Summary of Contents for Vornado TAVH10
- Page 1 TAVH10 WHOLE ROOM HEATER OWNER’S GUIDE GUÍA DEL PROPIETARIO EL CALENTADOR PARA AMBIENTES READ AND SAVE THESE INSTRUCTIONS LEER Y GUARDAR ESTAS INSTRUCCIONES www.vornado.com...
- Page 2 PERFECT www.vornado.com 800.234.0604 help@vornado.com English...
-
Page 3: Table Of Contents
CONTENTS Important Instructions ................ 4 Storage ....................14 Whole Room Heat ................8 Reset Heater ..................14 Safety Features ................... 9 Troubleshooting ................15 Controls ..................... 10 Warranty .................... 16 How To Use ..................11 Product Specifications ..............33 Remote Control ................. 12 Español p. -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS WARNING – When using electrical appliances, basic precau- tions should always be followed to reduce the risk of fire, electric READ ALL INSTRUCTIONS BEFORE USING. shock and injury to persons, including the following: WARNING This owner’s guide and any additional inserts are considered part of the product. - Page 5 - To disconnect heater, turn controls to off, then remove plug high power device, such as a vacuum or circular saw. from outlet. - Do Not use this heater on a circuit that has a variable speed - The TAVH10, like any other 1500-watt electric heater, draws up English...
- Page 6 Warning: In order to avoid overheating, do not cover the to 12.5 amps of electric current. If using your TAVH10 on the heater. High Heat mode setting causes your home circuit breaker or...
-
Page 7: Save These Instructions
If this equipment does cause harmful interference to radio or televi- sion reception, which can be determined by turning the equipment off and on, the user is encouraged to contact Vornado Consumer Service at 1-800-234-0604. SAVE THESE INSTRUCTIONS Please keep all documents for future reference and pass these docu- ments on, together with the product, to any future owner. -
Page 8: Whole Room Heat
WHOLE ROOM HEAT The TAVH10 use Vornado’s signature Whole Room Heat circulation to deliver continuous, uniform heat to the entire room. Be comfortable in the room you’re in. Heat only the rooms that you are in and not the entire house. -
Page 9: Safety Features
SAFETY FEATURES COOL TOUCH CASE Safe to touch, even on high heat setting. FINGER FRIENDLY DESIGN Resists curious fingers. AUTOMATIC SAFETY SHUT OFF SYSTEM If airflow becomes blocked, power to the heater is shut off to prevent overheating. AUTOMATIC TIP-OVER PROTECTION If tipped more than 10 degrees in any direction, the heater will immediately shut down. -
Page 10: Controls
CONTROLS The LCD Display illuminates when powered on and as settings are adjusted, then dims after five seconds of inactivity. MODE High Heat (1500 watts), Low Heat (750 watts) or Fan Only. POWER ON/OFF ( ) THERMOSTAT (-/+) TIMER ( POWER INDICATOR LIGHT To indicate the heater is on, the red light will illuminate. -
Page 11: How To Use
HOW TO USE Before use, check appliance for visible damage. DO NOT USE THIS HEATER if there is evidence of damage. If any damage is found, contact Vornado Air LLC at 1-800-234-0604. 1. Use the integrated handle for lifting and 4. -
Page 12: Remote Control
REMOTE CONTROL The TAVH10 Remote is wrapped inside a polybag. A separate polybag with a coin style battery is also included (battery is not installed in the remote). The polybags are packed inside the top section of molded pulp that is placed securely around the top and bottom of the heater. -
Page 13: Cleaning
Because your heater moves a substantial amount of air, it will need regular cleaning. Cleaning the outside of the heater is recommended on a bi-weekly basis. If service is required, return your heater to Vornado (see WARRANTY for instructions). 1. Unplug your heater before cleaning. -
Page 14: Storage
4. Plug in the power cord and place heater in desired position. carton if available. This will prevent the heater from accu- 5. Touch the power button on. Your Vornado Heater should now func- mulating dust overtime. tion normally and return to the last stored setting. -
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE AND SOLUTION The unit fails to power on. Unit is not plugged in. Plug power cord into electrical outlet. Household circuit breaker / ground fault interrupter has tripped or blown a fuse. Reset circuit breaker / ground fault interrupter, or replace fuse (See IMPORTANT INSTRUCTIONS). -
Page 16: Warranty
Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002. For your able information at time of printing. The contents of this manual may differ slightly from convenience, please have your model number and serial number when contacting the actual product. -
Page 17: Product Specifications
PRODUCT SPECIFICATIONS TAVH10 MODEL VOLTAGE 120V~ WATTAGE 1500W 12.5A AMPERAGE UNIT DIMENSIONS 11.63” (29.5 CM.) x 9.25” (23.5 CM.) x 12.00” (30.5 CM.) ESPECIFICACIONES DEL PRODUCTO MODELO TAVH10 VOLTAJE 120V~ 1500W VATIAJE AMPERAJE 12.5A DIMENSIONES DE LA UNIDAD 11.63” (29.5 CM.) x 9.25” (23.5 CM.) x 12.00” (30.5 CM.) -
Page 18: Español
Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | www.vornado.com CL3-0391 R-, V01...
Need help?
Do you have a question about the TAVH10 and is the answer not in the manual?
Questions and answers
No puedo desbloquear el calenton
To unlock the Vornado TAVH10 heater:
1. Touch the Power button to turn it off and unplug the unit.
2. On the bottom of the unit, find the cylindrical plunger.
3. Push the plunger 4–5 times to ensure it is not stuck.
4. Set the heater down on a flat surface.
5. Make sure the power cord lays completely flat and extends properly from the back of the heater.
6. Plug the unit back in.
7. Touch the Power button to turn it on.
8. Set it to the highest heat setting and ensure it is not on the Fan Only setting.
