WWW.TALOSSECURITY.COM
Head Office
705 Pleasant Valley Drive
Springboro, Ohio 45066 USA
937-550-0239 Office
888-980-8042 Toll Free
Instruction Guide
Mobile Black Box DVR
MBB-10
The Company is not responsible for any consequential damage in connection with use of the
Product as the Product is not contributing to a car accident directly or indirectly. The
Company is responsible for defect on the Product itself only. Product settings while driving is
dangerous and may lead to a road accident and 'Event' management may not function under
a certain type of impact.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Talos Security MBB-10
- Page 1 Instruction Guide WWW.TALOSSECURITY.COM Mobile Black Box DVR Head Office 705 Pleasant Valley Drive MBB-10 Springboro, Ohio 45066 USA 937-550-0239 Office 888-980-8042 Toll Free The Company is not responsible for any consequential damage in connection with use of the Product as the Product is not contributing to a car accident directly or indirectly. The Company is responsible for defect on the Product itself only.
-
Page 2: Table Of Contents
Caution for Safety Product Features Components Details Contents How to Insert Card Main Functions Check on Terminal Status Program Execution Program Installation Program Manual How To Play Recorded Firmware Update Measure for Disorder Product Warranty... -
Page 3: Caution For Safety
Safety Cautions This chapter provides safety information to prevent misuse or abuse of the Product which may lead to the risks of personal injuries or physical damages by electric shock, fire or explosion. Please read this chapter before use. ★ Contents of this User’s Manual may differ from one to another version of CARPA-10 software, and are subject to change without prior notice to users. - Page 4 Warning Do not install, dismantle or convert Do not change the installation the Product at your will. It may position of the Product. It may cause product breakdown, electric result in creation of blind spots in shock or fire. Please contact the recording, and you may apportion Service Center for repair.
- Page 5 Caution Do not remove the SD card while Do not use water, benzene or the power is connected. It may alcohol to clean the Product. It cause breakdown of the card. may cause Product failure. Use a dry soft cloth. Do not exert excessive impact on Do not touch the SD card with oily or wet hand.
- Page 6 Cautions 1. Do not install, dismantle or convert the Product at your will. 2. If any part is used in addition to the parts provided by the Company, please use the original or the Company recommended parts only. 3. Do not operate the Product outside the recommended power range. 4.
-
Page 7: Product Features
Product Features This Product is a device (the black box) to be installed inside the car, for recording of sounds and views at the front of the car and inside the car to secure evidences of road accident, parking damage, theft or violence of passengers as well as to induce safe driving. -
Page 8: Components Details
Components Name Description Inside LED Inner side Red, Blue, Purple LED Steady & Flashing Recording sensitivity control by Automatically illumination sensor LED Brightness sensor detected. Camera Vehicle’s front side recording (1.3Mega CMOS) SD Card slot To save recorded data into a SD card Emergency record Button Driver Panic &... -
Page 9: Contents
Product Content User’s Manual Instruction Guide Digital Video Recorder CARPA-10 The Company is not responsible for any consequential damage in connection with use of the The Company is not responsible for any consequential damage in connection with use of the Product as the Product is not contributing to a car accident directly or indirectly. -
Page 10: How To Insert Card
To Insert Card Insert the SD card before supplying power. The cut corner of the card should face downward when inserting. Lower the slot cover and insert the card to the end. (you will feel the card locking when fully inserted.) Caution Insert the card to the end to avoid card failure. -
Page 11: Main Functions
Main Functions Video recording SD memory card (2GB~32GB Power jack Power jack Options (sold separately) Front side LED Inner side LED ※ Insert a SD card, connect the power supply, and the front side recording will begin. (Red color LED flashing beeper soundLED flashing(Inner: Purple, front: Blue) ※... - Page 12 Emergency Saving Switch Installation on Mount (GPS Antenna) Connection Jack Inner side LED If emergency saving switch (REC button) is pressed, Installation on Mount with a built-in GPS relevant video is saved as event and will not be Tighten connection bolts of main body and mount. deleted unless random deletion is done.
- Page 13 DC Fuse power cable(Option) Power jack (DC FUSE POWER CABLE) Shock sensor sees collision while driving as main issue. Since shock sensor is weak during parking lot collision, compared with collision while driving, to supplement its weakness, there is a function, with which user can adjust sensor sensitivity.
- Page 14 AV Out Function ( Only after perchasing AV CABLE ) Connect the power after pressing emergency Navigation Cable AV CABLE (option sales) saving button Current screen can be seen at navigator (Monitor Output: PAL / NTSC compatible) Audio Guide: Tti~ Dick Dick(Beeper sound) After audio guide, take your hand off...
-
Page 15: Check On Terminal Status
Device Status Check (Check LED blinking display part) Rear Front Status Voice Message Blue Blue Steady Flashing Steady Flashing Steady Flashing Power ON Red LED inside is turned on. Continuous Recording Violet LED inside and Blue LED outside blink. Event Recording Violet LED inside and Blue LED outside are turned on. -
Page 16: Program Execution
PC Software Recommended PC Specification CPU: Pentium 4/1 GHz or up Memory: 512 MB RAM or up OS : WINDOWS XP, VISTA(partial) HDD : 500MB or up support Company Logo Minimization / End Car Plate Number and Date & Time List Deleting File Opening File List... -
Page 17: Program Installation
PC Software Installation CARPA PC Software is provide insert SD card file folder. If you removed pc software then please download on our website (www.dstelecom.co.kr) Installation is complete. The carpa-10 icon is created on the background screen on the PC... - Page 18 Playback List Playback List To delete all playback lists ▪ 1View file location. / Select Directory ▪ 2 The selected files can be added to a Playlist. ▪ 3 View all files / Sort of Event files ▪ 4 If a file list exists, it is shown in the blue box area. ▪...
-
Page 19: Program Manual
To run the program To select a file to playback Select file location ▶ Select a mobile disk (SD card). To open a file ▶ Select file location ▶ Select a mobile disk. ▶ Confirm ▶ Select a movie file to playback and click on the [▶] button. The selected movie file is added to a Playback List. - Page 20 To identify type of recording files Files are saved at 1-minute intervals by hour and day for easy retrieval. Files are also designated with letter (General) for normal recording, (Event) for event (such as accident and impact) and (Button) for emergency outdoor recording by button, for easy search.
- Page 21 Program Security (ON/OFF) close the window password log-in screen In case that password is created at Setting, password log-in screen appears before the program begins.
- Page 22 Speed Display Overlap G-sensor X,Y,Z information Compatible with Google Map With maps (Google Map), satellite and superposition information, driving route information is provided. Driving speed The built-in G-sensor enables detection of impact, acceleration Use of Google Map is recommended. or braking to be automatically recorded and saved. The ‘Map View’...
-
Page 23: How To Play Recorded
File convert & others Select the carpa-10 icon to execute the program Print Version Info File Save to print the screen to view the software version During playback, the file can be saved the instant printing function on a PC as well. / The file is converted to an mp4 file and saved. - Page 24 File Capture Screen Capture: to capture the current screen. The saved file is added to the hard Control of Playback speed and Volume disk. Control of Playback Speed: To control the speed to x6 slow, x4 slow, x2 slow, normal, x2 fast, 4x fast or 6x fast. Volume Control: in 9 levels (including ‘Mute’) / Select level 1 for mute and level 9 for the highest volume.
- Page 25 Program Setup Sensitivity Control Function: Sensitivity is set up. The higher the number is, the more sensitive it is. 1. least sensitive, 5 most sensitive. Event may not occur depending upon sensitivity while on parking. Set up sensitivity properly by vehicle type and user. Time Setup: input faster than present time by one minute, and save at...
-
Page 26: Firmware Update
Firmware Update Caution Do not disconnect the cigar Before Firmware Upgrade, format the SD memory card. jack or turn off the ignition Remove the SD card from the Main Body and place it on a card reader. during upgrade. Do not Connect the card reader to the USB port on a PC. -
Page 27: Measure For Disorder
Trouble Shooting Trouble Trouble Shooting Remarks Power failure 1. Check if the power cable at the rear of the Product is properly connected. If the trouble persists, please 2. Check if the power fuse inside the fuse box in the car that connects between the car contact the Service Center. -
Page 28: Product Warranty
Product Warranty Customer Service ※ • DS Telecom will provide product repair and replacement services within the warranty period in accordance with the consumer protection regulations (the Korea Fair Trade Commission Directive 2008-3) • The warranty services will be provided by the Company’s authorized service centers at the request of customers. •... - Page 29 Complementary Service Fee Paying Services In the event of product failure within 1 year (the warranty period) from the date of 1) Non-defective Product purchase, the Company will provide complementary repair service. If the product is Services for non-defective product are subject to service fees. Please read the User’s converted to a commercial use, the warranty period will be reduced to 6 months.
