- Page 1 960H HD 960H Bullet Camera with 30m IR Night Vision IP66 Weatherproof Adjustable Viewing Resolution Night Vision Rated Angle (23 to 92°) User Manual Version 1...
-
Page 2: Table Of Contents
Contents Overview ......... 1. Product 1.1. Product Features ......2. Product Contents ......... 3. Installation ............ 6 3.1. Lens Angle Adjust ......4. Installation Diagram ........5. Specifications ..........10... - Page 3 Warning Caution: To prevent electric shock and fire hazards, please don’t use a power supply not Warning: To reduce the risk of listed oin the manual. electric shock, non-professional personnel should not remove the cover. This symbol alerts the user to operate and maintain the product according to the manual.
-
Page 4: Product Overview
The bullet is ideal for indoor or outdoor use (IP66 Rated) and has a cable managed and compact design. The IQC range of 960H cameras from IQCCTV are designed to offer crystal clear images and amazing value for money, this is achieved by removing high-end features not needed in everyday applications. -
Page 5: Product Contents
2. Product Contents Before installing this product, please ensure that it contains the following; Contents 1x IQC960BV Bullet Camera 960H HD 960H Bullet Camera with 30m IR Night Vision 1x User Manual IP66 Weatherproof Adjustable Viewing Resolution Night Vision Rated Angle (23 to 92°) -
Page 6: Installation
3. Installation 12v DC Input Power Cable Video Cable 1. Select a suitable position on the wall or ceiling to install the camera. Use the camera bracket as a stencil and mark out holes to be drilled. 2. Using the correct drill bit for the type of wall, drill the holes out in the wall or ceiling. -
Page 7: Lens Angle Adjust
5. To adjust the camera angle, you will need to loosen the screw on the bracket, as shown right. 3.1 Lens Angle Adjust To adjust the lens angle, unscrew the cover as shown below Then, use the twist the focus and zoom screws (Below) to gain the desired view. -
Page 8: Installation Diagram
4. Installation Diagram Use a power splitter lead to power more than one camera. Plug & Play Cable Power Supply for camera(s) Power Lead (Do not use DVR PSU) Power Camera Power Lead Jack MAINS POWER BNC Input Power Supply Power For Camera Jack... - Page 9 To Connect Cable to Camera(s) Connect the power lead coming from the camera to the power jack on the Plug & Play cable Connect the BNC connector from the camera to the BNC on the Plug & Play cable To Connect Power to the Camera(s) Connect the power socket on the cable to the Power Supply –...
-
Page 10: Specifications
5. Speci cations Image Sensor High Resolution CMOS Image Sensor Resolution 800 TVL Lens Size 2.8 - 12mm Automatic Electronic Iris Automatic Electronic Shutter Automatic Gain Control DSP Functions Automatic White Balance Backlight Compensation Minimum Illumination 3 Lux (IR Off), 0 Lux (IR On) Night Vision 20-30m IR Night Vision Power Supply... - Page 11 Notes...
