle Group trading as Euro Appliances Service line: (08) 81651012 Fax: (08) 8165 1018...
  • Page 3: Use Outdoors Only

    USE OUTDOORS ONLY This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any outdoor enclosure or alfresco area in which the appliance is used shall comply with one of the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover.
  • Page 4 Do not do * Use spanner to tighten all gas fittings Do not lean over appliance when lighting * Check all gas hose and line connection for Do not store combustible materials, gasoline, damage, cuts or cracks each time for using flammable liquids or vapors within vicinity the appliance.
  • Page 5 Gas Cylinder Information Gas Cylinder Safety Information • This appliance is designed to be used with a gas cylinder not exceeding 9KG. • The gas cylinder supply valve must be turned off when the appliance is not in use. • Gas cylinders must be stored outdoors, out of reach of children and must not be stored in a building, garage or any other enclosed area.
  • Page 6: Lighting Your Barbecue

    LIGHTING YOUR BARBECUE This barbecue is designed for use outdoors, keep away from any flammable materials. It is important that there are no overhead obstructions and that there is a minimum distance of 915mm from the side or rear of the appliance. Do not use the BBQ under overhead combustible materials.
  • Page 7 7. To turn the barbecue ‘OFF’ turn the cylinder valve to the ‘OFF’ position and then turn all of the control knobs on the appliance clockwise to the OFF ( ) position. For Infrared rear burner Push down the control knob and keep pressing whilst turning anti-clockwise to HIGH ( ) position also pressing the ignition button (a clicking sound is...
  • Page 8: Cleaning And Care

    CLEANING AND CARE All cleaning and maintenance should be carried out when the barbecue is cool and with the fuel supply turned OFF at the cylinder. DO NOT mistake brown or black accumulation of grease and smoke for paint. Surfaces of the gas grills &...
  • Page 9: Technical Information

    Technical Information Model No.: EA120BTSX/ EA120BIS/ CB6-SBG001-BU CB6-BG001(B) Test Point Pressure: 2.75KPA 2.75KPA Total Nominal 96.1 MJ/h 81.1 MJ/h Gas Consumption: Gas Type: Propane Propane Main Burners: 11.6 MJ/h x 6 Main Burners: 11.6 MJ/h x 6 Nominal gas consumption: Side Burner: 15MJ/h Back Burner: 11.5MJ/h...
  • Page 10 Exploded View Model No. : EA120BTSX...
  • Page 11 Exploded View Model No. : EA120BIS...
  • Page 12 Exploded View Model No. : EA90BTSX...
  • Page 13 Exploded View Model No. : EA90BIS...
  • Page 14: Assembly Steps

    ASSEMBLY STEPS Tools required: 1. Attach left side table as shown in the diagrams below. . On each side of the BBQ there are 2 preassembled screws; Loosen them to 4mm of thread showing. . Hang the side table onto these loose screws on each side .
  • Page 15 Connect side burner 1) Take out side burner grid 2) Loosen the screws which secure the side burner with Philips head screwdriver and take it out. 3) Assemble the side valve, meanwhile put the knob seat on front panel and tighten the two screws together with knob seat and side valve.
  • Page 16 4) Put back side burner and tighten the screws, meanwhile put the side burner inlet into side valve injector.
  • Page 17 5) Connect the side burner ignitor. 6) Put back side burner grid. Attach left side table as shown in the diagrams below 1) Assemble the table and front panel with 3pcs of M6X10 and M6 2) Attach left side table .
  • Page 18 4. . . . Fit flame diffusers as shown in diagram below. 5. . . . Fit cooking grids and plate as shown below Please DO NOT use two hot plate together.
  • Page 19 6. . . . Fit warming rack as shown below 7. . . . Unscrew cap and place AA Battery into place with the (+) end facing outwards. Screw cap back on. Upon pressing the ignition button, you will hear a clicking noise if it has been installed correctly. AA battery is not provided...
  • Page 20 For Outdoor Built-in BBQ EA120BIS & EA90BIS Assemble the side bracket Fit flame diffusers as shown in diagram below.
  • Page 21 3. Fit cooking grids and plate as shown below Please DO NOT use two hot plate together. 4. Fit warming rack as shown below...
  • Page 22 Barbecue Dimensions for inbuilt models EA120BIS EA90BIS...
  • Page 23 Guide for building-in Warning: Contact your local municipality for any building codes regulating the installation of outdoor barbecue appliances. Outdoor installations must conform to local codes or, in the absence of local codes, with AS5601 - Gas Installations. THE CONSTRUCTION OF THE ENCLOSURE AND INSTALLATION OF THE BBQ SHOULD BE CARRIED OUT ONLY BY AUTHORISED PERSONS.
  • Page 24 Clearances Allow adequate clearance on the right and left side of the BBQ so that the rotisserie motor and skewer (where supplied) can be removed. Ensure there is at least 100mm clearance at the rear so that the hood can be opened without obstruction. Allow a minimum clearance of 10mm from the sides and rear of the BBQ to any non-combustible construction located below the BBQ cooking surface.
  • Page 25 For rotisseries kit The side burner is not allowed to operate during operation of turnspit motors PARTS Description Quantity Rotisseries Motor AC / Motor DC Bolt and Nut Motor Bracket Spit Rod collar 4-Sprong Meat Fork Spit Rod Collar Weight Balance (Counterweight) Handle Washer...
  • Page 26: Care And Maintenance

    ASSEMBLY, INSTALLATION AND OPERATION INSTRUCTIONS. Assembling and Attaching Rotisseries Kit to barbecue 1. Using 2 sets of bolts, nuts and washers provided, attach the bracket to the right side of the grill as shown in Fig 1 by passing two bolts through the bracket and then the outside of your grill.
