- Page 1 GoPro Brushless Gimbal Assembly Manual V2.0 Team Rebel Design...
- Page 2 Team Rebel Design...
-
Page 3: Check List
Check List Picture Item Part # Picture Item Part # Brushless Side Camera JYDCM- Gimbal JYDCM-EC031 Cover AL031 Controller Upper Camera JYDCM- IMU cable JYDCM-EC032 cover AL032 Brushless BL2210-80 JYDCM-EC033 Gimbal Motor JYDCM- Rear arm receiver wire JYDCM-EC034 AL033 JYDCM- Motor Mount USB to AV cable JYDCM-EC004... - Page 4 Check List Cont. Picture Item Part # Picture Item Part # Upper Damper JYDCM- M3 Nylon Nut NNM3 Plate CF31 Silicon JYDCM- Flat head screw SPS-3*6 Damper PL001 M3*6mm stainless steel cap screw cap screw CSM2.5*5 CS2.5*4 M2.5*4mm M2.5*5mm Set Screw Flat Flat head screw SS3x5 SPS-2.5*6...
- Page 5 Unboxing Team Rebel Design...
- Page 6 Assembly: Pitch Motor M2.5 x 4mm(Black) 2pcs Team Rebel Design...
- Page 7 Upper Camera Cover M2.5 x5mm (stainless steel) Team Rebel Design...
- Page 8 Gimbal Arms Team Rebel Design M2.5 x 4mm(Black)
- Page 9 Lower Damper Plate Flat Head M2.5 x 6mm(Black) Team Rebel Design...
-
Page 10: Camera Installation
Camera Installation M2.5 x5mm (stainless steel) Team Rebel Design... - Page 11 Upper Damper Plate M2.5 Nylon Screw/nut Silicon Dampers M2.5 x4mm Cap Screw Team Rebel Design...
- Page 12 Assembly Team Rebel Design...
-
Page 13: Balance Adjustment
Balance Adjustment Set Screw M3 x5mm Team Rebel Design (Apply carefully! Do NOT over tighten set screw) - Page 14 Team Rebel Design...
-
Page 15: Board Connections
Board Connections: Green V2, current version, mosfet based(OSBruGi ver fw) Team Rebel Design... - Page 16 Misc: USB-FPV/5v cable Black cable: GND RED: 5v input Yellow: Video out Team Rebel Design...
-
Page 17: Finished Assembly
Finished Assembly Team Rebel Design... - Page 18 Team Rebel Design...
- Page 19 Team Rebel Design...
- Page 20 Team Rebel Design...
- Page 21 Before Use Make sure the IMU is facing UP when installing. We suggest to use 3s battery for GoPro and/or similar size camera. Double check the battery polarity before plugged in. The Brushless Gimbal Controller is preset to plug-n-play with GoPro camera. There is no additional tuning needed for basic operation.
-
Page 22: Appendix I: Troubleshooting
Appendix I: Troubleshooting Q: Why does the gimbal not stabilize the camera? A: Please check the battery voltage and if the LED is lit. Q: Why is the gimbal not stabilizing the camera in right direction? A: Please refer to installation and make sure imu is installed at right orientation and the motors are connected to correct pins. -
Page 23: Appendix Ii: Legacy Controllers
Appendix II: Legacy Controllers Blue V1, lagacy (OSBruGi ver fw) *Green wire (pitch pin) is not used for OSBruGi ver. Red wire provides 5v if needed. **Blue wire is connected to F2 on Naza or any assigned manual pitch control channel. (GND must be connected) ***Due to configuration error, if manual pitch is used, please refer appendix iii on the back for correction. - Page 24 Blue V2, lagacy (OSBruGi ver fw) *Pitch pin is not used for OSBruGi ver. Red wire provides 5v if needed. **Blue wire is connected to F2 on Naza or any assigned manual pitch control channel. (GND must be connected) ***Due to configuration error, if manual pitch is used, please refer appendix iii on the back for correction. Team Rebel Design...
-
Page 25: Appendix Iii: Correct Configuration For Osbrugi Ver For Legacy Controllers
Appendix III: Correct configuration for OSBruGi ver for legacy controllers In OSBruGi GUI, change the circled value accordingly to enable “Roll” pin as manual input control. Team Rebel Design...
