Page 2 INTRODUCTION FEATURES Congratulations on your purchase of your new pre amplifier-Equalizer. Our The subwoofer output is an additional convenience when you sonic excellence is considered our most important objective. Your selection of wish to add subwoofers to your audio system to this component tells us you desire to achieve the same goal.
Page 3: Front Panel Controls
FRONT PANEL CONTROLS BACK PANEL CONNECTIONS G-EQ5B G-EQ5B 1. VOLUME CONTROL: Leave the source unit at 3/4 volume and use this Control as the master volume control. 2. INPUT SELECTOR SWITCH: This switch selects the RADIO/CD input. 3. FADER: Controls the output level to front and rear.
Page 4: Electrical Installation
ELECTRICAL INSTALLATION CROSSOVER CONTROL CD CHANGER RADIO/CASSETTE One of the best features of this unit is that it allows the listener to adjust each band exactly to his own satisfaction, so please note that the correct settings depend very much on the overall system itself and the individual musical taste of the listener.
Page 5: Mechanical Installation
Bracket can be reversed for MECHANICAL INSTALLATION installer s individual needs. We suggest securing to surface with a #8 metal screw. 1. Select the location to mount the unit under the dash board. 2. Drill (4) 4 mm diameter holes. Fix the mounting bracket to the location with (4) 4 x 15 mm tapping screw.
