Securia SC11 Owner's Manual

Multi-function door / window alarm
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SC11
Multi-function
Door / Window Alarm
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC11 and is the answer not in the manual?

Questions and answers

Summary of Contents for Securia SC11

  • Page 1 SC11 Multi-function Door / Window Alarm OWNER'S MANUAL...

  • Page 2: Table Of Contents

    Table of Contents Page 1. Introduction………………………………..1 2. General Features ………………………...2 3. Outlook …………………………………..3 4. Battery Insertion ………………………….4 5. Installation ………………………………...6 6. Operation Modes …………………………7 6.1 Alarm Mode Operation 6.2 Music / Chime Mode Operation 7. Specification …………………………….12...

  • Page 3: Introduction

    1. INTRODUCTION Congratulations! You are now the proud owner of a Multi-function Door/Window Entry Alarm. With this little device on your door/ window, a reliable guard begins to serve and secure your house and your family day and night. In addition to security purpose, this device is also ideal for use as a welcome “chirp”.

  • Page 4: General Features

    2. GENERAL FEATURES The outstanding features of SC11 Multi- function Door/Window Alarm include: •High Reliability by magnetic sensors •Choice of 3 different sounds (alarm, chime, music) •Selection of 3 alarm time •Selection of entry delay time (0, 5 seconds) •Panic alarm •Intrusion memory indicator...

  • Page 5: Outlook

    3. OUTLOOK 1. Digital key pad 2. Arm button 3. Password button 4. Set button 5. LED indicator 6. Alarm “ ” /Chime “ ” /Music “ ” switch 7. Magnetic sensor...

  • Page 6: Battery Insertion

    4. BATTERY INSERTION 4.1. Battery Installation To install the batteries, just open battery cover at the back of the unit. Place 3 pcs “AAA” alkaline batteries with right polarity according to the “+” and “-” marking as shown on the bottom of the battery compartment.
  • Page 7 Note: 1.If the batteries were incorrectly installed, the alarm will NOT function at all. 2.Do not use new batteries together with old ones.

  • Page 8: Installation

    5. INSTALLATION 5.1. To mount the unit to the wall, mark the locations of holes and install anchor and screw accordingly. Place the unit over the screw and slide it down to secure in place. 5.2. To mount the magnetic sensor to the door/window and door/window frame by peeling off the sealing paper of the adhesive tapes at the back...

  • Page 9: Operation Modes

    6. OPERATION MODES 6.1. Alarm Mode Operation 6.1.1. To arm & disarm the unit, please follow the operating steps below: a.Slide the Alarm/Chime/Music “ ” switch to Alarm “ ” position. b.Press the Arm “ ” button. You now have 15 seconds exit time to close the door/ window.
  • Page 10 (default setting is 111). In Alarm Mode, you can change the setting of password, alarm time & entry delay time as you like. All settings could be modified in disarm status only. Note: In Chime/Music mode, modification of setting is not allowed. 6.1.2.
  • Page 11 can be heard indicating the acceptance of the new password. 6.1.3. Change of Alarm Time & Entry Delay Time The alarm time & entry delay time can be changed by pressing Set “ ” button and then follow by 1-digit key as below: 1 minute (default) 1 minute alarm, 30 seconds rest,repeat 2 cycles and then...

  • Page 12: Music / Chime Mode Operation

    6.1.4. Intrusion Memory Whenever you disarm the unit, the LED indicator flash for 6 times. That means it has detected an intruder during armed state but no body disarm it by inputting correct password. Then, you must take necessary precautions before you enter the area. 6.1.5.
  • Page 13 a.Slide the Alarm/Chime/Music “ ” switch to Chime “ ” or Music “ ” position according to your preference. b.Whenever the door/window opens, you will hear “Ding Dong” or music for about 3 seconds. c.To turn off the unit, slide the Alarm/Chime/ Music “...

  • Page 14: Specification

    7. SPECIFICATIONS 7.1. Power characteristics Power source :4.5 V DC ( 3 pcs “AAA” Alkaline batteries) Battery life Alarm mode :1.5 year (once per week,1 minute alarm time) Chime/Music mode :1 year (4 times per day) Power consumption :< 50 µA Low battery check :<...
  • Page 15 7.2. Alarm Exit time : 15 seconds Entry delay time : 0 (default) or 5 seconds Alarm time : •1 minute (default); •1 minute alarm,30 seconds rest, repeat 2 cycles; •1 minute alarm, 30 seconds rest, repeat this cycle until disarm Panic alarm : continuous alarm Alarm sound...
  • Page 16 7.3. Dimensions Main unit :55 (L) x 23 (W) x 88 mm(H) Magnetic sensor :26 (L) x 14 (W) x 54 mm(H)
