Master Lock SafeSpace 2120D Instructions

SETTING THE COMBINATION
1. Locate the combination dials and viewing window on the lock.
2. Rotate the dials to the current combination. If the product is new,
lock is preset to initially open at 0-0-0-0. The combination will
appear in the window.
3. Locate the set button.
4. Using a tool (pen, screwdriver or similar object),
Step 4
FIRMLY PUSH THE SET BUTTON IN AND HOLD IT IN PLACE.
5. Move the dials to the desired combination.
IMPORTANT: If while moving the dials, the set button becomes
disengaged, stop and look at the dials. Note the combination.
To continue setting a new combination, repeat steps 4-6.
6. Release the set button. Record and save your new
combination at masterlockvault.com.
Step 5 & 6
TESTING THE COMBINATION
Before attaching the lock to your device:
1. Scramble the combination dials to conceal your combination.
2. Return to the combination you set.
3. Check that the lock button slides to the right.
Step 3
SECURING THE LOCK TO ELECTRONIC DEVICE
Step 1 & 2
USING THE SPACERS
gap
Step 2
CONFIRMING THE LOCK IS SECURE
LOCKED CORRECTLY:
Black spacer is tightly squeezed
Digits are all visible
©2012 Master Lock Company LLC Milwaukee, Wisconsin 53210 U.S.A.
www.masterlock.com
Made to exclusive Master Lock specifications in Taiwan R.O.C.
Fabriqué selon las spécifications exclusives de Master Lock en Taiwan R.O.C.
Hecho según las especificationes exclusivas de Master Lock en Taiwan R.O.C.
Marcas Registradas
1. Take the looped end of the cable and wrap it around a stationary object.
2. Feed the lock through the looped end of the cable.
3. Rotate the dials to the current combination. The combination will appear in the window.
4. Slide and hold the lock button to the right to align the locking teeth.
5. Insert the lock into your device's lock slot. Listen for a slight click.
6. Release the lock button and scramble the combination dials to lock and conceal your combination.
Step 5
Note: Due to variation in the size of lock slots on various devices, you may find that there is a gap between the lock
and the device. The supplied spacers are included to provide a custom fit and added security.
Step 3
Step 4
LOCKED INCORRECTLY:
Black spacer is not tightly squeezed
Digits are NOT all visible
2120D Computer Lock Instructions
Locking
Teeth
Spacers
Combination
Dials
1. Insert the lock into your device's lock slot (see step 4 in "Securing the
Lock to Electronic Device" section above). Release lock button.
2. Pull the lock away from the electronic device and check if there is a gap.
3. If so, remove lock from electronic device and add spacer.
To add a spacer, remove the spacer backing and adhere onto the lock.
4. Repeat steps 1 & 2. If there is still a gap present, add additional spacer(s)
on top of the first.
Step 5
5. Insert and push the lock firmly into your device's lock slot to
compress the spacers and have a tight fit. Listen for a slight click.
Lock
Button
Viewing
Window
Set
Button
Be sure to record your combination.
Store in safe location.
P17513
