Service Manual

32PFL3505D/F7
32PFL3515D/F7
TYPE B
32PFL3505D/F7
TYPE C
32PFL3505D/F7
This service manual contains information of different types of models.
Make sure to refer to the section describing your model.
© 2010 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
with the
design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way
without the express written consent of Funai. All other trademarks used herein remain the exclusive property of
their respective owners. Nothing contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any
other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights
to the fullest extent of the law.

Contents

PHILIPS
(Serial No.: DS1A, DS2A, DS3A, YA1A)
PHILIPS
(Serial No.: YA1A)
PHILIPS
(Serial No.: DS4A)
PHILIPS
(Serial No.: DS8A, DS9A, YA2A, YA4A)
32" LCD TV
chassis PL10.3
101202

Advertisement

Table of Contents
loading

Related Manuals for Philips 32PFL3505D/F7

Summary of Contents for Philips 32PFL3505D/F7

  • Page 1: Service Manual

    32” LCD TV chassis PL10.3 Service Manual Contents TYPE A 32PFL3505D/F7 PHILIPS (Serial No.: DS1A, DS2A, DS3A, YA1A) 32PFL3515D/F7 PHILIPS (Serial No.: YA1A) TYPE B 32PFL3505D/F7 PHILIPS (Serial No.: DS4A) TYPE C 32PFL3505D/F7 PHILIPS (Serial No.: DS8A, DS9A, YA2A, YA4A) This service manual contains information of different types of models.

  • Page 2: Important Safety Notice

    IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all P&F Equipment. The service procedures recommended by P&F and described in this service manual are effective methods of performing service operations. Some of these service special tools should be used when and as recommended.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Specifications ................1-1 Important Safety Precautions .

  • Page 4: Specifications

    SPECIFICATIONS < TUNER / NTSC > ANT. Input ---------------------- 75 Ω Unbal., F type Description Condition Unit Nominal Limit 1. AFT Pull-In Range ±2.3 ±2.1 TV.ch.4 dBµ 2. Synchronizing Sens. CA.ch.31 dBµ CA.ch.87 dBµ < TUNER / ATSC > Description Condition Unit Nominal...

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
  • Page 6 3. Design Alteration Warning - Do not alter or add 7. Product Safety Notice - Some electrical and to the mechanical or electrical design of this TV mechanical parts have special safety-related receiver. Design alterations and additions, characteristics which are often not evident from including, but not limited to circuit modifications visual inspection, nor can the protection they give and the addition of items such as auxiliary audio...
  • Page 7 Precautions during Servicing A. Parts identified by the # symbol are critical for safety. Replace only with part number specified. B. In addition to safety, other parts and assemblies are specified for conformance with regulations applying to spurious radiation. These must also be replaced only with specified replacements.
  • Page 8 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original positions. Afterwards, perform the following tests and confirm the specified values in order to verify compliance with safety standards. 1.

  • Page 9: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications How to Remove / Install Flat Pack-IC 1. The output pin of the 3 pin Regulator ICs is 1. Removal indicated as shown. With Hot-Air Flat Pack-IC Desoldering Machine: Top View 1. Prepare the hot-air flat pack-IC desoldering Bottom View machine, then apply hot air to the Flat Pack-IC Input...
  • Page 10 3. The flat pack-IC on the CBA is affixed with glue, so With Soldering Iron: be careful not to break or damage the foil of each 1. Using desoldering braid, remove the solder from pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 11 2. Installation With Iron Wire: 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the CBA flux which is applied to all pins of the flat pack-IC, so you can install a replacement flat pack-IC more you can remove it easily.
  • Page 12 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.

  • Page 13: Type A, Type B

    CABINET DISASSEMBLY INSTRUCTIONS [TYPE A, TYPE B] 1. Disassembly Flowchart Removal Step/ This flowchart indicates the disassembly steps for the Remove/*Unhook/ Loc. Part Fig. Unlock/Release/ cabinet parts, and the CBA in order to gain access to Note Unplug/Unclamp/ item(s) to be serviced. When reassembling, follow the Desolder steps in reverse order.
  • Page 14 (S-2) [2] Rear Assembly (S-3) (S-3) (S-2) (S-2) (S-2) (S-4) [1] Stand Assembly (S-1) Fig. D1 PL10.3DC...
  • Page 15 [3] Inverter CBA (S-5) (S-5) [4] Jack CBA (S-7) (S-10) Shield Box (S-7) (S-6) (S-9) [7] Digital Main (S-7) CBA Unit [5] Power Supply CBA (S-9) (S-8) [6] Jack Holder Fig. D2 PL10.3DC...
  • Page 16 [14] Front Cabinet [13] Speaker [12] Speaker (S-14) Holder (S-13) (S-14) [13] Speaker (S-12) [12] Speaker (S-13) Holder [11] LCD Module [10] Function CBA Assembly [8] Junction (S-12) (S-11) [9] IR Sensor CBA Fig. D3 PL10.3DC...
  • Page 17 TV Cable Wiring Diagram Inverter CBA Jack CN1050 Power Supply CBA CL701B CN1100 CN1001 CN201 CN1150 CL701A CN602 CN1900 CN302 CN1200 CN1003 AC CORD CN301 CN801 CN101 CN802 To LCD Module Assembly To Speaker Digital Main Junction CBA Unit CN151 CL102A CN3702 IR Sensor CBA...
  • Page 18 [TYPE C] 1. Disassembly Flowchart Removal Step/ This flowchart indicates the disassembly steps for the Remove/*Unhook/ Loc. Part Fig. Unlock/Release/ cabinet parts, and the CBA in order to gain access to Note Unplug/Unclamp/ item(s) to be serviced. When reassembling, follow the Desolder steps in reverse order.
  • Page 19 (S-2) [2] Rear Assembly (S-3) (S-3) (S-2) (S-2) (S-2) (S-4) [1] Stand Assembly (S-1) Fig. D1 PL10.3(A01FU)DC...
  • Page 20 [3] Inverter CBA (S-5) (S-5) [4] Jack CBA (S-7) (S-10) Shield Box (S-7) (S-6) (S-9) [7] Digital Main (S-7) CBA Unit [5] Power Supply CBA (S-9) (S-8) [6] Jack Holder Fig. D2 PL10.3(A01FU)DC...
  • Page 21 [13] Front Cabinet [12] Speaker [11] Speaker (S-14) Holder (S-13) (S-14) [13] Speaker (S-12) [11] Speaker (S-13) Holder [10] LCD Module [9] Function CBA Assembly (S-12) (S-11) [8] IR Sensor CBA Fig. D3 PL10.3(A01FU)DC...
  • Page 22 TV Cable Wiring Diagram Inverter CBA Jack CN1050 Power Supply CBA CL701B CN1100 CN1001 CN201 CN1150 CL701A CN602 CN1900 CN302 CN1200 CN1003 AC CORD CN301 CN801 CN101 CN802 To LCD Module Assembly To Speaker Digital Main CBA Unit CN3702 IR Sensor CBA Function CBA CL103B CN3701...

  • Page 23: Electrical Adjustment Instructions

    ELECTRICAL ADJUSTMENT INSTRUCTIONS General Note: “CBA” is abbreviation for How to set up the service mode: “Circuit Board Assembly.” Service mode: Note: Electrical adjustments are required after 1. Turn the power on. replacing circuit components and certain mechanical parts. It is important to perform 2.

  • Page 24: Type A

    1. Purity Check Mode 2. VCOM Adjustment This mode cycles through full-screen displays of red, Test Point Adj. Point green, blue, and white to check for non-active pixels. [CHANNEL UP/DOWN ] Screen 1. Enter the Service mode. buttons 2. Each time pressing [7] button on the remote M.

  • Page 25: White Balance Adjustment

    The White Balance Adjustment should be 5. [CUTOFF] Press [1] button to select “COR” for Red Cutoff performed when replacing the LCD Panel adjustment. Press [3] button to select “COB” for or Digital Main CBA. Blue Cutoff adjustment. [DRIVE] 3. White Balance Adjustment Press [4] button to select “DR”...

  • Page 26: How To Initialize The Lcd Tv

    HOW TO INITIALIZE THE LCD TV The purpose of initialization is to place the set in a new out of box condition. The customer will be prompted to select a language and program channels after the set has been initialized. To put the program back at the factory-default, initialize the LCD TV using the following procedure.

  • Page 27: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE Equipment Required The appearance shown in *1 is described as follows. Appearance State a. USB storage device Downloading the firmware from b. Remote Control Unit Downloading... the USB storage device. Writing the downloaded firmware Writing... Firmware Update Procedure in flash memory.

  • Page 28: Troubleshooting

    TROUBLESHOOTING [ Power Supply Section ] FLOW CHART NO.1 The power cannot be turned on. Is the fuse (F601) normal? See FLOW CHART No.2 <The fuse blows out.> Check if there is any leak or short-circuiting on the primary circuit component, and service it if defective. (C605, D601, D602, D603, D604, Q601, Q602, Q603, Q604, IC602, T601) Is the AL+33V line voltage normal?
  • Page 29 FLOW CHART NO.6 LCD+24.5V is not output. FLOW CHART NO.7 LCD+16V is not output. FLOW CHART NO.8 INV+16V is not output. FLOW CHART NO.9 P-ON+7V is not output. PL10.3TR...

  • Page 30: Flow Chart No

    FLOW CHART NO.10 P-ON+5V is not output. (LCD+16V is outputted normally.) Replace Q641. FLOW CHART NO.11 TUNER+5V is not output. (LCD+16V is outputted normally.) Replace Q640. FLOW CHART NO.12 AL+13V is not output. Is approximately +13V voltage supplied to the cathode of D641 and D642? FLOW CHART NO.13 P-ON+3V is not output.
  • Page 31 FLOW CHART NO.14 P-ON+3.3V is not output. FLOW CHART NO.15 P-ON+9V is not output. (LCD+16V is outputted normally.) Replace Q642. FLOW CHART NO.16 AL+3.3V is not output. FLOW CHART NO.17 LCD-6.8V is not output. Replace Q211. PL10.3TR...
  • Page 32 [ Video Signal Section ] FLOW CHART NO.1 The key operation is not functioning. Re-install the switches (SW101B, SW103B~SW107B) correctly or replace the poor switch. Check the switches (SW101B, SW103B~SW107B) and their periphery, and service it if defective. Replace Digital Main CBA Unit. FLOW CHART NO.2 No operation is possible from the remote control unit.
  • Page 33 FLOW CHART NO.4 Picture does not appear normally.(Tuner input) FLOW CHART NO.5 Picture does not appear normally.(S-Video input) Pin(6): S-VIDEO-C Pin(8): S-VIDEO-Y FLOW CHART NO.6 Picture does not appear normally.(Y/Pb/Pr input) Pin(15): VIDEO-Y Pin(17): VIDEO-Pb Pin(19): VIDEO-Pr PL10.3TR...
  • Page 34 [ Audio Signal Section ] FLOW CHART NO.1 Audio is not outputted normally.(Audio input) Check the line between Pin(2, 15) of IC771 and input terminal(JK753, JK754), and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L)
  • Page 35 FLOW CHART NO.2 Audio is not outputted normally.(Component Audio input) Check the line between Pin(4, 11) of IC771 and input terminal(JK741, JK742), and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L) Check SP801,SP802 and their periphery circuit, CN802: SP(R) and service it if defective.
  • Page 36 FLOW CHART NO.3 Audio is not outputted normally.(Tuner input) Check TU301 and their periphery circuit, and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L) Check SP801,SP802 and their periphery circuit, CN802: SP(R) and service it if defective.

  • Page 37: Block Diagrams

    BLOCK DIAGRAMS [TYPE A] 1. System Control Block Diagram PL10.3ABLS...
  • Page 38 2. Video Block Diagram PL10.3BLV...
  • Page 39 3. Audio Block Diagram PL10.3BLA...
  • Page 40 4. Digital Signal Process Block Diagram PL10.3ABLD...
  • Page 41 5. Inverter Block Diagram PL10.3BLINV...
  • Page 42 6. Power Supply Block Diagram PL10.3BLP...

  • Page 43: Type B]

    [TYPE B] 1. System Control Block Diagram PL10.3BBLS...
  • Page 44 2. Video Block Diagram PL10.3BLV...
  • Page 45 3. Audio Block Diagram PL10.3BLA...
  • Page 46 4. Digital Signal Process Block Diagram PL10.3BBLD 9-10...
  • Page 47 5. Inverter Block Diagram 9-11 PL10.3BLINV...
  • Page 48 6. Power Supply Block Diagram 9-12 PL10.3BLP...

  • Page 49: Type C]

    [TYPE C] 1. System Control Block Diagram 9-13 PL10.3CBLS...
  • Page 50 2. Video Block Diagram 9-14 PL10.3BLV...
  • Page 51 3. Audio Block Diagram 9-15 PL10.3BLA...
  • Page 52 4. Digital Signal Process Block Diagram PL10.3BBLD 9-16...
  • Page 53 5. Inverter Block Diagram 9-17 PL10.3BLINV...
  • Page 54 6. Power Supply Block Diagram 9-18 PL10.3BLP...

  • Page 55: Schematic Diagrams / Cba And Test Points

    SCHEMATIC DIAGRAMS / CBA AND TEST POINTS Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
  • Page 56 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE_A,_V FUSE. ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE MÊME TYPE DE_A,_V. 2.
  • Page 57 Power Supply 1 Schematic Diagram CAUTION ! NOTE: Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. The voltage for parts in hot circuit is measured using CAUTION ! : For continued protection against risk of fire, If Main Fuse (F601) is blown , check to see that all components in the power supply hot GND as a common terminal.
  • Page 58 Power Supply 2 Schematic Diagram 10-4 PL10.3SCP2...
  • Page 59 Power Supply 3 & Jack Schematic Diagram 10-5 PL10.3SCP3...
  • Page 60 Power Supply 4 Schematic Diagram PL10.3SCP4 10-6...
  • Page 61 Inverter Schematic Diagram NOTE: The voltage for parts in hot circuit is measured using hot GND as a common terminal. PL10.3SCINV 10-7...
  • Page 62 Function Schematic Diagram 10-8 PL10.3SCF...
  • Page 63 IR Sensor & Junction Schematic Diagram PL10.3SCIR 10-9...
  • Page 64 Digital Main 1 Schematic Diagram [TYPE A] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-10 PL10.3SCD1...
  • Page 65 Digital Main 2 Schematic Diagram [TYPE A] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-11 PL10.3SCD2...
  • Page 66 Digital Main 3 Schematic Diagram [TYPE A] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-12 PL10.3SCD3...
  • Page 67 Digital Main 4 Schematic Diagram [TYPE A] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. PL10.3SCD4 10-13...
  • Page 68 Digital Main 5 Schematic Diagram [TYPE A] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. PL10.3SCD5 10-14...
  • Page 69 Digital Main 1 Schematic Diagram [TYPE B, TYPE C] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-15 PL10.3_2SCD1...
  • Page 70 Digital Main 2 Schematic Diagram [TYPE B, TYPE C] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-16 PL10.3_2SCD2...
  • Page 71 Digital Main 3 Schematic Diagram [TYPE B, TYPE C] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. 10-17 PL10.3_2SCD3...
  • Page 72 Digital Main 4 Schematic Diagram [TYPE B, TYPE C] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. PL10.3_2SCD4 10-18...
  • Page 73 Digital Main 5 Schematic Diagram [TYPE B, TYPE C] 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section. PL10.3_2SCD5 10-19...

  • Page 74: Troubleshooting

    Power Supply CBA & Jack CBA Top View Because a hot chassis ground is present in the power supply CAUTION ! circuit, an isolation transformer must be used when repairing. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. CAUTION ! : For continued protection against risk of fire, Also, in order to have the ability to increase the input slowly,...
  • Page 75 Power Supply CBA & Jack CBA Bottom View CAUTION ! Because a hot chassis ground is present in the power supply Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. CAUTION ! : For continued protection against risk of fire, circuit, an isolation transformer must be used when repairing.
  • Page 76 Inverter CBA, Function CBA, IR Sensor CBA & Junction CBA Top View Because a hot chassis ground is present in the power supply NOTE: circuit, an isolation transformer must be used when repairing. The voltage for parts in hot circuit is measured using Also, in order to have the ability to increase the input slowly, hot GND as a common terminal.
  • Page 77 Inverter CBA, Function CBA, IR Sensor CBA & Junction CBA Bottom View Because a hot chassis ground is present in the power supply NOTE: circuit, an isolation transformer must be used when repairing. The voltage for parts in hot circuit is measured using Also, in order to have the ability to increase the input slowly, hot GND as a common terminal.

  • Page 78: Waveforms

    WAVEFORMS WF1 ~ WF7 = Waveforms to be observed at Waveform check points. (Shown in Schematic Diagram.) Input: NTSC Color Bar Signal (with 1kHz Audio Signal) Pin 4 of CN302 Pin 17 of CN302 CVBS 0.2V 20µs VIDEO-Pb 0.2V 20µs Pin 8 of CN302 Pin 19 of CN302 20µs...

  • Page 79: Wiring Diagram

    WIRING DIAGRAM [TYPE A, TYPE B] 12-1 PL10.3AWI...
  • Page 80 [TYPE C] 12-2 PL10.3CWI...

  • Page 81: Exploded Views

    EXPLODED VIEWS Cabinet 32PFL3505D/F7 (Serial No. : YA1A, YA2A, YA4A), 32PFL3515D/F7 (Serial No. : YA1A) 32PFL3505D/F7 (Serial No. : DS1A, DS2A, DS3A, DS4A, DS8A, DS9A) See Electrical Parts List for parts with this mark. 32PFL3505D/F7 (Serial No. : YA1A, YA2A, YA4A), 32PFL3515D/F7 (Serial No.
  • Page 82 Packing 32PFL3505D/F7 (Serial No. : DS1A, DS2A, DS3A, DS4A, DS8A, DS9A) Tape Stand Assembly 32PFL3505D/F7 (Serial No. : YA1A, YA2A, YA4A), 32PFL3515D/F7 (Serial No. : YA1A) X10 X12 Packing Tape 32PFL3505D/F7 (Serial No. : YA1A, YA2A, YA4A), 32PFL3515D/F7 (Serial No. : YA1A) Some Ref.
  • Page 83 PARTS LIST [32PFL3505D/F7 (Serial No. : DS1A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. QUICK START GUIDE A01F2UH 1EMN25660 Before replacing any of these components, read...

  • Page 84: Electrical Parts

    Electrical Parts PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. C501 ELECTROLYTIC CAP . 100µF/25V M CE1EMASDL101 Before replacing any of these components, read C601# CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004 carefully the product safety notice in this service C602#...
  • Page 85 Ref. No. Description Part No. Ref. No. Description Part No. C804 CHIP CERAMIC CAP .(1608) B K 0.1µF/25V CHD1EK30B104 D203 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 C805 CHIP CERAMIC CAP .(1608) CH J 1000pF/50V CHD1JJ3CH102 D204 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036 C806 CHIP CERAMIC CAP .(1608) B K 0.47µF/25V CHD1EK30B474 D205...
  • Page 86 Ref. No. Description Part No. Ref. No. Description Part No. D659 DIODE ZENER 5V6BSA-T26 NDTA5R6BST26 Q640 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F D660 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 Q641 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F D661 DIODE FR154 NDLZ000FR154 Q642 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P D662 DIODE FR154 NDLZ000FR154...
  • Page 87 Ref. No. Description Part No. Ref. No. Description Part No. CHIP RES. 1/10W J 47k Ω RES CARBON FILM T 1/4W J 10 Ω R403 RRXAJR5Z0473 R678 RCX4100T1001 CHIP RES. 1/10W J 22k Ω CHIP RES. 1/10W F 3.6k Ω R404 RRXAJR5Z0223 R679...
  • Page 88 JACK CBA(MPW-B) Ref. No. Description Part No. CHIP RES.(1608) 1/10W 0 Ω R875 RRXAZR5Z0000 Ref. No. Description Part No. CHIP RES.(1608) 1/10W 0 Ω R876 RRXAZR5Z0000 JACK CBA(MPW-B) ---------- CHIP RES. 1/10W J 1k Ω R877 RRXAJR5Z0102 Consists of the following: RES CARBON FILM T 1/4W J 1.0k Ω...
  • Page 89 Ref. No. Description Part No. Ref. No. Description Part No. C1065 CAP CERAMIC HV 15pF/6.3KV/SL/J CCA1500MR001 CN1100# CONNECTOR/JACK 1747386-1 JB17J02AP002 C1066 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061 CN1150# CONNECTOR/JACK 1747386-1 JB17J02AP002 C1067 ELECTROLYTIC CAP . 10µF/50V M CE1JMASDL100 CN1200# CONNECTOR/JACK 1747386-1 JB17J02AP002 C1068 CHIP CERAMIC CAP .(1608) B K 0.01µF/50V...
  • Page 90 Ref. No. Description Part No. Ref. No. Description Part No. D1214 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 Q1803 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P D1215 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 Q1804 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P D1216 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 Q1815 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F D1217 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133...
  • Page 91 Ref. No. Description Part No. Ref. No. Description Part No. CHIP RES. 1/10W J 20k Ω RES CARBON FILM T 1/4W J 4.7k Ω R1111 RRXAJR5Z0203 R1803 RCX4472T1001 CHIP RES. 1/10W J 390 Ω RES CARBON FILM T 1/4W J 1.2 Ω R1112 RRXAJR5Z0391 R1804...
  • Page 92 FUNCTION CBA Ref. No. Description Part No. FUNCTION CBA ---------- Consists of the following: CAPACITOR C108 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062 RESISTORS RES CARBON FILM T 1/4W J 220 Ω R108 RCX4221T1001 RES CARBON FILM T 1/4W G 10k Ω R109 RCX4103T1002 RES CARBON FILM T 1/4W G 4.7k Ω...
  • Page 93 PARTS LIST [32PFL3505D/F7 (Serial No. : DS2A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 94 Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) There are no different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A). Refer to the parts list for the original model 32PFL3505D/F7 (Serial No. : DS1A). 20100507...
  • Page 95 PARTS LIST [32PFL3505D/F7 (Serial No. : DS4A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 96 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. DIGITAL MAIN CBA UNIT A01FDMMA-003 MPW CBA A01FDMPWS001 POWER SUPPLY CBA(MPW-A) ---------- D205...
  • Page 97 PARTS LIST [32PFL3505D/F7 (Serial No. : DS8A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 98 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. DIGITAL MAIN CBA UNIT A01FDMMA-003 MPW CBA A01FDMPWS002 POWER SUPPLY CBA(MPW-A) ---------- CN101...
  • Page 99 PARTS LIST [32PFL3505D/F7 (Serial No. : DS9A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 100 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. DIGITAL MAIN CBA UNIT A01FDMMA-003 MPW CBA A01FDMPWS002 POWER SUPPLY CBA(MPW-A) ---------- CN101...
  • Page 101 PARTS LIST [32PFL3505D/F7 (Serial No. : YA1A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 102 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. INVERTER ASSEMBLY A01F9M1V-001 Consists of the following INVERTER CBA A01F9M1V-001-IV ------------------------------------------------------------- ------------------------------------...
  • Page 103 PARTS LIST [32PFL3505D/F7 (Serial No. : YA2A)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing.
  • Page 104 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. DIGITAL MAIN CBA UNIT A01FDMMA-003 MPW CBA A01FDMPWS002 POWER SUPPLY CBA(MPW-A) ---------- CN101...
  • Page 105 Don't degrade the safety of the product through improper servicing. NOTE: Parts that are not assigned part numbers (---------) are not available. Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. REAR CABINET ASSEMBLY A01F9MZ...
  • Page 106 C..±0.25% D..±0.5% F..±1% G..±2% J..±5% K..±10% M..±20% N..±30% Z..+80/-20% Different parts from the original model 32PFL3505D/F7 (Serial No. : DS1A) Ref. No. Description Part No. INVERTER ASSEMBLY A01F9M1V-001 Consists of the following INVERTER CBA A01F9M1V-001-IV ------------------------------------------------------------- -----------------------------------...

  • Page 107: Revision History

    REVISION HISTORY Chassis PL10.3 • 2009-11-26 32PFL3505D/F7 (Serial No. : DS1A**********) added • 2010-02-10 32PFL3505D/F7 (Serial No. : DS1A**********) : B44 is added. • 2010-05-14 32PFL3505D/F7 (Serial No. : DS2A**********) added • 2010-05-14 32PFL3505D/F7 (Serial No. : YA1A**********) added • 2010-05-14 32PFL3515D/F7 (Serial No.
  • Page 108 COMPARISON LIST OF MODEL NAME Chassis PL10.3 32PFL3505D/F7 (DS1A) A01F2UH (DS2A) A01FBUH (DS3A) A01FCUH (DS4A) A01FDUH (DS8A) A01FDUH (DS9A) A0RF2UH (YA1A) A01F9MF (YA2A) A01FUMF (YA4A) A0RF3MF 32PFL3515D/F7 (YA1A) A01FEMF PL10.3COM...

This manual is also suitable for:

32pfl3515d/f7
