- Page 1 OFA-CCS/CCD Series 1U/2U-Shelf Network Managed Optical Amplifier User’s Manual June 2014 DKT A/S Fanoevej 6 DK-4060 Kirke Saaby +45 4646 2626 +45 4646 2625 E-mail mail@dktcomega.com www.dktcomega.com...
-
Page 2: Table Of Contents
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 Contents INTRODUCTION ................5 About this Manual ........................5 General Descriptions ......................5 Mechanical Dimensions and Operational Conditions ............5 Precautions for Installation and Warnings ................5 Grounding Considerations ..................... 6 Laser Safety .......................... - Page 3 User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.2.10 hePowerSupply ...................... 35 5.2.11 heFans ........................36 5.2.12 Trap......................... 36 WEB Interface ........................37 5.3.1 WEB browser ......................37 5.3.2 Monitoring ....................... 38 5.3.3 Parameter ......................... 39 5.3.4 Control set ........................
- Page 4 User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 Figure Contents Figure 1. Electric Power Supply Connection ....................7 Figure 2. Front Panel ..........................9 Figure 3. Rear Panel ..........................11 Figure 4. Shelf Type EDFA Measuring Instrument Setup ................46 Table Contents Table 1.
-
Page 5: Introduction
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 INTRODUCTION About this Manual This manual consists of six sections. They are; Introduction of the Shelf Type EDFA, System Requirements, Installation, Operation, Testing, and Trouble Shooting. A brief chapter outline of this manual is below. -
Page 6: Grounding Considerations
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 it is also strongly prohibited from iterating of power on/off in very shot interval. The recommended on/off interval is at least 5secconds. The optical adapters for the EDFA input and output are located on the front panel of the Shelf Type EDFA. -
Page 7: Preparation
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 PREPARATION Summary In this chapter, the first steps of installation after unpacking are covered. The box inventory, basic electrical and optical connections are presented. Check the Contents After unpacking you need to check the contents. The inventory should be as follows: Table 1. -
Page 8: How To Connect The Optical Cable
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 DC input voltage range: -36~-76V(for DC-48V) AC input voltage range: 100~240 VAC, 50~60 Hz DC Power supply: When you connect DC power supply, handle it very carefully. Make sure you connect the positive (+) and negative (-) connections properly, positive supply to the positive input and negative supply to the negative input. -
Page 9: Description
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 DESCRIPTION Summary In this chapter, general information about the front and rear panels of the Shelf type EDFA are explained. The individual switches and connections will be introduced. Panel Description 3.2.1 Front Panel... -
Page 10: Led State Information
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 Condition Color Performance Green Pump Lasers On Laser Pump Lasers Off Green Normal Operation (No Alarm) Status LOS Alarm / LOP Alarm Yellow Bias / Temp / Case Temp/ Power / FAN Alarm Comm Blue Ethernet Link On... -
Page 11: Rear Panel
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 green to red. The LOP alarm turns off when the output optical power of the EDFA is normal and the color of status LED changes red to green. ... -
Page 12: Operation
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 OPERATION Summary In this chapter, the operation of the EDFA using the LCD menu will be explained. The diagram below shows the operational menu tree selectable. Menu Provision EDFA ACT EDFA DEACT Laser Key Switch is “ON”... -
Page 13: Lcd Operation
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 LCD Operation The functions of the Shelf Type EDFA are supported by selecting the LCD Menu switch on the front panel. If an electric power is applied, the initial display of the LCD display is as follows. -
Page 14: Provision Menu
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 In this condition MAIN MENU is finished. 4.2.2 Provision menu User is able to control the operational state of the EDFA in the Provision menu. It is the menu for selecting activate (ACT) and deactivate (DEACT) operational states of the EDFA. -
Page 15: Control
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 Table 7. Provision Menu Descriptions ACT State DEACT State EDFA: normal operation EDFA: normal operation Status LED: Green (Alarm information is not detected) 4.2.3 Control In the Control Menu, the optical output power of the EDFA can be controlled by Laser ON or Laser OFF. -
Page 16: Status
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 In this state push the ENTER switch. Set & Store Laser : Off Note: When the Laser is selected the “Off”, the output of the EDFA also turns off and the Laser LED becomes red. -
Page 17: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 > Status Test If you push the Enter switch, the cursor moves to the “Input Power” menu. The Input Power is the optical input power. > Input Power Output Power Input Power is displayed. -
Page 18: Table 8. Alarm Descriptions
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 The Temperature is the EDFA module temperature. The unit is centigrade [℃]. LD Thermistor ℃ LD1 : LD Thermistor ℃ LDx : Using the Alarm menu you are able to check the EDFA Alarms. Temperature >... -
Page 19: Test
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 > EDFA Model Name Input Power 4.2.5 Test From the Test menu you are able to test the LED, Buzzer. Status > Test If you push the Enter switch, the cursor moves to the “LED Test” menu. In the LED Test menu the operating state of all the LEDs can be checked. -
Page 20: Ip Address
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 YYYY MM DD HH MM SS 2 0 0 5 0 6 0 9 1 5 0 5 3 0 YYYY MM DD HH MM SS 2 0 0 5 0 6 0 9 1 5 0 5 3 0 If you push the Enter switch, the time value is stored. -
Page 21: Interface
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 INTERFACE Command Line Interface (CLI) User can monitor or control EDFA through Ethernet port or COM port. ADMIN and USER accounts are established separately for different access priorities. ADMIN account holder can set passwords for both ADMIN and USER accounts. -
Page 22: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 gateway Read/Write Read Only reset Read/Write Read Only Read/Write Read Only ofau Read/Write Read Only snmp Read/Write Read Only shelf Read/Write Read Only Read/Write Read Only 5.1.1.1 Software version information. ADMIN:>... -
Page 23: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 ARG1 : get, set ARG2 : get - sysinfo. MPU module Information status. MPU module Status config. MPU module Configuration inpower. Input Power Value of MPU Module set - time. descr. -
Page 24: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 SHELF GET INFO : View Logical ID SHELF GET PSINFO : Power supply module information ADMIN:> shelf get psinfo -------------------------------------------------------- # Power Supply Voltage Information. Power supply module count : [2] Power supply No.[1] type : DC -48 PS output voltage : 1.3[V]... -
Page 25: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 TEMP alarm : [1] SHELF GET SYSTH : Shelf system threshold value ADMIN:> shelf get systh -------------------------------------------------------- # SHELF system threshold value Casetemp alarm threshold value information. AlarmHIHI : [750] AlarmHI : [650] AlarmLO... -
Page 26: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 -------------------------------------------------------- # Log Count : [0] (1~1024) # Last log index : [0] (1~32767) 5.1.1.11 OFAU Check information on OFAU and its status. In addition, basic set up of OFAU is possible. See below for examples. -
Page 27: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 LD[2] ==> Bias : 0 [mA] Temp. : 25 ['C] LD[3] ==> Bias : 3 [mA] Temp. : 24 ['C] LD[4] ==> Bias : 0 [mA] Temp. : 25 ['C] OFAU GET CONFIG –... -
Page 28: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.1.1.12 SNMP Before SNMP interface connection, a few preliminary setups need to be done. SNMP interface requires Read Only Community and Read Write Community to be set up. For Trap set up, Trap IP, Trap Community, and Trap Enable/Disable need to be defined beforehand. -
Page 29: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 ADMIN:> snmp get trapen 1 -------------------------------------------------------- SNMP Trap enable[1] : [OFF] SNMP GET TRAPCOMM [Index] ADMIN:> snmp get trapcomm 1 -------------------------------------------------------- SNMP Trap Community[1] : [public] SNMP SET ROCOMM [string] ADMIN:>... -
Page 30: Dk-4060 Kirke Saaby
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 ADMIN:> ntp set server 141.223.182.106 172.0.0.1 -------------------------------------------------------- NTP Server Setting is Successful. -------------------------------------------------------- NTP GET SERVER ADMIN:> ntp get server -------------------------------------------------------- server 141.223.182.106 server 172.0.0.1 -------------------------------------------------------- NTP SET TIMEZONE [GMT+9] ADMIN:>... -
Page 31: Network Configuration
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.1.2 Network Configuration User needs to set up network configuration for the product. Factory default IP address is 192.168.0.100. Network configuration is to be modified by either SNMP or Telnet. The modified configuration is enacted by reboot. The reset command of CLI also allows the modified configuration to be enacted. -
Page 32: Snmp Mib Table
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 SNMP MIB Table 5.2.1 entPhysicalEntry entityMIB OID : 1.3.6.1.2.1.47 Name Type Access E.T.C entPhysicalIndex 1.3.6.1.2.1.47.1.1.1.1.1.x Integer32 entPhysicalDescr 1.3.6.1.2.1.47.1.1.1.1.2.x octets entPhysicalClass 1.3.6.1.2.1.47.1.1.1.1.5.x Integer32 entPhysicalName 1.3.6.1.2.1.47.1.1.1.1.7.x octets - entPhysicalIndex : entity physical index - entPhysicalDescr : entity physical description - entPhysicalClass : entity physical class - entPhysicalName : entity physical name... -
Page 33: Discretepropertyentry
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 - currentAlarmAlarmSate : Alarm state of generated alarm - currnetAlarmAlarmValue : Alarm value of generated alarm 5.2.4 discretePropertyEntry discretePropertyEntry OID : 1.3.6.1.4.1.5591.1.1.3.1 Name Type Access E.T.C discreteParameterOID 1.3.6.1.4.1.5591.1.1.3.1.1.x object identifier discreteAlarmValue 1.3.6.1.4.1.5591.1.1.3.1.2.x... -
Page 34: Commonmulticastgroup
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 commonInternalTemperature 1.3.6.1.4.1.5591.1.3.1.13.0 Integer32 commonTime 1.3.6.1.4.1.5591.1.3.1.14.0 Integer32 commonVarBindings 1.3.6.1.4.1.5591.1.3.1.15.0 Integer32 commonResetCause 1.3.6.1.4.1.5591.1.3.1.16.0 Integer32 commonLogicalID : logical ID - commonVendor : vendor - commonModelNumber : model number - commonSerialNumber : serial number of model - commonVendorInfo : vendor information - commonReset : software reset(write ‘1’) - commonAlarmDetectionControl : Detection control of all alarm parameter... -
Page 35: Hebaseident
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 - heOpAmpInputPower : input power value - heOpAmpLaserIndex : index of LD - heOpAmpLaserTemp : temp of LD - heOpAmpLaserBiasCurrent : bias current fo LD - heOpAmpOutputIndex : index of output power - heOpAmpOutputPower : value of output power - heOpAmpOutputGainType : output power gain type(AGC/APC) [x : Pump LD Index (1 ~ 7)]... -
Page 36: Hefans
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 [x : PS Index (1 ~ 2)] 5.2.11 heFans heFans OID : 1.3.6.1.4.1.5591.1.11.2.3 Name Type Access heFanUnitAlarm 1.3.6.1.4.1.5591.1.11.2.3.1.1.1.1.1.x Integer32 heFanStatusIndex 1.3.6.1.4.1.5591.1.11.2.3.1.1.2.1.1.1.x Gauge32 heFanStatusIndex 1.3.6.1.4.1.5591.1.11.2.3.1.1.2.1.3.1.x Integer32 - heFanUnitAlarm : status of fan(‘1’ is ok, another value is not ok) - heFanStatusIndex : index of fan - heFanStatusAlarm : status of fan(‘1’... -
Page 37: Web Interface
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 WEB Interface Users have an option to monitor or control the EDFA through a WEB browser. ADMIN and USER accounts are established separately for different access priorities. The ADMIN account holder can set passwords for both ADMIN and USER accounts. -
Page 38: Monitoring
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.2 Monitoring The present status of the optical amplifier can be monitored. Status data can be automatically refreshed at a user-selectable rate. The Default refresh period is 15 seconds. The monitoring page is accessible through all of the user levels. DKT A/S Fanoevej 6 DK-4060 Kirke Saaby... -
Page 39: Parameter
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.3 Parameter The parameter page provides a view similar to the screen shot below. The Input Power and Output Power alarm threshold values are displayed and can be modified. Other elements are read only.Users should exercise caution in adjusting the threshold values away from the default, as they are critical for proper optical amplifier operation. -
Page 40: Control Set
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.4 Control set This page allows for various control settings to be adjusted via the convenient WEB GUI. Only the ADMIN account user can access this page. DKT A/S Fanoevej 6 DK-4060 Kirke Saaby +45 4646 2626... -
Page 41: Event Log
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.5 Event log The Event Log page will display all of the recorded events during the optical amplifier’s operation. Up to 200 events are recorded and shown in this page. The event log page is accessible through all the user levels. -
Page 42: Ip & Login Set
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.6 IP & Login set IP, Subnet mask, and Gateway addresses can be set via this page. Passwords for Admin and User accounts can be set. A system reboot and Factory Reset can be performed. Caution should be exercised as the optical amplifier operation can be affected critically. -
Page 43: Snmp Set
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.7 SNMP set SNMP Trap IP addresses can be set and enabled/disabled. The Trap community information is case-sensitive, and should be matched to the MIB browser or NMS settings that is communicating with the device. -
Page 44: Manual
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 5.3.8 Manual The user’s manual in .PDF format is resident on the amplifier and available via the web GUI for convenience. This link is accessible through all the user levels. DKT A/S Fanoevej 6 DK-4060 Kirke Saaby... -
Page 45: Performance Check
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 PERFORMANCE CHECK Precautions for Testing In this chapter after completing installation of the Shelf Type EDFA the proper operation, power supply procedures, monitor connection, start test method, and other instructions are explained. -
Page 46: Alarm Test
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 Optical Optical Optical Power Source Attenuator Meter Figure 4. Shelf Type EDFA Measuring Instrument Setup Test procedure of the Shelf Type EDFA 1) Connect the measuring instrument in Figure 4. 2) Check the optical signal power from the optical source (ⓐ) by using the optical power meter. -
Page 47: Maintenance
User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 MAINTENANCE Maintenance Cautions If the Shelf type EDFA is out of order, a specialized expert must check the EDFA and the problem. The expert should try to resolve the problem using the technical information provided. The expert should follow the steps below which may fix the problem or recover the operational state. - Page 48 User’s Manual Rev 1.3 Network Managed Optical Amplifier OFA-CCS/CCD Series June 2014 If you identify the problems as shown in the Table or have an unidentified problem you must stop operating the EDFA immediately. Please contact manufacturer. DKT A/S Fanoevej 6 DK-4060 Kirke Saaby +45 4646 2626 +45 4646 2625...
