Summary of Contents for Maxx Cold MCWC28-O
- Page 1 MCWC28-O INSTRUCTION MANUAL Outdoor Wine Cellar Be sure unit is standing upright 24 hours prior to plug-in. English MCWC28-O MAN 0511 REV A PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Read all instructions before using this appliance. Use this appliance only for its intended purpose as described in this instruction manual. Always exercise basic safety precautions, as described below. After reading the instruction manual, store it in an accessible place where the user(s) of this product can easily find it. The purpose of these safety precautions is to ensure safe and correct use of the product to minimize risks that could cause serious damage and injury to you or others. - Page 3 electrical shock could result. 9. Never climb onto the unit. The unit could tip over or fall and cause material damage or personal injury. 10. Disconnect the power cord plug from the wall outlet before moving the unit and make sure that the power cord is not damaged during transport. A damaged power cord could result in electrical shock and/or fire.
-
Page 4: Table Of Contents
SAVE THESE INSTRUCTIONS! DANGER! Risk of child entrapment! Before discarding your old refrigerator: • take off the doors • leave the shelves in place so that children may not easily climb inside. Table of Contents IMPORTANT SAFEGUARDS ............1 – 3 Technical Specifications .............. -
Page 5: Technical Specifications
Technical Specifications Model Number: MCWC28-O Description: outdoor wine cellar Electrical Input: 115VAC ~ 60Hz Current Rating: 2.0A Unit Dimensions: 14⅝”W x 24⅜”D x 33½”H 370mm x 620mm x 850mm Unit Weight: 79 lbs / 36 kg Ambient Temperature Range: 25ºF - 100ºF / -4℃ - 38℃... -
Page 6: Installation
Direct sunlight may affect the finish, and nearby heat sources will cause higher electrical consumption. The MCWC28-O Outdoor Wine Cellar is designed to be either free-standing or built-in. It has motorized fan at the back of the unit that direct compressor- generated heat away from the compressor and through the front of the unit. -
Page 7: Operating Your Wine Cellar
Failure to do so may result in the unit working improperly. Compartment Design The MCWC28-O Wine Cellar has a capacity of 28 standard wine bottles. The control panel displays the current temperature and allows you to turn the interior lights on and off, and allows you to turn the interior temperature. - Page 8 0 to 6 Fahrenheit degrees. When fully loaded with room temperature product, the MCWC28-O will operate continuously for as long as 24 hours to reduce the temperature inside the cabinet to the desired point.
- Page 9 Memorized Temperature Settings Your unit has been designed to “remember” the last run mode to which it was set. If there is a power outage or any other power cutoff, the unit will automatically return to the previous temperature setting after the power has returned. Compressor Run Indicator When the unit’s compressor is running, the control panel will display a moving icon representing a running fan.
-
Page 10: Cleaning And Maintenance
Cleaning and Maintenance Cleaning the Outside Unplug your Wine Cellar. Clean the outside with a cloth dampened in mild soapy water. Dry thoroughly with a soft cloth. To clean the door gasket, use only mild soapy water. Never use harsh cleansers or scouring pads to clean any part of your unit. - Page 11 Follow steps E through H on the following page to install the new bulb:...
-
Page 13: Troubleshooting
Troubleshooting Unit does not turn on Not plugged in. Fuse blown or circuit breaker tripped. Noise or vibration Check that unit is level. If not, adjust leveling legs. Unit is too warm Check that door is properly closed and sealed. Check temperature setting. -
Page 14: Wiring Diagram
WIRING DIAGRAM...
