KT-LCD3 eBike Display User Manual
Dear customer, please read this manual before you use KT-LCD3 instrument. The manual will guide you use the
instrument correctly to achieve a variety of vehicle control and vehicle status display.
Functions and Display
Instruments using the structure form of instrument body portion and the operation buttons are designed separately.
1 UP Button
2 SW Button
3 DOWN Button
4 Battery capacity indicator
5 Backlight and headlights
6 The brake display
TM Single trip time
7
TTM Total trip time
MOTOR W Power display
MOTOR ℃
8 Motor temperature
MOTOR ℉
Motor fahrenheit
℃
Environment temperature
9
℉
Environment fahrenheit
Operation
1. ON/OFF
Hold button long to turn on the power, and hold
motor stops driving and when the e-bike is not used for a consecutive 5 minutes, it will automatically shut down and turn off
the motor power supply.
2. Display 1
Hold
10 6Km/H push power assist
Km/H Riding speed(metric)
MPH Riding speed
11
MXS Single maximum speed
AVS Single average speed
Km Distance(metric)
Mil Distance (imperial)
12 DST Trip distance
ODO Total distance
VOL Battery voltage
ASSIST Pas level
13
CRUISE Cruise
long for a second time to turn off the power. When the
button to start up and enter display 1.
2.1 Turn on backlight and headlights
V1.0
2.2 Assist ratio gear (ASSIST) switch
2.3 6Km/H assist promotion function
2.4 Cruise function
(imperial)
2.5 Display and delete of single Data
2.6 Battery capacity indicator display
displays are totally turned off. When the controller is power off due to voltage shortage, the power display frame flashes,
indicating the vehicle has been in voltage shortage and waiting for shutdown currently.
3. Display 2
Hold long to turn on backlight and headlights (the controller should have
headlight drive output function); hold long again to turn off the backlight and
headlights.
Hold or shortly to switch 1-5 file gear. Gear 1 is for the minimum power,
gear 5 is for the highest power. Each startup will automatically restore the gear shutdown
last time(the user can set randomly). Gear 0 is without booster function.
Hold and flashes,the vehicle drives at the speed not more than 6Km /h.
Release button,the function is invalid.
After the cruise function is turned on, the trip riding speed is greater than 7km/ h,
hold long and enter cruise, the CRUISE lit. Brake or hold any button to cancel.
After power on for 5 seconds, hold and
riding time (TM) and single trip distance (DST) flash, hold
content of both is cleared. If failed holding the button within 5 seconds, it will
automatically return the display interface after 5 seconds, original content is preserved.
The meter can automatically identify 24V, 36V, 48V battery capacities when it is
supporting use with the specified controller. When the battery capacity is over 70%, the
four power displays of the meter are lit, when the battery capacities drop, the four power
displays are off in order, when the power capacity is less than 15%, the four power
Hold button shortly in display 1 to enter display 2. Toal trip time (TTM) and
total distance (ODO), single average speed (AVS), motor operating temperature
at the same time, single trip
button shortly, the
