USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR BUILT-IN HOT PLATES
Dear Customer
Thank you for purchasing a Blanco Cooktop.
Before we continue telling you about this cooktop, we cordially invite you to become part of the Blanco family by
subscribing to ongoing information and invitations. Please visit our website where you can subscribe and request
such things as invitations to future cooking classes and gourmet recipes. Go to www.meaappliances.com.au and
fill in the subscription details.
You will find that the clean lines and modern look of your Blanco Cooktop blends perfectly with your kitchen décor.
It is easy to use and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen such as ovens, rangehoods, dishwashers,
microwaves, sinks and taps.
There are models to complement your new Blanco Cooktop.
Of course we make every effort to ensure that our products meet all your requirements, and our Customer
Relations department is at your disposal, to answer your questions and to listen to all your suggestions (see back
cover of manual).
Please complete the warranty section of this manual and keep your receipt as proof of purchase. Retain all
documents relating to the purchase of this products.
Blanco is committed to providing increasingly efficient products that are easy to use, respect the environment and
are attractive and reliable.
BLANCO
MODELS: CG904WWXC - CG904WWXFFC
We ask that you carefully read the instructions within this booklet to enable you to abtain quality results from the outset.
The appliance must be installed only by an authorised person in compliance with the instructions provided. The manufacturer
declines all responsability for improper installation which may harm persons and animals and damage property.
The appliance must be used for the purpose for which it was expressly designed. Any other use (eg heating rooms) is considered to
be improper and consequently dangerous. The manufacturer declines all responsability for damage resulting from improper and
irresponsible use.
The manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors. The
designs in the figures are purely indicative.
The manufacturer also reserves the right to make any modifications to the products as may be considered necessary, useful or in the
interests of the user, without jeopardizing the main functional and safety features on the products themselves.
If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of
this booklet.
COD. 04031GGZB - 13.05.2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blanco CG904WWXC
Summary of Contents for Blanco CG904WWXC
- Page 1 If your cooktop requires service, please contact your local customer service centre or your nearest Blanco agent listed at the back of this booklet.
- Page 2 DESCRIPTION OF THE HOT PLATES NATURAL PROPANE 1 Wok burner 13.0 MJ 11.0 MJ 3 Semi rapid gas burner (front and rear) 5.4 MJ 6.0 MJ 4 Cast iron pan support 1F 5 Cast iron pan support 2F 6 Burner n° 1 control knob 8 Burner n°...
- Page 3 1) BURNERS - When the pan comes to the boil, set the knob to the reduced rate position (small flame fig. 1). A diagram is screen-printed above each knob on the front panel. This diagram indicates to which burner - Always place a lid on the pans. the knob in question corresponds.
- Page 4 Notes: Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated by keeping the natural air vents clear (fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig. 4 and fig. 5). Intensive and lengthy use of the appliance may require additional ventilation.
- Page 5 CLEANING IMPORTANT: Always disconnect the appliance from the gas and electricity mains before carrying out any cleaning operation. 2) HOT PLATE Periodically wash the hot plate, the enamelled steel pan support, the enamelled burner caps “C” and the burner heads “T” (see fig. 6) with lukewarm soapy water. Following this, all parts should be thoroughly rinsed and dried.
-
Page 6: Installation
INSTALLATION TECHNICAL INFORMATION 3) INSTALLING THE HOT PLATE INSTALLATION PERSONNEL Check that the appliance is in a good condition after having removed the outer packaging and internal This appliance shall be installed only by authorised wrappings from around the various loose parts. In case of persons and in accordance with the manufacturer's doubt, do not use the appliance and contact qualified installation instructions, local gas fitting regulations,... -
Page 7: Fixing The Cooktop
INSTALLATION 4) FIXING THE COOKTOP - Fix the hob with the proper brackets “S” and fit the prominent part into the porthole “H” on the bottom; The hot plate has a special seal which prevents turn the screw “F” until the bracket “S” stick on the liquid from infiltrating into the cabinet. -
Page 8: Gas Connection
INSTALLATION 5) GAS CONNECTION Natural Gas Natural Gas installations require the connection of a The gas connection is located in the rear and on the gas regulator at the appliance. This regulator is underside of the appliance 118 mm (for 60 cm), supplied with the appliance on purchase. -
Page 9: Electrical Connection
INSTALLATION 6) ELECTRICAL CONNECTION THE APPLIANCE MUST BE EARTHED Ensure that this power point is properly earthed. The appliance is supplied with a 1800 mm long Look at the connection wiring diagrams flexible supply lead. (fig. 13). The point of attachment for this lead is located at the Warning: In order to avoid any hazard, any rear and on the underside of the appliance electrical work performed on this equipment or... - Page 10 ADJUSTMENTS 7) TAPS Always disconnect the appliance from the electricity main before making any adjustments. Our taps are suitable for all the gas, they are male All seals must be replaced by the technician at conical type at one way. the end of any adjustments or regulations.
- Page 11 8. Check for gas leaks. Do not use a naked flame models: to check for gas leaks. 9. Adjust the gas pressure to 1.00 kPa. CG904WWXC 4 Burners 10. Remove the control knob, with a thin shaft blade CG904WWXFFC 4 Burners screwdriver down the centre of each gas valve shaft, screw the by-pass injector anti-clockwise.
- Page 12 7. Fit the Propane Gas test point inlet fitting supplied in the conversion kit. CG904WWXC 4 Burners 8. Connect the gas supply to the inlet fitting. CG904WWXFFC 4 Burners 9. Check for gas leaks. Do not use a naked flame to check for gas leaks.
- Page 13 CONVERSIONS BURNER ARRANGEMENT ON THE HOT PLATE TABLE N O M I N A L INJECTOR NORMAL BURNERS HEAT BY PASS DIAMETER INPUT (MJ/h) PRESSURE (1/100 mm) MAX. DESCRIPTION (kPa) N° 1/100 mm 11.0 2.75 91 zE PROPANE ULTRA RAPID 1.00 160 zE 13.0...
-
Page 14: Components Replacement
SERVICING WARNING: Greasing the taps (see fig. 20 - 21) Servicing should be carried out only by If a tap becomes stiff to operate, it must be authorised personnel. immediately greased in compliance with the following instructions: 10) COMPONENTS REPLACEMENT - Remove the tap. - Page 15 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE HOT PLATE CABLE POWER SUPPLY Gas hot plate H05 RR - F Section 3 X 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
-
Page 16: Technical Assistance And Spare Parts
1300 739 033 Endeavour Appliances Telephone: 07 3137 3633 Facsimile: 07 3137 3663 Website: www.meaappliances.com.au Platinum Appliance Service www.blanco-australia.com.au Telephone: 07 3862 1154 www.dedietrich.com.au Facsimile: 07 3862 1114 Roshad (Gold Coast) * Contact Showrooms to confirm hours of business. Telephone... -
Page 17: Warranty Section
3. Should service be required under this Warranty, the good order and working condition, the purchaser shall be purchaser should contact an approved BLANCO Service liable for a service fee charged by BLANCO/MEA or one Provider during their normal business hours. of its’ Service Providers.
