Page 3 Use and instructions book Introduction pag. Chapter 1 Use adjustments pag. Chapter 2 Safety pag. Chapter 3 Checks and adjustments pag. Chapter 4 Maintenance pag. Chapter 5 Warranty pag. ENGLISH...
Page 4 Use and instructions book INTRODUCTION Dear Customer, the bicycle you chose is absolutely reli-able and safe. It is the result of specialized technical researches and qua- lity controls that guarantee reliability and give you the pos- sibility to appreciate safely its performances. The owners manual will help you to optimize the perfor- mances of your bicycle and to keep always under control its efficiency and safety.
Page 5 ENGLISH CH PTER 1 USE ADJUSTMENT Before using the first time the bicycle has to be checked and adjusted according to the characteristics of the owner verifying also his reactions. THE BICYCLE 1 FRAME • 2 TOP TUBE • 3 DOWN TUBE 4 SEAT POST •...
Page 6: Saddle Position
Use and instructions book SADDLE POSITION When riding the big toes have to lean on the centre of the pedal. When the pedal is nearest to the ground your knee has to be lightly bended. Straddle the saddle, lean your heel on the pedal and move Fig.
Page 7 ENGLISH stem in the right position (with 20 Nm). If you have a Ahead set han- dlebar the height cannot be adjusted. In this case you have to operate on the two screws that lock the handlebar (stee- ring) A1 and A2 (fig. 5). You can set the steering flowability Fig.
Page 8 Use and instructions book RIDING YOUR BIKE IN SAFETY CH PTER 2 For a safe use of your bike it is necessary and very impor- tant: - To know the bicycle traffic rules of your country and of the countries where you will ride your bike. - To ride the bicycle following the normal traffic direction, in single file and keeping a straight line.
Page 9: Proper Use
ENGLISH - Braking well in advance gradually to avoid falling and losing your bicycle control, consider that going down-hill there is a decreased grip of the tyres. - Replacing immediately any bicycle components that are damaged. - Making sure that your bicycle is in good overall conditions and providing for maintenance if necessary.
Page 10: Checks And Adjustments
Use and instructions book YPE OF BIKE YPE OF JOURNEY ISTANCE COVERED Sporting, long distance. Asphalted road and pavé RACING BIKE Specific clothing is required Asphalted road and pavé Sporting and tourist, HIGH VELOCITY road medium distance. Sporting and tourist, Asphalted road and pavé, HIGH VELOCITY hybrid medium and long distance.
Page 11: Braking System
ENGLISH WARNING/IMPORTANT: Check the fixture or the position of the tyres particularly after long downhill routes. Using your bike with the recom- mended air pressure in the tyres ensures prolonged safety and lifetime. BRAKING SYSTEM The brakes have to be checked when the bicycle is still. Pull the levers of both brakes towards the handlebar, ensu- re that the levers do not reach/touch the handlebar as this could release the brakes.
Page 12: Brake System Adjustment
Use and instructions book BEFORE RIDING CHECK THE STAND POSITION THAT HAS TO BE COMPLETED RAISED. BRAKE SYSTEM ADJUSTMENT Our bicycles are equipped with four different brake systems: - Disc brake (fig. 9) - Caliper brake (fig. 10) - V-Brake (fig. 11) - Coaster brake When adjusting the Caliper or V-brake system you have to keep a distance of 1/2 mm between the brake pad and the...
Page 13 ENGLISH brake pads has to be adjusted 0,2-0,4 mm working on the relevant screws. The hydraulic brakes are adjusted automatically. WARNING/IMPORTANT: For the best performance the brake pads have to reach the minimum wear. Do not touch the discs when you stop as they overheat when working.
Page 14 Use and instructions book You will find the perfect rhythm by a ratio of 60 and 90 pedal rpm (revolutions per minute). The front and rear derailleur that allow you to change the speed moving the chain from a gear to another is the most used one.
Page 15: Warning /Important
ENGLISH WARNING /IMPORTANT: Initial lever (A) position We suggest to avoid always following combinations as the chain would be out of line and could encounter friction: small front gear with rear small one or big front gear with big rear one (Fig.
Page 16 Use and instructions book FRONT AND REAR DERAILLEUR ADJUSTMENT To adjust the front and rear derailleur, you have to keep your bicycle raised from the ground in order to allow to drive the gears and the shift system keeping the bicycle still. If the gear change operation is not perfect, adjust the ten- sion of the cable through the regulator put on the cable joint...
Page 17: Frame And Fork
ENGLISH The screws are originally adjusted by the producer and cannot be modified during the normal use, so the comple- te front and rear derailleur adjustment has to be done by the dealer. WARNING/IMPORTANT: For the adjustment and maintenance of the shifts you have to contact exclusively your dealer as this operation is done by specialized personnel using specific equipments.
Page 18 Use and instructions book Never use high pressure water jets when washing your bicycle, if the water penetrates into the bearings they could be damaged and loose their qualities. The suspended forks have to be lubricated periodically in order to guarantee a good performance and a long lasting life.
Page 19 ENGLISH The quick release has to be correctly adjusted and fasten- OPEN ed as described here below. To take the wheel out, you have to open the quick release of the side pull brakes or remove the cantilver of V- CLOSED brake arc;...
Page 20 Use and instructions book to the following tightening: front 40 Nm and rear 40 Nm. Then check again. Particularly verify if the nuts fixing the wheels to the threaded hub axle is well fastened or if the quick release lever that allows to put the wheel in and off without using any equip- ment is well closed (Fig.
Page 21 ENGLISH around the rim. If the track is not evident, it means that the braking surface is worn and it is necessary to replace the rim. After making all these checks , if you note any anomalies or if you have any doubt about the status of the wheels, con- tact your dealer to get assistance.
Page 22 Follow carefully the instructions to avoid to damage the pedals and the crank thread and check the wear limit of the shoe plates. AFTER USING YOUR FERRINI BICYCLE A correct and periodical cleaning of your bicycle guarantee you an excellent functioning.
Page 23: Maintenance And Lubrication
ENGLISH MAINTENANCE AND LUBRICATION CH PTER 4 We suggest a periodical maintenance of your bicycle to get always the best performances and guarantee your safety. Book right now your first check by the dealer. After two months from the purchase date or anyway after riding 200-400 Km it is necessary to do a first check as the running-in is finished and your bicycle should be already settled.
Page 24 Use and instructions book OMPONENTS AINTENANCE RODUCT TO USE OW OFTEN Water + protective polishing Every 1-6 months Frame Check and cleaning detergent for frames Check, lubrication and Every 15 days Fork See supplier manual cleaning Cloth with gentle Once a month Wheels Check and cleaning cleaning products...
Page 25 ENGLISH TIGHTENING OMPONENTS Nut/Wing front hub Nm 40-45 Nut/wing back hub Nm 40-45 Saddle clamp nut Nm 20-24 Brake fixing bolt Nm 7-10 Brake shoe fixing bolt Nm 5-8 Saddle post tube bolt Nm 10-14 Handlebar expander bolt Nm 18-20 Rear derailleur bolt Nm 8-15 Front derailleur bolt...
Page 26 Use and instructions book The purchaser right of cancel the contract, ask for damages refund or for a price reduction are out of the question. Manpower, transport and other costs originating from defects are not covered by the warranty. To enjoy the use of the warranty you have to contact exclu- sively your dealer and ask him for the assistance showing the purchase receipt.
Page 27: Assembly Of Training Wheels
ENGLISH COMPLIANCES To guarantee the quality of this bicycle, the design and the manufacturing are done in compliance with the most upda- ted EN 14764, EN 14765, EN 14766, EN 14781 European Norms. LIFETIME The disposal of the components that have finished their lifetime has to be done by the authorized waste dump.
Page 28 Use and instructions book Warranty...
Page 29: Warranty Conditions
2) This guarantee is valid for a period of 24 (twentyfour) months, starting from the date of purchase from the Ferrini retailer for the structural breakges of the suspended frames. 24 (twentyfour) months for other models. 3) Maxtec LTD is recommended to provide free of charge on ex factory basis the defective parts due to materials or manufactoring flaw.
Page 30 7) The repairs or the replacement of defective parts can be done by Ferrini premises, by the dealer or by the customer according to Ferrini decision. t all events, the transport costs and risks will be charged to the customer as well as labour costs.
Page 31 ENGLISH FOR THE WARRANTY TO HAVE VALIDITY, FILL OUT AND MAIL THIS COUPON WITHIN 10 DAYS.
Page 32 Use and instructions book...
Page 33 ENGLISH For the Retailer Ferrini Warranty...
Page 34 Use and instructions book FOR THE CUSTOMER TO KEEP Purchased model Frame number Date of sale Customer name ddress Zip code City Country Telephone E-mail Furthermore I will give my consensus on the treatment and/or communication of all the data relative to the execution of all the operations. Customer signature...
Page 35 ENGLISH 1 - FERRINI SERVICE PLAN - Km 500 / 0 - 12 month Model Annual service to be done • Check of shock mounts incl. lubricating the Year bushings Size • Check of swingarm pivot incl. axle and mounts Frame •...
Page 36 Use and instructions book 2 - FERRINI SERVICE PLAN - Km 3.000 or 2 year Model Annual service to be done • Check of shock mounts incl. lubricating the Year bushings Size • Check of swingarm pivot incl. axle and mounts Frame •...
Page 37 ENGLISH 3 - FERRINI SERVICE PLAN - Km 6.000 or 3 year Model Annual service to be done • Check of shock mounts incl. lubricating the Year bushings Size • Check of swingarm pivot incl. axle and mounts Frame • Check of rear shock according to the enclosed...
Page 38 Use and instructions book 4 - FERRINI SERVICE PLAN - Km 9.000 or 4 year Model Annual service to be done • Check of shock mounts incl. lubricating the Year bushings Size • Check of swingarm pivot incl. axle and mounts Frame •...
Page 39 ENGLISH 5 - FERRINI SERVICE PLAN - Km 12.000 or 5 year Model Annual service to be done • Check of shock mounts incl. lubricating the Year bushings Size • Check of swingarm pivot incl. axle and mounts Frame • Check of rear shock according to the enclosed...
Page 40 NOTES...
Page 41 NOTES...
Page 42 w w w . f e r r i n i - b i k e s . c o m 1, Goliamokonarsko Shosse Str. - 4027 Plovdiv ulgaria tel. ++359 32 921 909 - fax ++359 32 921 921 info@maxtecbike.eu - www.maxtecbike.eu a part of the group...
