NOTE: All warranty work must be performed by an authorized dealer using original (manufacturer) replacement parts. NOTE: Bercomac reserves the right to change or improve the design of any part or accessory without assuming any obligation to modify any product previously manufactured.
INTRODUCTION TO THE PURCHASER This new accessory was carefully designed to give years of dependable service. This manual has been provided to assist in the safe operation and servicing of your attachment. NOTE: All photographs and illustrations in the manual may not necessarily depict the actual models or attachment, but are intended for reference only and are based on the latest product information available at the time of publication.
SAFETY PRECAUTIONS Careful operation is your best insurance against an accident. Read this section carefully before operating the vehicle and accessory. This accessory is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. All operators, no matter how experienced they may be, should read this and other manuals related to the vehicle and accessory before operating.
Page 6
SAFETY PRECAUTIONS OPERATION: MAINTENANCE AND STORAGE Do not put hands or feet near, under or inside rotating parts. When cleaning, repairing or inspecting the vehicle and accessory, make certain that all moving parts Exercise extreme caution when operating on or have stopped.
SAFETY DECALS REPLACE IF DECALS ARE DAMAGED SEE PARTS BREAKDOWN FOR DECAL LOCATION DECAL #105133 Failure to observe these instructions could lead to severe injury or death. To avoid injury to hands or fingers: -Always keep hands clear of rope hook loop, ,hook and fairlead opening during installation , operation and when spooling in or out.
ASSEMBLY IMPORTANT: TORQUE ALL BOLTS ACCORDING TO TORQUE SPECIFICATION TABLE WHEN STATED: TIGHTEN FIRMLY. THE WINCH KIT IS TO BE USED ONLY TO LIFT BERCO ACCESSORIES, ANY OTHER USE MAY CAUSE DAMAGE TO THE VEHICLE. This subframe may be used to install different attachments (see attachments page).
Page 9
ASSEMBLY Install the spring (item 1) # Item Description Action Spring Install the spring on the frame as shown. NOTE: The latch must move freely. Install the spring as shown Install the handle support (item 1) on the left side. # Item Description Action...
ASSEMBLY STEP 2: INSTALLATION OF THE WINCH CONTROL SWITCH Install the relay (item 1). Description Action Item Relay Install in an appropriate area. Metal screw Secure relay in place. #12 x 3/4’’ (qty 4) Nylon tie wrap 8’’ See * (qty 4) *If necessary use the nylon tie wraps to secure the Install the relay...
Page 11
ASSEMBLY CONNECTING THE WIRES NOTE: The posts on the relay are identified by numbers. (1-2-3-4). Install the wires from the winch on the posts of the relay. Red wire (+) on post #3. Black wire (-) on post #4. Connect the red wire from the winch (limit switch) with the green wire from the relay.
Page 12
ASSEMBLY CAUTION FOR YOUR SECURITY: Read and follow the safety precautions for the battery in the vehicle’s manual. CONNECT THE WIRES ON THE BATTERY: Connect the wires from the relay to the vehicle’s battery. The red wire (+) on the positive post of the battery (item 1).
ASSEMBLY STEP 3: DRIVE MECHANISM PREPARATION NOTE: You must remove mower deck to install the drive mechanism. NOTE: Pictures are a reference only, they may vary from the actual part. If you have the 700502-1 or the 700503-1 or a higher dash, please follow these instructions.
Page 14
ASSEMBLY Install the belt on the engine pulley of the vehicle. Check the tension on the spring. If necessary, adjust the tension by moving the adjustment rod (item 1) and tighten the set screw (item 2). Belt routing VERIFICATION OF THE BELT AND PULLEY ALIGNMENT: WARNING TO PREVENT INJURIES:...
OPERATION & MAINTENANCE MAINTENANCE CAUTION a) Check mounting bolts at frequent intervals for Read the vehicle Owner’s Manual carefully. Be proper tightness to be sure equipment is in safe thoroughly familiar with the controls & proper working condition. use of the attachment. Know how to stop the b) Apply oil at all pivot points.
TROUBLESHOOTING * Please refer to parts breakdown section for parts identification. PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION Winch runs backwards. Winch wires reversed. Recheck wiring. Switch wires reversed. Recheck wiring. Switch installed incorrectly. Check switch installation. Battery wires reversed. Recheck wiring. Winch cable is not winded up from Wind winch cable from underneath.
TORQUE SPECIFICATION TABLE GENERAL TORQUE SPECIFICATION TABLE USE THE FOLLOWING TORQUES WHEN SPECIAL TORQUES ARE NOT GIVEN NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal oil. They do not apply if special graphited or moly disulphide greases or other extreme pressure lubricants are used. This applies to both UNF and UNC threads.
PARTS BREAKDOWN COMPACT DRIVE MECHANISM 700502-1...
Page 19
PARTS LIST COMPACT DRIVE MECHANISM 700502-1 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Drive frame Châssis d'entraînement 106069 Support Support 106070 Bracket Fixation 106071 Spacer Espaceur 106072 Belt guide Guide-courroie 104095 Adjustment rod Tige d'ajustement 104841 Idler arm Bras de tension...
PARTS BREAKDOWN NORTHEAST DRIVE MECHANISM 700503-1...
Page 21
PARTS LIST NORTHEAST DRIVE MECHANISM 700503-1 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Drive frame Châssis d'entraînement 106069 Support Support 106070 Bracket Fixation 106071 Spacer Espaceur 106072 Belt guide Guide-courroie 104043 Adjustment rod Tige d'ajustement 104841 Idler arm Bras de tension...
PARTS LIST SUBFRAME 700501-2 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Female hitch Attache femelle 104817 Left support Support gauche 105200 Right support Support droit 105201 Latch Loquet 104818 Heat shield Pare-chaleur 104824 Cab support...
Page 24
PARTS LIST SUBFRAME 700501-2 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Breaker Disjoncteur 105219 Winch control switch Commutateur de contrôle du treuil 106090 Reflector (Pack of 2) Réflecteur (Ensemble de 2) 106108 Flat washer 9/16" hole Rondelle plate 9/16"...
PARTS BREAKDOWN WINCH 106125 PARTS LIST WINCH 106125 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Reduction box Boîte de réduction 105237 Planetary gear Engrenage planétaire 105241 Inner gear Engrenage intérieur 105239 Drum support bushing Coussinet du support de tambour 105242 Drum support plate Plaque de support du tambour...
ATTACHMENTS ATTACHMENTS ROTARY TILLER #700312 SOUFFLEUSE 700465 40" Mounts to the rear of lawn, yard & BLADE #700463 700474 44" garden tractors 14 to 25 HP. Comes 700478 48" complete with drive & manual lift Mounts on the same subframe as the Mounts on the same subframe as the mechanisms &...
Page 28
WHEN PERFORMANCE & DEPENDABILITY ARE NON NEGOTIABLE ! Ber comac Limitée 92, For t in Nor t h, Adstock, Quebec, Canada, G0N 1S0 WWW.BERCOMAC.COM PRINTED IN CANADA (ORIGINAL NOTICE)
