  • Page 1 H81TM-ITX R2.0 H81TM-ITX R2.0 H 8 1 T M - I T X R 2 . 0 H 8 1 T M - I T X R 2 . 0...

  • Page 2: Copyright Notice

    (including damages for loss of proits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 he terms HDMI™ and HDMI High-Deinition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 4: Table Of Contents

    Expansion Slots (PCI Express Slots) Jumpers Setup Onboard Headers and Connectors Chapter 3 Software and Utilities Operation Installing Drivers A-Tuning Intel® Smart Connect Technology ASRock APP Shop 3.4.1 UI Overview 3.4.2 Apps 3.4.3 BIOS & Drivers 3.4.4 Setting Start8 Chapter 4 UEFI SETUP UTILITY...
  • Page 5 Introduction 4.1.1 UEFI Menu Bar 4.1.2 Navigation Keys Main Screen OC Tweaker Screen Advanced Screen 4.4.1 CPU Coniguration 4.4.2 Chipset Coniguration 4.4.3 Storage Coniguration 4.4.4 Intel® Smart Connect Technology 4.4.5 Super IO Coniguration 4.4.6 ACPI Coniguration 4.4.7 USB Coniguration Tools Hardware Health Event Monitoring Screen Boot Screen Security Screen...

  • Page 6: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for speciic information about the model you are using. You may ind the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 7: Speciications

    1.2 Speciications • hin Mini-ITX Form Factor (Compatible with Mini-ITX) Platform • Solid Capacitor for CPU power • Supports New 4 and 4 Generation Intel® Core i7/i5/i3/ Xeon®/Pentium®/Celeron® Processors with up to 65W TDP in an LGA1150 package • Supports Intel ®...
  • Page 8 • 1 x DC Jack Rear Panel • 1 x DVI-I Port • 1 x HDMI Port • 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) • 2 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED...
  • Page 9 • Microsot® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64- bit / 7 32-bit / 7 64-bit • FCC, CE, WHQL Certiica- • ErP/EuP Ready (ErP/EuP ready power supply is required) tions * For detailed product information, please visit our website: http://www.asrock.com...
  • Page 10 Due to limitation, the actual memory size may be less than 4GB for the reservation for sys- tem usage under Windows® 32-bit operating systems. Windows® 64-bit operating systems do not have such limitations. You can use ASRock XFast RAM to utilize the memory that Windows® cannot use.

  • Page 11: Motherboard Layout

    1.3 Motherboard Layout PLED PWRBTN USB6 CHA_FAN1 CIR1 PANEL1 DC Jack HDLED RESET USB4_5 SATA_POW1 ATX19V_IN1 BKT_PWR1 SATA_1 SATA_0 MONITOR_SWITCH1 LPC1 PNL_PWR1 USB 3.0 T: USB0 B: USB1 CMOS Battery DDR3_B1 COM1 DVI1 CLRCMOS1 DDR3_A1 BLT_VOL1 Intel H81TM-ITX HTPC1 32Mb BIOS RJ-45 USB 2.0...
  • Page 12 H81TM-ITX R2.0 No. Description Internal Power Header (ATX19V_IN1) USB 2.0 Header (USB6) SATA3 Connector (SATA_1) Chassis Fan Connector (CHA_FAN1) Consumer Infrared Module Header (CIR1) SATA3 Connector (SATA_0) USB 2.0 Header (USB4_5) SATA Power Connector (SATA_POW1) Monitor Switch Header (MONITOR_SWITCH1) System Panel Header (PANEL1)

  • Page 13: I/O Panel

    1.4 I/O Panel No. Description No. Description DC Jack* LAN RJ-45 Port** USB 3.0 Ports (USB3_01) USB 2.0 Ports (USB01) DVI-I Port (DVI1) Microphone (Pink) HDMI Port (HDMI1) Front Speaker (Lime) * Please use a 19V power adapter for the DC jack. his jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where the inner contact is +19 (±10%) VDC and the shell is (centre positive).

  • Page 14: Chapter 2 Installation

    H81TM-ITX R2.0 Chapter 2 Installation his is a hin Mini-ITX form factor motherboard. Before you install the motherboard, study the coniguration of your chassis to ensure that the motherboard its into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1150-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 16 H81TM-ITX R2.0...
  • Page 17 Please save and replace the cover if the processor is removed. he cover must be placed if you wish to return the motherboard for ater service.

  • Page 18: Installing The Cpu Fan And Heatsink

    H81TM-ITX R2.0 2.2 Installing the CPU Fan and Heatsink...

  • Page 19: Installing Memory Modules (So-Dimm)

    2.3 Installing Memory Modules (SO-DIMM) his motherboard provides two 204-pin DDR3 (Double Data Rate 3) SO-DIMM slots. It is not allowed to install a DDR or DDR2 memory module into a DDR3 slot; otherwise, this motherboard and SO-DIMM may be damaged. he SO-DIMM only its in one correct orientation.
  • Page 20 H81TM-ITX R2.0...

  • Page 21: Expansion Slots (Pci Express Slots)

    2.4 Expansion Slots (PCI Express Slots) here is 1 PCI Express slot and 1 Half mini-PCI Express slot on this motherboard. Before installing an expansion card, please make sure that the power supply is switched of or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 22: Jumpers Setup

    H81TM-ITX R2.0 2.5 Jumpers Setup he illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. he illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...

  • Page 23: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power PLED+ PLED-...
  • Page 24 H81TM-ITX R2.0 SATA Power Connector Please connect a SATA (SATA_POW1) power cable. (see p.6, No. 8) USB 2.0 Headers Besides two USB 2.0 ports USB_PWR (5-pin USB6) on the I/O panel, there (see p.6, No. 2) are three headers on this motherboard.
  • Page 25 Analog Surround Signal Signal Audio Header Name Name (17-pin HD_AUDIO2) SENSE (see p.6, No. 23) A_GND A_GND Center Surr_Rear_R A_GND A_GND Surr_Rear_L Surr_Side_R A_GND A_GND Surr_Side_L Front_R A_GND A_GND Front_L 3W Audio AMP Output Please connect the chassis Wafer Header speaker to this header.
  • Page 26 H81TM-ITX R2.0 Internal Power Header his motherboard (2-pin ATX19V_IN1) provides a 2-pin ATX 19V (see p.6, No. 1) power connector. CIR input Consumer Infrared his header can be used to +5VA Learn-in Module Header connect the remote controller (7-pin CIR1) receiver.
  • Page 27 Home heater PC Signal Name Signal Name Header HDMI CEC #Power_Button (7-pin HTPC1) SMB_DATA 3.3V Standby SMB_CLK No pin (see p.6, No. 24) Recording LED LVDS Panel Connector Signal Name Signal Name (40-pin LVDS1) ODD_Lane3_P ODD_Lane3_N EDID_3.3V (see p.6, No. 13) ODD_Lane2_P LCD_GND ODD_Lane2_N...
  • Page 28 H81TM-ITX R2.0 Monitor Switch Header his header can be used to (2-pin MONITOR_ PWRDN connect a switch that turns on/ SWITCH1) of the LVDS panel display’s (see p.6, No. 9) backlight.

  • Page 29: Chapter 3 Software And Utilities Operation

    Chapter 3 Software and Utilities Operation 3.1 Installing Drivers he Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. he CD automatically displays the Main Menu if “AUTORUN”...

  • Page 30: A-Tuning

    H81TM-ITX R2.0 3.2 A-Tuning A-Tuning is ASRock’s multi purpose sotware suite with a new interface, more new features and improved utilities, including XFast RAM, Dehumidiier, Good Night LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more. 3.2.1 Installing A-Tuning When you install the all-in-one driver to your system from ASRock’s support CD,...
  • Page 31 Tools Various tools and utilities. XFast RAM Boost the system’s performance and extend the HDD’s or SDD’s lifespan! Create a hidden partition, then assign which iles should be stored in the RAM drive. XFast LAN Boost the speed of your internet connection! Select a speciic mode for making the designated program's priority highest.
  • Page 32 H81TM-ITX R2.0 FAN-Tastic Tuning Conigure up to ive diferent fan speeds using the graph. he fans will automatically shit to the next speed level when the assigned temperature is met. Dehumidiier Prevent motherboard damages due to dampness. Enable this function and conigure the period of time until the computer powers on, and the duration of the dehumidifying process.
  • Page 33 OC Tweaker Conigurations for overclocking the system. System Info View information about the system. *he System Browser tab may not appear for certain models.
  • Page 34 H81TM-ITX R2.0 Live Update Check for newer versions of BIOS or drivers. Tech Service Contact Tech Service if you have problems with your computer. Please leave your contact information along with details of the problem.
  • Page 35 Settings Conigure ASRock A-Tuning. Click to select "Auto run at Windows Startup" if you want A-Tuning to be launched when you start up the Windows operating system.

  • Page 36: Intel® Smart Connect Technology

    H81TM-ITX R2.0 3.3 Intel® Smart Connect Technology Intel® Smart Connect Technology is a feature that periodically wakes your computer from Windows® sleep state to refresh email or social networking applications. It saves your waiting time and keeps the content always up-to-date.

  • Page 37: Setup Guide

    3.3.2 Setup Guide Installing ASRock Smart Connect Utility Step 1 Install ASRock Smart Connect Utility, which is located in the folder at the following path of the Support CD: \ ASRock Utility > Smart Connect. Step 2 Once installed, run ASRock Smart Connect from your desktop or go to Windows...
  • Page 38 H81TM-ITX R2.0 Step 3 Click the Add button. Take Foxmail as an example, add Foxmail to the Application list. Step 4 Select Foxmail from the Application List, then click the arrow pointing right to add this application to the Smart Connect List.
  • Page 39 Step 6 Double-click the Intel® Smart Connect Technology Manager icon in the Windows system tray. Step 7 Drag the slider to conigure how oten the system will connect to the network to download updates. Shorter durations will provide more frequent updates, but may cause more power consumption.
  • Page 40 H81TM-ITX R2.0 he system will wake up from sleep state periodically, and then start to update Foxmail. he screen will not display anything so the computer can maintain minimum power usage. Aterwards, the system will automatically return to sleep state again.

  • Page 41: Asrock App Shop

    Double-click on your desktop to access ASRock APP Shop utility. *You need to be connected to the Internet to download apps from the ASRock APP Shop. 3.4.1 UI Overview Category Panel Hot News...

  • Page 42: Apps

    H81TM-ITX R2.0 3.4.2 Apps When the "Apps" tab is selected, you will see all the available apps on screen for you to download. Installing an App Step 1 Find the app you want to install. he most recommended app appears on the let side of the screen. he other various apps are shown on the right.
  • Page 43 Step 3 If you want to install the app, click on the red icon to start downloading. Step 4 When installation completes, you can ind the green "Installed" icon appears on the upper right corner. To uninstall it, simply click on the trash can icon *he trash icon may not appear for certain apps.
  • Page 44 H81TM-ITX R2.0 Upgrading an App You can only upgrade the apps you have already installed. When there is an available new version for your app, you will ind the mark of "New Version" appears below the installed app icon. Step 1 Click on the app icon to see more details.

  • Page 45: Bios & Drivers

    3.4.3 BIOS & Drivers Installing BIOS or Drivers When the "BIOS & Drivers" tab is selected, you will see a list of recommended or critical updates for the BIOS or drivers. Please update them all soon. Step 1 Please check the item information before update. Click on to see more details.

  • Page 46: Setting

    H81TM-ITX R2.0 3.4.4 Setting In the "Setting" page, you can change the language, select the server location, and determine if you want to automatically run the ASRock APP Shop on Windows startup.

  • Page 47: Start8

    3.5.1 Installing Start8 Install Start8, which is located in the folder at the following path of the Support CD: \ ASRock Utility > Start8. 3.5.2 Coniguring Start8 Style Select between the Windows 7 style and Windows 8 style Start Menu. hen select...
  • Page 48 H81TM-ITX R2.0 Conigure Conigure provides coniguration options, including icon sizes, which shortcuts you want Start Menu to display, quick access to recently used apps, the functionality of the power button, and more. Control...
  • Page 49 Control lets you conigure what a click on the start button or a press on the Windows key does. Desktop Desktop allows you to disable the hot corners when you are working on the desktop. It also lets you choose whether or not the system boots directly into desktop mode and bypass the Metro user interface.

  • Page 50: Chapter 4 Uefi Setup Utility

    Chapter 4 UEFI SETUP UTILITY 4.1 Introduction ASRock Interactive UEFI is a blend of system coniguration tools, cool sound efects and stunning visuals. Not only will it make BIOS setup less diicult but also a lot more amusing. his section explains how to use the UEFI SETUP UTILITY to conigure your system.

  • Page 51: Navigation Keys

    4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 52: Main Screen

    When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Active Page on Entry Select the default page when entering the UEFI setup utility. UEFI Guide UEFI Guide is a quick tutorial for ASRock's UEFI setup Utility. You may abort the tutorial by pressing "esc".

  • Page 53: Oc Tweaker Screen

    4.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI sotware is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.

  • Page 54: Long Duration Maintained

    H81TM-ITX R2.0 CPU OC Fixed Mode CPU OC ix mode allows you to keep the max CPU ratio as your setting without throttling. Please note that overclocking may cause damage to your CPU and motherboard. It should be done at your own risk and expense.

  • Page 55: Dram Timing Coniguration

    GT Voltage Mode Auto: For optimized settings. Adaptive: Add voltage to the integrated GPU when the system is under heavy load. Override: he voltage is ixed. GT Adaptive Voltage Conigure the ixed voltage added to the integrated GPU. GT Voltage Ofset Conigure the voltage added to the integrated GPU when the system is under heavy load.
  • Page 56 H81TM-ITX R2.0 RAS# to CAS# Delay (tRCD) he number of clock cycles required between the opening of a row of memory and accessing columns within it. Row Precharge Time (tRP) he number of clock cycles required between the issuing of the precharge command and opening the next row.
  • Page 57 CAS Write Latency (tCWL) Conigure CAS Write Latency. tREFI Conigure refresh cycles at an average periodic interval. tCKE Conigure the period of time the DDR3 initiates a minimum of one refresh command internally once it enters Self-Refresh mode. tRDRD Conigure between module read to read delay. tRDRDDR Conigure between module read to read delay from diferent ranks.

  • Page 58: Fivr Coniguration

    H81TM-ITX R2.0 Conigure round trip latency for channel A. RTL (CHB) Conigure round trip latency for channel B. IO-L (CHA) Conigure IO latency for channel A. IO-L (CHB) Conigure IO latency for channel B. ODT WR (CHA) Conigure the memory on die termination resistors' WR for channel A.

  • Page 59: Voltage Coniguration

    Conigure the voltage added to the Vcore when the system is under heavy load. Vcore Voltage Additional Ofset Conigure the dynamic Vcore voltage added to the Vcore. CPU Cache Override Voltage Add voltage to the CPU Cache when the system is under heavy load. CPU Cache Voltage Ofset Conigure the voltage for the CPU Cache.

  • Page 60: Advanced Screen

    H81TM-ITX R2.0 4.4 Advanced Screen In this section, you may set the conigurations for the following items: CPU Coniguration, Chipset Coniguration, Storage Coniguration, Intel® Smart Connect Technology, Super IO Coniguration, ACPI Coniguration and USB Coniguration. Setting wrong values in this section may cause the system to malfunction.

  • Page 61: Cpu Coniguration

    4.4.1 CPU Coniguration Intel Hyper Threading Technology Intel Hyper hreading Technology allows multiple threads to run on each core, so that the overall performance on threaded sotware is improved. Active Processor Cores Select the number of cores to enable in each processor package. CPU C States Support Enable CPU C States Support for power saving.

  • Page 62: Intel Virtualization Technology

    H81TM-ITX R2.0 Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving. CPU Thermal Throttling Enable CPU internal thermal control mechanisms to keep the CPU from overheat- ing. No-Execute Memory Protection Processors with No-Execution Memory Protection Technology may prevent certain classes of malicious bufer overlow attacks.

  • Page 63: Chipset Coniguration

    4.4.2 Chipset Coniguration Primary Graphics Adapter Select a primary VGA. VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance.

  • Page 64: Onboard Lan

    H81TM-ITX R2.0 Render Standby Power down the render unit when the GPU is idle for lower power consumption. LVDS Coniguration his allows you to enable or disable the Onboard LVDS. Panel Type Selection Use this to select a panel type.
  • Page 65 Restore on AC/Power Loss Select the power state ater a power failure. If [Power Of] is selected, the power will remain of when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers. Good Night LED By enabling Good Night LED, the Power/HDD LEDs will be switched of when the system is on.

  • Page 66: Storage Coniguration

    H81TM-ITX R2.0 4.4.3 Storage Coniguration SATA Controller(s) Enable/disable the SATA controllers. SATA Mode Selection IDE: For better compatibility. AHCI: Supports new features that improve performance. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk performance but IDE mode does not have these advantages.

  • Page 67: Intel® Smart Connect Technology

    4.4.4 Intel® Smart Connect Technology ® Intel Smart Connect Technology ® Intel Smart Connect Technology automatically updates your email and social networks, such as Twitter, Facebook, etc. while the computer is in sleep mode.

  • Page 68: Super Io Coniguration

    H81TM-ITX R2.0 4.4.5 Super IO Coniguration Serial Port Enable or disable the Serial port. Serial Port Address Select the address of the Serial port.

  • Page 69: Acpi Coniguration

    4.4.6 ACPI Coniguration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. Check Ready Bit Enable to enter the operating system ater S3 only when the hard disk is ready, this is recommended for better system stability.
  • Page 70 H81TM-ITX R2.0 RTC Alarm Power On Allow the system to be waked up by the real time clock alarm. Set it to By OS to let it be handled by your operating system. USB Keyboard/Remote Power On Allow the system to be waked up by an USB keyboard or remote controller.

  • Page 71: Usb Coniguration

    4.4.7 USB Coniguration USB Controller Enable or disable all the USB ports. Intel USB 3.0 Controller Enable or disable all the Intel USB 3.0 ports. Legacy USB Support Enable or disable Legacy OS Support for USB 2.0 devices. If you encounter USB compatibility issues it is recommended to disable legacy USB support.

  • Page 72: Tools

    H81TM-ITX R2.0 4.5 Tools UEFI Tech Service Contact ASRock Tech Service if you are having trouble with your PC. Please setup network coniguration before using UEFI Tech Service. Easy Driver Installer For users that don’t have an optical disk drive to install the drivers from our support...

  • Page 73: Network Coniguration

    Network Coniguration Use this to conigure internet connection settings for Internet Flash. Internet Setting Enable or disable sound efects in the setup utility. UEFI Download Server Select a server to download the UEFI irmware. Dehumidiier Function If Dehumidiier Function is enabled, the computer will power on automatically to dehumidify the system ater entering S4/S5 state.
  • Page 74 H81TM-ITX R2.0 Dehumidiier CPU Fan Setting Conigure the speed of the CPU fan while Dehumidiier is enabled. he higher the value, the faster the fan speed. Max: 255 Min: 1 Save User Default Type a proile name and press enter to save your settings as user default.

  • Page 75: Hardware Health Event Monitoring Screen

    4.6 Hardware Health Event Monitoring Screen his section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. CPU Fan 1 Setting Select a fan mode for CPU Fans 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.

  • Page 76: Boot Screen

    H81TM-ITX R2.0 4.7 Boot Screen his section displays the available devices on your system for you to conigure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device.
  • Page 77 AddOn ROM Display Enable AddOn ROM Display to see the AddOn ROM messages or conigure the AddOn ROM if you've enabled Full Screen Logo. Disable for faster boot speed. Boot Failure Guard If the computer fails to boot for a number of times the system automatically restores the default settings.
  • Page 78 H81TM-ITX R2.0 Launch Storage OpROM Policy Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only. Do not launch? Launch Video OpROM Policy Select UEFI only to run those that support UEFI option ROM only. Select Legacy...

  • Page 79: Security Screen

    4.8 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 80: Exit Screen

    H81TM-ITX R2.0 4.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save coniguration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit...

  • Page 81: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp...
