SWIT S-2040 User Manual

LED Camera Light S-2040/S-2050
Congratulations on your purchase of this product. Please read this user manual carefully.
Features
New generation chip-array LED technology, outputs bright but soft & glareless light;
S-2040: 23W power consumption, equivalent to a 80W halogen bulb;
S-2050: 48W power consumption, equivalent to a 150W halogen bulb;
10%-100% dimmerable
5000K output, 5600K/3200K filter;
Lightweight; cool-touch design.
Product view
Fig 1
Caution
1. Never attempt to open the device. Refer all servicing to
qualified personnel.
2. Never insert anything into the cooling vent to avoid damage
or short circuit.
3. Keep the light away from rain or moisture.
4. Please do not stare at the turned on LED light.
5. Keep the filters clean.
6. When powering through DC-IN socket by S-7104 D-tap
cable, please make sure the power supply's voltage and
power meet the light input requirements.
7. Working temperature: -10 ~40
8. Keep the cooling vent clear to avoid damage.
Clean
Use a soft, dry cloth to clean the LED light. If you clean the
light with soft cloth slightly moistened with neutral detergent,
please dry the surface of the light with a soft, dry cloth. Do
not use a damp cloth or alcohol, gasoline and other solvents
of any kind.
USER MANUAL
SWIT Electronics Co., Ltd.
Fig 2
℃ ℃
1. 5600K filter
2. Barn door
3. 3200K filter
4. Barn door
5. Cooling vent
6. Switch on/off

Specifications

Model S-2040
Input DC 6V-17V
Power Approx. 23W
Beam angle Approx. 50°
Illuminance 900 lx @ 1 meter
Color temp. 5000K itself, with 5600K&3200K filter
Mass
Dimension
Working temp.
Storage temp.
Package
LED light
Cold shoe slot
Power adaptor S-7104
User manual
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
7. Knob
8. Cold shoe mount
9. Dimmer
10. DV mount slot (only S-2040)
11. DC-IN socket
12. Protection cover
S-2050
DC11V-17V
Approx. 48W
Approx. 50°
2200 lx @ 1 meter
Approx. 500g
103×157×84mm
-10 ℃ ~ +40 ℃
-20 ℃ ~ +55 ℃
× 1
1
×
× 1
× 1
