Abtus SPS-SO35A/P1 User Operating Manual

RS-232 COMMAND CODE

RS-232 Command Code Item
1.
Description Setting
2.
Baud Rate : 9600bps
3.
Data Length : 8 bits
4.
Parity : Non Parity
5.
Stop Bit : One stop bit
6.
X on/Off : None
7.
8.
9.
RS-232 Conection
10.
Pin Function
11.
1 Tx Transmit data
12.
2 Rx Receive data
13.
3 GND Ground
14.
15.
1.
2.
3.

SPECIFICATIONS

Technical Model:
Signal Type
Input 2 x Stereo Audio
Line-in (Mixed)
Output 1 x Left Speaker
2 x 12V DC (Max 1A)
1 x Line out
(Loop Out)
Control Port RS-232
`
External Volume
Control (0~5V)
Output Power
Speaker Unit
Tweeter
Woofer
Sensitivity
Frequency Range
Treble Adjust
Bass Adjust
Separation
S/N Ratio
Power Supply Switching Power Supply unit AC 100~240V 50/60Hz
Mechanical
Housing ABS enclosure
Product
Dimensions (L x W xH) 288 x 215 x 180 mm
Weight 3.4 Kg (*Active Speaker)
3.2 Kg (*Passive Speaker)
Fixedness
Package include
1 x Active Speaker *With Eco Digital Audio Amplifier
2 x Wall-mount U bracket
1 x Power Cord
**Specification are subjected to changes without notice. . . for detail and updated information please visit www.abtussingapore.com
Description Command code (Hex)
VOL SET 01 53 45 54 53 09 30 56 43 30 30 31 30 30 31
VOL SET 20 53 45 54 53 09 30 56 43 30 30 31 30 32 30
VOL SET 54 (max) 53 45 54 53 09 30 56 43 30 30 31 30 35 34
VOL UP 53 45 54 53 09 30 72 43 30 30 31 30 30 2B
VOL DOWN 53 45 54 53 09 30 72 43 30 30 31 30 30 2D
BASS SET 00 (min) 53 45 54 53 09 30 49 43 30 30 31 30 30 30
BASS SET 15 (max) 53 45 54 53 09 30 49 43 30 30 31 30 31 35
BASS UP 53 45 54 53 09 30 76 43 30 30 31 30 30 2B
BASS DOWN 53 45 54 53 09 30 76 43 30 30 31 30 30 2D
TREBLE SET 00 (min) 53 45 54 53 09 30 4A 43 30 30 31 30 30 30
TREBLE SET 15 (max) 53 45 54 53 09 30 4A 43 30 30 31 30 31 35
TREBLE UP 53 45 54 53 09 30 77 43 30 30 31 30 30 2B
TREBLE DOWN 53 45 54 53 09 30 77 43 30 30 31 30 30 2D
AUDIO MUTE ON 53 45 54 53 09 30 41 43 30 30 31 30 30 31
AUDIO MUTE OFF 53 45 54 53 09 30 41 43 30 30 31 30 30 30
Get Status
GET VOL 53 45 54 53 09 31 56 43 30 30 31 58 58 58
GET BASS 53 45 54 53 09 31 49 43 30 30 31 58 58 58
GET TREBLE 53 45 54 53 09 31 4A 43 30 30 31 58 58 58
SPS-S035A/P1
Connector type Connector type
2 x 3pin screw type 2 x 3pin screw type
terminal block
1 x 2pin screw type 1 x 2pin screw type
terminal block
2 x 2pin screw type
terminal block
1 x 3pin screw type
terminal block
1 x 3pin screw type
terminal block
1 x 3pin screw type
terminal block
35W + 35W
1” (balanced dome)
5 3/4” PP cone
89 dB
20 Hz to 20 KHz (Amplifier)
30 Hz to 18 KHz (Speaker)
± 10 dB
± 10 dB
45 dB
75 dB
Package
425 x 250 x 330 mm
6.8 Kg
2 x Wall-Mount U bracket
1 x Passive Speaker
1 x Quick User Guide
1 x Speaker Cable
“Eco Digital Amplifier 35W per channel”
SPS-S035A1
terminal block
terminal block
2 x 2pin screw type
terminal block
1 x 3pin screw type
terminal block
NIL
NIL
ABtUS SINGAPORE PTE LTD
Eco Active
Speaker System
Model: SPS-S035A/P1
