Summary of Contents for Fontel RTX KF300WX-VoIP
- Page 1 Bundle Part#: KF300WX-VoIP (1) RTX SIP DECT Base (1) Konftel 300Wx Conference Phone More Information: 800-238-0787 sales@fontel.com Konftel/ RTX SIP DECT Solution Wireless SIP Conference Phone Installation Guide...
- Page 2 The IP address can be set statically under the “Network” menu of the RTX Base Station Administration web interface. While a static LAN IP is not required, it does simplify adding phones in the future. Fontel Inc. 800-238-0787 MAY 2015...
- Page 3 IP PBX vendor or hosted provider. To add an IP PBX to the RTX Base Station: 1. Click on “Servers” from the RTX Main Screen. 2. Click “Add Server” in the “Servers” screen. Fontel Inc. 800-238-0787 MAY 2015 PAGE 3...
- Page 4 5. If G.722 HD Audio is supported by the IP PBX, click “Reset Codecs” under “Codec Priority” and then use the Up/Down buttons to move G.722 to the top of the list. a. Adjust other codec based on the requirements of the IP PBX. Fontel Inc. 800-238-0787 MAY 2015 PAGE 4...
- Page 5 SIP IP PBX Setting to the RTX Base Station” section. Sample “Add extension” Settings 4. Click “Save” to save the IP PBX settings. 5. Repeat this section for any additional phones that will be connected to this RTX Base Station. Fontel Inc. 800-238-0787 MAY 2015 PAGE 5...
- Page 6 6. Once this is complete the “Extensions” page will show a list of all of the phones that were added. a. Note: The IPEI for all phones will be FFFFFFFFFF prior to the phones making a DECT connection. Sample “Extensions” Settings Fontel Inc. 800-238-0787 MAY 2015 PAGE 6...
- Page 7 3. Toggle the cursor to US-NONEXTENDED. 4. Press OK. 5. Press the button to escape back to the main menu. 6. Turn the phone o and then back on by long holding the red onhook button. Fontel Inc. 800-238-0787 MAY 2015 PAGE 7...
- Page 8 9. After a couple of seconds the screen should say “SUCCESS”. a. NOTE: If it says “FAILURE” try the complete pairing procedure again and then call technical support if it does not work the second time. Konftel 300Wx Accepting PIN code and Registering Fontel Inc. 800-238-0787 MAY 2015 PAGE 8...
- Page 9 11. Also in the “Extensions” page con rm that the “State” column shows “Registered” as above which indicated that the SIP registration the IP PBX/Hosted Provider was successful. 12. You should now be able to make calls to and take calls from the Konftel 300Wx. Fontel Inc. 800-238-0787 MAY 2015 PAGE 9...
- Page 10 Base Station web interface to see if the registration failure cab be identi ed. Often a “404 Not Found” or other message will lead to the cause of the issue. If you continue to have issues or questions, please contact Fontel Inc. for assistance. sales@fontel.com or 800-238-0787 Fontel Inc.
