Original Instruction Manual
CX2000 Compact Dust &
Chip Extractor
Version 3.0
August 2013
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Kg
Always wear safety glasses when
using woodworking equipment.
CX2000 Manual 3.0.indd 1
To register this product please visit
www.recordpower.info
Please see back cover for contact details.
i
Always read the instructions
provided before using
woodworking equipment.
Kg
Important
For your safety read instructions carefully
before assembling or using this product.
Save this manual for future reference.
i
19/08/2013 09:47
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Record Power CX2000
Summary of Contents for Record Power CX2000
- Page 1 Original Instruction Manual CX2000 Compact Dust & Chip Extractor Version 3.0 August 2013 To register this product please visit www.recordpower.info It is important to register your product as soon as possible in order to receive efficient after sales support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
-
Page 2: Table Of Contents
5. Getting to Know your Chip Collector 6. Specifications 7. Contents of the Package 8. Assembly 9. Operation 10. Maintenance 11. Troubleshooting 12. Electrical Connection & Wiring Diagram 13. Parts Diagram & Parts List CX2000 Manual 3.0.indd 2 19/08/2013 09:47... -
Page 3: Explanation Of Symbols
Indicates a risk of severe personal injury from electrical shock Risk of personal injury from lifting of heavy items Indicates a risk of severe personal injury from airborne objects Risk of fire CX2000 Manual 3.0.indd 3 19/08/2013 09:47... -
Page 4: General Health & Safety Guidance
13. Store machines safely when not in use using the fixings provided. • When not in use, machines should be stored in a dry place, out of reach CX2000 Manual 3.0.indd 4 19/08/2013 09:47... - Page 5 • Do not attempt to machine more than one work piece at a time. CX2000 Manual 3.0.indd 5 19/08/2013 09:47...
-
Page 6: Additional Health & Safety For Chip Extractors
• All Record Power chip extractors are designed solely for use with wood dust and chippings. Do not use the machine to remove vapours, fumes, gases or other materials such as plaster dust, as there is a risk of combustion. -
Page 7: Record Power Guarantee
Guarantee should be made directly to Record Power or its Authorised Distributor Record Power guarantees that for a period of 5 years from the date (for details of the Authorised Distributor in your country please see of purchase the components of qualifying Products (see clauses 1.2.1 your Product manual or check www.recordpower.info for details). -
Page 8: Getting To Know Your Chip Collector
Size: H1520 x W370 x D670 mm Motor: 230 V / 50 Hz / 550 W / 3/4 hp Full load current: 2.4 A Weight: 15 kg Filtration: 30 micron Air flow: 500 CFM CX2000 Manual 3.0.indd 8 19/08/2013 09:47... -
Page 9: Contents Of The Package
Extraction hose Flat Washer Left Frame Support Plate Right Frame Knob 4pcs Bag support arm Socket head cap screw 4pcs Filter bag Flat washer 4pcs Collection Bag Nylon locking nut 4pcs Washer hose pipe clip CX2000 Manual 3.0.indd 9 19/08/2013 09:47... -
Page 10: Assembly
4. Position the support plate (O) as fig 5 and Fig.8.3 lock in place with socket head cap screws (Q), washers (R) and nylon locking nuts (S). Ensure the frame is assembled correctly, then tighten. Fig 8.3. CX2000 Manual 3.0.indd 10 19/08/2013 09:47... - Page 11 Place the spring washer (M) and washer (N) on the bag support arm and screw the bag support arm to the motor and housing, Fig 8.5. Lock the arm in position using the butterfly nut. CX2000 Manual 3.0.indd 11 19/08/2013 09:48...
- Page 12 9. Finally, attach the 100 mm diameter extraction hose to the inlet on the underside of the motor and housing (directly beneath the motor) using the hose clip. CX2000 Manual 3.0.indd 12 19/08/2013 09:48...
-
Page 13: Operation
This will ensure all waste is extracted from the machinery and the extraction hose. Empty the contents of the collection bag when it is within 100 mm (4') one the top of the bag. CX2000 Manual 3.0.indd 13 19/08/2013 09:48... -
Page 14: Maintenance
1. Remove the hose from the machine and unblock. 2. Blocked inlet. 2. Remove the collection bag and carefully unblock the inlet 3. Hose diameter reducer being used. using a suitable tool. 3. Remove the reducer. CX2000 Manual 3.0.indd 14 19/08/2013 09:48... -
Page 15: Electrical Connection & Wiring Diagram
In this case there will not be an earth wire within the circuit. qualified electrician. In the case of the BS1363 plug for use in the UK, always ensure that it is fitted with a fuse conforming to BS1362 appropriate to the rating of the CX2000 Manual 3.0.indd 15 19/08/2013 09:48... - Page 16 13. Parts Diagrams CX2000 Manual 3.0.indd 16 19/08/2013 09:48...
-
Page 17: Parts List
Tube Joint Base Spring Washer Spring Pin Butterfly Nut Washer Filter Bag Wheel Motor and Housing Impeller Frame Base Capacitor L Joint Tube Base Washer L Joint Tube Cover Bolt-L Tube Pad 100mm Hose clip CX2000 Manual 3.0.indd 17 19/08/2013 09:48... - Page 18 EU Declaration of Conformity Cert No: EU / CX2000 / 1 RECORD POWER LIMITED, Centenary House, 11 Midland Way, Barlborough Links, Chesterfield, Derbyshire, S43 4XA declares that the machinery described:- Type: Dust Collector Model No: CX2000 Serial No ................. Conforms with the following directives:-...
- Page 19 CX2000 Manual 3.0.indd 19 19/08/2013 09:48...
- Page 20 Derbyshire, S43 4XA Tel: 1300 124 422 Tel: 0800 142 326 Tel: 01246 561 520 Tel: 01246 561 520 Fax: 1800 262 725 Fax: 09 2717 237 www.recordpower.co.uk www.recordpower.co.uk www.recordpower.com.au www.recordpower.co.nz Made in China CX2000 Manual 3.0.indd 20 19/08/2013 09:48...
