Cyber Console IC-1501 User Manual

LCD CONSOLE
IC-1501 / IC-1701
USER MANUAL
Package Inside
LCD Console x 1
USER Manual x 1
Power Cord x 1
Rack-Mount Brackets x 2
Screws (for Brackets) x 6
Key x 2
Features
• The keyboard, mouse and 15" LCD monitor was built-in on LCD console.
• Support resolution of 1024x768, 75Hz.
• Comply with the height of the 1U chassis specification and installable with a hanging
stand into a 19" chassis system.
• Requiry no additional software or hardware.

Specifications

Function
LEDs Power
Keyboard
Mouse
Console Port
Monitor
Audio
VGA Resolution
Power
Housing
Weight
Dimensions (LxWxH)
Keyboard and Mouse Specifications
Keyboard
Mouse
LCD Monitor Specifications
Size
Screen Type
Contrast
Brightness
View Angle
Resolution
Response Time
Display Color
IC-1501
IC-1501
1
1x6 pin mini-DIN Female (PS/2)
1x6 pin mini-DIN Female (PS/2)
1x HD-15 Female (Std. VGA/SVGA)
1x 3.5ψ Stereo Plug
1024x768@75Hz
AC 100~240V, 50~60Hz
Metal
12.1Kg
600x447x48 mm
Standard 104 key
Touch pad module
15 inch
TFT
500:1
2
250 cd/m
110°
1024x768@75Hz
16 ms
16.7 M
-1-
