Summary of Contents for Doublesense Systems StripOne
- Page 1 SYSTEMS AB 070913_B1...
-
Page 2: Thanks
The StripOne is developed by The Doublesense Team with great help from : Tobias Lindell (Tobias Lindell Musicproduction AB) Matias Karlsson Jörgen Andersson Peter Skörvald Svensk Elektronikproduktion AB Thanks ! The MicOne is manufactured and distributed by Doublesens Systems AB 2007... -
Page 3: Table Of Contents
This unit is supplied with an external power supply dependant on the region in which the StripOne is purchased. To avoid the risk of fire, replace the mains fuse only with the correct value fuse, as marked on the plug. The external power supply unit contains no user serviceable parts. -
Page 4: Introduction & In The Box
The StripOne is handcrafted in Sweden. Built and developed by engineers for engineers! The all discrete Class StripOne uses only the very best componentsavailable on the market today. The extremely user friendly StripOne is a high-end recording channel strip encompassing an all tube microphone preamplifier that features input gain, output gain, phantom power, low-cut, phase and direct out. -
Page 5: Front & Rear Panel
Output The StripOne is the ideal choice for the recording or mixing of a mono signal, whether it's a vocal track or a guitar plugged directly into the input. And also the abillity to be linked with a other StripOne for suberb stereo dynamics. The StripOne utilises classic vintage dynamics and mic preamp solutions and also making use of new technology. -
Page 6: Connecting The Strip
- HOT PIN 1 - GROUND RING - GROUND PIN 2 - HOT PIN 3 - COLD ALL RIGHTS RESERVED StripOne for stereo linked limiter S ri SO-2 B-07 21-24 M ade in SWEDEN SYSTEMS A B LIMITER SECTION MICROPHONE PREAMP... -
Page 7: Facilities And Controls
Output level in % of mic gain to give a clear air feeling. JUICE INPUT GAIN OUTPUT LEVEL Link Link ON=stereo limiting with an Limiter other StripOne Bypass Limiter bypass Bypass= No limiter, preamp out Input to limiter out Input level from preamp Gainreduction Limiter reduction... -
Page 8: Notes
Notes My setting______________________ TUBE MICROPHONE PREAMPLIFIER DISCRETE OPTICAL LIMITER ADEQUATE Line Preamp to Limiter Link Action Phase Limiter CRUSH LESS Bypass Lowcut METER SELECTOR JUICE ACTION Gainreduction INPUT GAIN OUTPUT LEVEL THRESHOLD OUTPUT GAIN Input Output My setting______________________ TUBE MICROPHONE PREAMPLIFIER DISCRETE OPTICAL LIMITER ADEQUATE Line... -
Page 9: Block Diagram
Block Diagram of the StripOne +48V Lowcut Preamplifier Line Preamplifier Mic & Line Input Phase Preamp to Limiter Line Output Tube Microphone Preamplifier Balanced Balanced Z_line Link Discrete optical Limiter Limiter Limiter Stereo link Limiter Line Output Line Input Balanced... -
Page 10: Specifications
Technical specifications Inputs All discrete Class A design Electronically balanced 20kW. Optical Limiter Nominal level +4dBu / -10dBV All tube microphone preamplifier Input Connectors Direct preamp out, direct limiter in 1/4” jack (Link only) +24dbu at maximum balanced levels 1 XLR inputs for Mic / Line Frequence response: 15-35kHz OEP Transformers Front Panel Controls...
