Summary of Contents for IMS MPC1005

Page 1: Media Player
Media Player MPC1005 MPC1006 Operation Manual Movie Photo Music...
Page 2: Table Of Contents
Content I. Main Features ....................... 2 1.1.Applications ....................... 2 1.2.Display format ....................2 1.3. Supported Languages .................. 5 II. Remote control ....................5 III.SETUP MENU ...................... 8 IV. Interface port ....................10 V. Operation Manual ................... 12 5.1 Boot auto-play ....................12 5.2 Custom control display ...................
Page 3: Main Features
MPC1005/MPC1006 is a high performance 1080p Full HD media player. OS belongs to the Linux operating system. I. Main Features 1.1 Applications Ideal replacement for Blue Ray and DVD video players. Ideal playback unit for Large LCD and Plasma display.
Page 4 1.2.3 Supported picture format: JPEG, BMP, GIF, PNG, TIFF 1.2.4 Supported subtitles format: SRT, SMI, SUB, SSA, IDX+SUB 1.2.5 Supported video code: MPEG1/2/4, H.264, AVC, VC1, WMV, RM/RMVB, DivX3/4/5/6, Xvid3/4/5/6 1.2.6 Supported video files: RM/RMVB, AVI, TS, M2TS, MTS, MKV, MOV, FLV, DVD-ISO, BD-ISO, VOB, MPG, DAT, ASF, TP, TRP, WMV, IFO, SWF, 3GP, EVO, DIVX, MP4, OGM 1.2.7 Video Format: A.
Page 5 C. Windows media HD (xxx.avi,xxx.wmv) at up to 35 mbps: The player supports windows media HD VC-1 files xxx.avi (AP@L3). The video size is up to 1080p (1920X1080) and average bit rate is 35mbps with peaks at up to 50mbps.For continuous 24/7 loop file only, limit the average bit rate to 25mbps.
Page 6: Supported Languages
1.3 Supported Languages English, Espaňol, Français, Deutsch, Italiano, Dutch. II. Remote control All procedures in this manual can be carried out using the remote control buttons. See the following for details on each button and its function: Name Function Power button: Power Press to POWER on or off the device Title button:...
Page 7 Repeat buttons: Repeat Press REPEAT 1 / ALL to set repeat option - Chapter, Title or Off. Time seek buttons; Time seek Press to jump to a specific point on the disc or title. Specify the point using Title, Chapter and Time. TV Mode button;...
Page 8 Vol + buttons: Vol+ Press to increase the volume. Audio button: Audio Press to select an audio track on a HDD or USB file. Subtitle button: Press to activate available subtitles when play the DIVX file. Subtitle DivX subtitle supported: SRT,SMI,SUB,SSA format file Resume buttons;...
Page 9: Iii.setup Menu
III. SETUP MENU...
Page 11: Iv.interface Port
IV.Interface port 4.1 MPC1005 ports：...
Page 12 4.2 MPC1006 ports：...
Page 13: Operation Manual
V. Operation Manual 5.1 Boot auto-play The media player will auto-play all the files in root directory of USB/SD CARD. But files that stored in the folder can’t be auto-played. The display files can be: video files, picture files, and audio files. Play sequence: video→picture→audio.
Page 14: Pictures Sync Playback（Bgm
5.3 Pictures Sync playback (BGM) For pictures’ playback, you can define a background music folder. Here are two ways. 5.3.1 The first way: Music folder stored in the root directory, it will boot auto-play. In this case, background music will play once playing pictures. First, create a folder named “audio”...
Page 15: Custom Function
A. Picture playing time and transition model from one picture to the next. Set as follows: Add below programme at the beginning of the configuration file “autoplay.txt”: Transition=9 (Setting the transition model from one picture to another, parameter range 1-13) Slide time=5 (Setting the playing time of each picture) B.
Page 16: Other Functions' Operation Manual
5.5 Other functions’ operation manual ( only specific models have these functions) 5.5.1 RS232 control display A. The MPC1005 provides a DB9 female port for communication with control PC and program download. The pins are defined as below: Interface RS232(9 pins)
Page 17 C. Instruction of RS232 commands a. Examples of command format: @00:VOL+$ Represents: Volume up @00:NEXT$ Represents: Next file @01:PREV$ Represents: Previous file (this command can only be accepted by media player that set the address as “01”, all other media players will not act on this command).
Page 18 commands sent out from broadcast address. If it is user address, only defined media player can act on this command. There is only one broadcast address “00”, and addresses range from 01 to 99 is user address. User address can be defined in the “autoplay.txt”.
Page 19 E. Commands List (take broadcast address “00” as example ) Command Description @00:OK$ @00:UP$ Direction key, up @00:REV$ Playback @00:FWD$ Fast forward @00:REP$ Repeat play @00:MUTE$ No sound @00:VOL+$ Volume up @00:VOL-$ Volume down @00:STOP$ Stop @00:PREV$ Previous file @00:NEXT$ Next file @00:ENTER$ Enter...
Page 20 F. Software Download a. Download link: http://www.docklight.de/download en.htm b. Choose “Docklight V2.0” to download the RS232 controling software: c. Click “Docklight V2.0” on PC The windows: Button : Clear Button : Send Button : Edit RS232 commands...
Page 21 Take care of these settings: d. Edit RS232 commands G. RS232 Return Message...
Page 22 a. Auto read the definitions in "autoplay.txt" when power on： volume=15 irmode=1 00[av:off][spdif:off][hdmi:off]=/ 01[hdmi:off][av:off][n]=01/ 02[av:off][spdif:off]=02/ 03[hdmi:off][spdif:off]=03/ 04=04/ 05[av:off]=05/ 06[n][vol:10]=06/ ( Here button 1 and folder 01 is defined "NO INTERRUPT" in configuration file“autoplay.txt”: “01[hdmi:off][av:off][n]=01/”)
Page 23 b. RS232 Return Message Format ① RS232 command format ② Remote control format ③ Push button control format c. Description Here take “RS232 command format” as an example: ① Send RS232 command “@00:01$”, start to play folder 01, the RS232 Return Message is as below: When folder 01 is displaying, send RS232 command “@00:01$”...
Page 24: Button Control Display
H. Note “@0:WHO?”: This is a signal that stand-alone media player ask the synchronization console to confirm if this player is host machine or slave machine. If the player is host machine, it will synchronize other machine. And if it is slave machine, it will wait for the sync signal. You can turn off this finding by sending the string “@00:SLAVE$”.
Page 25 Description: (Define the default volume) volume=20 irmode=1（Button function definition）; 01=01/（“01” before “=” represents button number. “01” behind “=” represents the folder or file path (“/” must be added after folder name) vol_plus=03（Button 3:VOL+）; vol_minus=04（Button 4:VOL-）; NEXT=05 Button 5: play next file PREV=06 Button 6: play previous file C.
Page 26 volume=15 irmode=1 00[av:off][spdif:off][hdmi:off]=/ 01[hdmi:off][av:off][n]=01/ 02[av:off][spdif:off]=02/ 03[hdmi:off][spdif:off]=03/ 04=04/ 05[av:off]=05/ 06[n][vol:10]=06/ Instruction: Here "av" represents "audio output", "spdif" represents "optical and coaxial output","hdmi" represents "HDMI output" , "off" represents no sound output. 1. volume=15(Define the default volume) 2. irmode=1（Button function definition） 3. 06[n][vol:10]=06/ The "[n]"...
Page 27: Motion Sensor Display
A. DISPLAY NEXT FILE---The player auto loop play root directory files when power on, it switches to the next file（files in folder 01） when the IR body sensor detects passer-by. When the file is finished, it switches to root directory files. B. Define configuration file in “autoplay.txt”: a. MPC1005-3 Sensor_mode=Nextfile 01=01/...
Page 28 b. MPC1006-3 Sensor_mode=Nextfile Sensor_file=01/ C. Store the displaying files in root directory as follows: a. Files stored in root will be displayed as homepage; b. Files in folder “01” will be displayed as next files when IR body sensor detects passer-by.
Page 29: Pin Definition Of Button Interface
VI. Pin definition of button interface Pin definition of LED button interface Pin definition of no LED button interface...
Page 30: Setting Of Picture Playback
VII. Setting of picture playback When picture is displaying on the screen, you can set picture playback by pressing button “MENU” on remote control, and then use direction key and button “OK” to carry on.
